ScANNeR PARtS

1
2
3
4
8
1 Open tab
5
Automatic
2 Document Feeder
6
(ADF) and cover
Output tray
7
3
extension
4
Stopper
8
Input tray extension
5
and Support Flap
a
6 Input tray
b
c
7
Paper Guides
8 control Panel
d
Power and Power
a
leD
Scan/Stop and
b
Operation leD
c
leD Display
d
Up/Down Selector
9 Power Jack
9
10
10
USb Port (to Pc)
Pull this tab to open the ADF cover.
Feed paper stack from the Input tray
automatically for scanning. Open the ADF
cover when maintenance is required.
Pull the tray out to hold paper as it exits
from the ADF.
lift it up to keep paper from sliding off.
extend them if the paper is longer than the
Input tray.
holds paper stack to be fed into the ADF for
scanning.
Adjust the Guides to match the paper width.
turn on or off the power. Show the leD
indicator (see Status leD Indicators).
Start or stop a scan. Show the leD
indicator (see Status leD Indicators).
Display the selected Scan-to option from
1~9.
Use the up and down arrow to cycle
through the Scan-to options from 1~9.
connect the Power Adapter.
connect the USb cable to a computer.
