  • Page 1 Escape Owner’s Manual...

  • Page 2: Table Of Contents

    All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company of Australia Limited.
  • Page 3 INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing. Ford may change the contents without notice and without incurring obligation.

  • Page 4: Introduction

    Introduction SPECIAL NOTICES Notice to owners of four wheel drive (4WD) vehicles 4WD vehicles have a significantly higher rollover rate than other types of vehicles. Before you drive your vehicle, please read this Owner’s Guide carefully. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of control or an accident.
  • Page 5 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Supplementary Restraint Fasten Safety Belt System Child Seat Installation Child Seat Warning Child Seat Tether Brake System Anchorage Brake Fluid - Anti-Lock Brake System Non-Petroleum Based Traction Control...
  • Page 6 Introduction Vehicle Symbol Glossary Interior Luggage Compartment Release Panic Alarm Symbol Do Not Open When Hot Engine Oil Engine Coolant Avoid Smoking, Flames, Temperature or Sparks Explosive Gas Battery Power Steering Fluid Battery Acid Fan Warning Emission System Maintain Correct Fluid Passenger Compartment Level Air Filter...

  • Page 7: Instrumentation

    Instrumentation Hazard control (pg. 128) Rear window defroster Audio system control (pg. 22) (pg. 18) 4wd control (pg. 18) 6000 CD RDS E O N BASS/TREB FADE/BAL AM/FM CD CHANGER COMPATIBLE VOL ON/OFF MENU SEEK Climate controls Auxiliary power point (pg.
  • Page 8 Instrumentation Windshield wiper/washer control Headlamp and turn (pg. 41) signal control (pg. 56) Gearshift lever (pg. 109) Fog lamp control* Instrument cluster (pg. 63) (pg. 8) Power mirror control Cruise controls* (pg. 18) Tilt steering wheel lever (pg. 53) (pg. 52) Instrument panel dimmer Driver air bag control...
  • Page 9 Instrumentation WARNING LIGHTS AND CHIMES Service engine soon Your vehicle is equipped with a computer that monitors the engine’s emission control system. This system is commonly known as the On Board Diagnostics System (OBD II). The OBD II system protects the environment by ensuring that your vehicle continues to operate within factory specifications.
  • Page 10 Instrumentation 3. The fuel cap may not have been properly installed and securely tightened. These temporary malfunctions can be corrected by filling the fuel tank with high quality fuel of the recommended octane and/or properly installing and securely tightening the fuel cap. After three driving cycles without these or any other temporary malfunctions present, the light should turn off.
  • Page 11 Instrumentation position. If the light fails to illuminate, continues to flash or remains on, have the system serviced immediately. Safety belt Momentarily illuminates when the ignition is turned to the ON position to remind you to fasten your safety belts. For more information, refer to the Seating and safety restraints chapter.
  • Page 12 Instrumentation High beams Illuminates when the high beam headlamps are turned on. Cruise control (where fitted) This light comes on when the vehicle cruise control is engaged and actively controlling the vehicle speed. It turns off when the cruise control OFF or CANCEL controls are pressed or the brake is applied.
  • Page 13 Instrumentation Four wheel drive indicator Illuminates when 4x4 the system has been activated by not pressing the lock switch. If the light continues to flash have the system serviced. Door ajar Illuminates when any door, liftgate or liftgate window is open. O/D off Illuminates when the Transmission Control Switch (TCS), refer to...
  • Page 14 Instrumentation Supplemental Restraint System (SRS) warning chime For information on the SRS warning chime, refer to the Seating and safety restraints chapter. Key-in-ignition warning chime Sounds when the key is left in the ignition in the OFF/LOCK or ACC position and any door, liftgate or liftgate window is opened. Headlamps on warning chime Sounds when the headlamps or parking lamps are on, the ignition is off (and the key is not in the ignition) and the driver’s door is opened.
  • Page 15 Instrumentation Never remove the coolant reservoir cap while the engine is running or hot. This gauge indicates the temperature of the engine coolant, not the coolant level. If the coolant is not at its proper level the gauge indication will not be accurate. Tachometer Indicates the engine speed in revolutions per minute.
  • Page 16 Instrumentation empty, there is a small amount of reserve fuel in the tank. When refueling the vehicle from empty indication, the amount of fuel that can be added will be less than the advertised capacity due to the reserve fuel. The arrow near the fuel pump icon indicates which side of the vehicle the fuel filler door is located.

