HYPERFOR
I
ATTUATORE ELETTROMECCANICO
400V IRREVERSIBILE A CREMAGLIERA
PER CANCELLI SCORREVOLI FINO A
4000 KG DI PESO
GB
400V ELECTRO-MECHANICAL
IRREVERSIBLE RACK ACTUATOR
FOR SLIDING GATES UP TO 4000 KG
F
OPERATEUR ELECTROMECANIQUE
400V IRREVERSIBLE A CREMAILLERE
POUR PORTAILS COULISSANTS
JUSQU'A 4000 KG DE POIDS
E
MOTOR ELECTROMECANICO 400V
IRREVERSIBLES A CREMALLERA
PARA PUERTAS CORREDERAS
HASTA 4000 KG DE PESO
ZIS380
IL 404-1
EDIZ. 28/01/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYPERFOR and is the answer not in the manual?

Questions and answers

Related Manuals for V2 HYPERFOR

Summary of Contents for V2 HYPERFOR

  • Page 1 ZIS380 IL 404-1 EDIZ. 28/01/2019 HYPERFOR ATTUATORE ELETTROMECCANICO 400V IRREVERSIBILE A CREMAGLIERA PER CANCELLI SCORREVOLI FINO A 4000 KG DI PESO 400V ELECTRO-MECHANICAL IRREVERSIBLE RACK ACTUATOR FOR SLIDING GATES UP TO 4000 KG OPERATEUR ELECTROMECANIQUE 400V IRREVERSIBLE A CREMAILLERE POUR PORTAILS COULISSANTS JUSQU’A 4000 KG DE POIDS...
  • Page 2 565 mm...
  • Page 3 23 - ANOMALIE DI FUNZIONAMENTO In questo paragrafo vengono elencate alcune anomalie di funzionamento che si possono presentare, ne viene indicata la causa e la procedura per porvi rimedio. VISUALIZZAZIONE DESCRIZIONE SOLUZIONE Led MAINS spento Alimentazione della parte logica assente Controllare il fusibile F1 Led OVERLOAD acceso Alimentazione accessori 24V sovraccarica...
  • Page 4 V2 raccomanda l’utilizzo delle seguenti norme tecniche: L’intervallo raccomandato tra ogni manutenzione è di sei mesi, le verifiche previste dovrebbero riguardare almeno: •...
  • Page 5 Concordate con il vostro installatore un piano di manutenzione con frequenza periodica; V2 SPA raccomanda un piano di manutenzione da eseguire ogni 6 mesi per un normale utilizzo domestico, ma questo periodo può...
  • Page 6 - 30 -...

  • Page 7: Table Of Contents

    INDEX 1 - GENERAL SAFETY INFORMATION ........................1.1 - PRELIMINARY CHECKS AND IDENTIFICATION OF THE TYPE TO BE USED ............1.2 - TECHNICAL ASSISTANCE SERVICE ........................1.3 - EU DECLARATION OF CONFORMITY ....................... 2 - TECHNICAL DATA ..............................3 - INSTALLATION OF THE MOTOR ..........................3.1 - INSTALLATION OF THE MOTOR ........................

  • Page 8: General Safety Information

    V2 customer assistance service. 1 - GENERAL SAFETY INFORMATION • V2 declines all responsibility for failure to comply with good construction practice standards in addition to structural deformation of the gate that might occur during use.

  • Page 9: Preliminary Checks And Identification Of The Type To Be Used

    1.1 - PRELIMINARY CHECKS AND IDENTIFICATION OF THE TYPE TO BE USED The automation device should not be used until installation, as specified in “Testing and start-up”, has been performed. It should be remembered that the device does not compensate for defects caused by improper installation, or poor maintenance, thus, prior to proceeding with installation, ensure that the structure is suitable and meets current standards and, if necessary, perform any structural modifications aimed at the implementation of safety gaps and the protection or segregation of all crushing, shearing and transit zones, and verify that:...

  • Page 10: Technical Assistance Service

    4800 N Declaration in accordance with Directives: 2014/35/UE (LVD); 2014/30/UE (EMC); 2006/42/CE (MD) ANNEX II, PART B Duty cicle The manufacturer V2 S.p.A., headquarters in Corso Principi di Pinion M6 - Z15 Piemonte 65, 12035, Racconigi (CN), Italy Operation temperature -20°C ÷...

  • Page 11: Installation Of The Motor

    7. Adjust the 4 grains F to make the motor be perfectly levelled 8. Control that the motor is perfectly parallel to the gate, then To fix HYPERFOR, follow the instructions below: insert the 4 washers R and lightly screw the 4 bolts D 1.

  • Page 12: Mounting The Rack

    3.2 - MOUNTING THE RACK 1. Release the motor and turn the gate completely open. 2. Fix all the rack elements to the gate, making sure that they stand at the same height than the motor pinion. The rack MUST BE positioned 1 or 2 mm over the pinion of the motor all the gate length.

