Canon imagePRESS Server F200 Installation And Service Manual page 54

R
EPLACING PARTS
T ,
O REPLACE BOARDS CABLES
1 Replace the hard disk drive bracket, with hard disk drive attached (see
You removed the hard disk drive bracket to provide clearance for removing the motherboard.
2 Replace the following cables (see
• CPU power cable
• Motherboard power cable
• UIB cable
• Hard disk drive cable
• DVD drive cables:
– Power and data combination cable
– SATA data cable
Connect the thin, black SATA power cable connectors to the hard disk drive and DVD
N :
OTE
drive. Do not connect the white, 4-pin power cable connectors. Connecting both types of
power cables will damage the hard disk drive and DVD drive. For more information on
connector locations, refer to the label that is on the bottom surface of the chassis.
• Front panel USB port cables
• Speaker cable
• Power button cable
• Reset button cable
• Front panel fan cable
3 Secure cables as necessary with any plastic cable clamp that you may have removed earlier.
4 Replace the copier interface board (see
Make sure to install the board mounting bracket screw to secure the board to the chassis. Press
down firmly on the top of the board as you insert the screw.
Make sure that unused connector panel slots are covered with slot covers. Uncovered
N :
OTE
slots reduce air flow and may cause the imagePRESS Server to overheat.
5 If you reinstalled the old motherboard, reassemble the imagePRESS Server and verify its
functionality (see
6 If you replaced the motherboard with a new motherboard, do the following:
• Remove the battery (see
• Wait two minutes to allow the motherboard electrical components to fully discharge.
• Reinstall the battery.
• Reassemble the imagePRESS Server (see
• Reset the time and date in Setup (see Configure Help for more information).
,
AND COMPONENTS
page 48
page 48
page 78).
page 62).
for the connector locations).
for the location).
page 78).
54
page 71).