  • Page 13: Installing The Magnetic Limit Switches

    3.4 - INSTALLING THE MECHANICAL LIMIT ATTENTION: check that the limit switch bracket will SWITCHES work effectively on the limit switch spring of the motor. If necessary add thickness between the lower part of the Install limit switches on the rack and fix them using the screws rack and the limit switch bracket in order to keep to the provided in the tool kit.

  • Page 14: Motor Overriding System

    3.6 - MOTOR OVERRIDING SYSTEM In the absence of power, the gate can be released by operating on the motor: 1. Open the rear hatch 2. Screw anti-clockwise (left thread) the ring nut K using the supplied 19” wrench until the pinion is released To restart the automation proceed as follows: 1.

  • Page 15: Description Of The Control Unit

    5 - DESCRIPTION OF THE CONTROL UNIT 7 - CONTROL PANEL The control unit HEAVY2 is an innovative V2 product that When the power supply is turned on the display shows in guarantees a safe and reliable automation of industrial sliding sequence the following information: gates.

  • Page 16: Electric Connections

    7 - ELECTRIC CONNECTIONS TOP BOARD LOWER BOARD Antenna shielding MOTOR Motor (PRE-WIRED) U3-U2-U1 Antenna REL2 relay options ING1 - configurable input to connect devices with OUTPUT N.O. contact parameter a Z6-Z5 REL2 DEFAULT = (no function) parameter ING1 REL1 relay options DEFAULT = (activates the cycle) START...
  • Page 17 VOLTAGE SELECTOR MAINS FRONT PANEL ATTESA OVERLOAD A1A2 S1 S2 S3 S4 S5 S6 S7 S8 S9 H1H2 H3 H4 H5 H6 H7 H8 E1 E2 E3 E4 E5 T1 T1 MOTOR OUTPUT MAINS - 41 -...

  • Page 18: Power Supply

    8 - POWER SUPPLY 11 - PHOTOCELLS The control unit must be fed by a 400V - 50Hz electric line, The unit has two inputs for photocells (normally closed contact), protected by a differential magnetothermal switch complying with which can be independently enabled and associated with different the law provisions in force.

  • Page 19: Power Of Photocells And And Functional Test

    11.1 - POWER OF PHOTOCELLS AND AND FUNCTIONAL TEST Photocells can be powered to 24 Vac (FIG.1) or 12 Vdc (FIG.2). POWER SUPPLY 12VDC Regardless of the selected function, the photocells can be tested The DC power supply is available between terminals prior to each movement.

  • Page 20: Detection Of Obstacles (Amperometric Sensor, Encoder, Safety Ribbons)

    12 - DETECTION OF OBSTACLES WARNING: (AMPEROMETRIC SENSOR / SAFETY • If you do not connect any ribbon to the terminal S7, the RIBBONS) parameter must be set to COS1 • If you do not connect any ribbon to the terminal S8, the The presence of an obstacle that prevents the movement of the parameter must be set to...

  • Page 21: Blinker

    13 - BLINKER 14 - OPEN GATE WARNING LIGHT The HEAVY2 unit has two outputs for the management of the The unit is fitted with a 24Vdc - 3W output that allows the blinker: connection of a warning light. The open gate warning light shows in real time the status of the 1.

  • Page 22: Control Mode From Terminal Board

    16 - CONTROL MODE FROM TERMINAL • Stop ( value to be set) STOP This function corresponds to a stop command: it is the only BOARD case in which the connected device must work with normally closed contact; it can be used to stop the gate and hold it in a To control the gate through external devices you need have to locked position.

  • Page 23: Remote Control Mode

    17 - REMOTE CONTROL MODE 19 - SPECIAL OPERATING MODES The HEAVY2 unit is fitted for the connection of an MRx series The HEAVY2 unit has some special operating modes, to be used receiver. The receiver has 4 channels, which can be associated only in special cases.

  • Page 24: Option Relay Output

    20 - OPTION RELAY OUTPUT 20.1 - COURTESY LIGHT The unit has 2 relay outputs with normally open dry contact The courtesy lights can be operated in the following ways: (maximum current 10A on 230V) that can be configured with different functions through the parameters 1.

  • Page 25: Service Reporting

    The ADI (Additional Devices Interface) interface of the control activate a warning light. unit allows the connection to V2 optional modules. Refer to V2 catalogue or to the technical sheets to see which optional modules with ADI interface are available for this control 20.4 – OPENING COMMAND unit.

  • Page 26: Programming

    22 - PROGRAMMING 22.2 - LOADING DEFAULT PARAMETERS The programming of the functions and times of the unit is carried If necessary, you can reset all parameters to their DEFAULT values out through the configuration menus, accessible and searchable (see table on page 52) FRONT PANEL through the 3 buttons and OK placed next to the display of...

  • Page 27: Reading The Cycle Counter

    22.5 - PROGRAMMING THE OPERATING 8. - To confirm the value displayed, press the OK button, then select the menu to store the values of the FINE PARAMETERS sensors, the limits of the travels and exit the function - To change the value of the parameters SEN.A SEN.C 1.