  • Page 17: Controls And Features

    Controls and features PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel. • Push and hold top of control to brighten. • Push and hold bottom of control to dim.
  • Page 18 Controls and features POWER SIDE VIEW MIRRORS The ignition must be in the ACC or ON position to adjust the power side view mirrors. To adjust your mirrors: 1. Rotate the control clockwise to adjust the right mirror and rotate the control counterclockwise to adjust the left mirror.
  • Page 19 Controls and features 3. Return to the center position to lock mirrors in place. Fold-away mirrors Pull the side mirrors in carefully when driving through a narrow space, like an automatic car wash. FOUR WHEEL DRIVE (4X4) LOCK SWITCH This control operates the four wheel drive (4X4) system.
  • Page 20 Controls and features CLIMATE CONTROL SYSTEM Manual heating and air conditioning system Fan speed control Controls the volume of air circulated in the vehicle. Temperature control knob Controls the temperature of the airflow inside the vehicle. The heater maintains warmth only when the engine is operating.
  • Page 21 Controls and features been enabled. To engage the A/C mode, the fan control must be set to at least position one, otherwise the indicator will not illuminate and the A/C will not engage despite being set. • (Recirculated air selector) — An indicator light will illuminate when the recirculated air mode has been selected.
  • Page 22 Controls and features • Do not put objects under the front seat that will interfere with the airflow to the back seats. • Remove any snow, ice or leaves from the air intake area at the base of the windshield. •...

  • Page 23: Audio Systems

    Audio The following units are compatible with a CD changer 6000CD series unit CD eject Fade/Balance Waveband/ control changer AutoStore control selector Traffic information Bass/ Treble Programme control type selection 6000 CD RDS E O N BASS/TREB FADE/BAL AM/FM CD CHANGER COMPATIBLE VOL ON/OFF MENU SEEK...
  • Page 24 Audio 6006E CD control Bass Anti-theft Anti-theft control protection protection panel release panel button CD eject Programme Traffic CD load type selection information DISC CD PLAYER LOAD 6006E CD RDS E·O·N VOL ON/OFF MENU BASS FADE SEEK SEEK TREB Balance Station MENU SEEK...
  • Page 25 BASS FADE Replacement panels Your Ford Dealer will require the following information if you need to order a replacement panel: 1. Your name and address. 2. The Vehicle Identification Number (visible in the corner of the windscreen).
  • Page 26 KEYCODE SECURITY Units incorporate a unique Keycode security number that must be entered before the unit will operate. Normally, the Ford Dealer does this during the pre-delivery inspection. If the battery is disconnected for any reason, or the audio unit is...
  • Page 27 • After ten incorrect attempts the unit will be permanently inoperative and ‘LOCK 10’ or ‘LOCKED’ will be displayed. Contact your local Ford Dealer for help. VEHICLE IDENTIFICATION (VID) Every vehicle has a unique vehicle identification number. If this is entered into the audio unit, it helps the police to locate the true owner of a recovered unit.
  • Page 28 Audio To enter or amend the number: MENU 1. Press and hold the MENU button for two seconds, then press it repeatedly until the display shown opposite appears. 2. Press the SEEK control. The current vehicle identification number will be shown or, if a number has yet to be entered, NO VID will be displayed.
  • Page 29 Audio The following tips will help you to get the best sound from your Ford audio system. RADIO RECEPTION Always store stations broadcasting the strongest signal on the radio presets. AM (Medium/Long Wave) reception Under most conditions, strong MW and LW signals provide stable sound quality and little signal disturbance.
  • Page 30 Audio RADIO DATA SYSTEM (RDS) Some radio stations on the FM waveband transmit additional code in their broadcast signal that allows receivers equipped with the necessary decoder to present more information to the listener. This is known as the Radio Data System (RDS). The additional features include the station name, the station’s programme identification number, alternative broadcasting frequencies, clock and date information, and traffic information.
  • Page 31 Audio Alternative Frequencies (AF) By using the PI code, the radio receiver can store a list of transmitters in the same, or adjacent, areas transmitting a particular programme. Consequently, if one transmitter’s signal weakens, the audio unit can automatically retune to a stronger alternative signal, if one exists. Under certain conditions, however, alternative frequency tuning may temporarily disrupt normal reception.
  • Page 32 Audio Clock and Date Displays Time and date information broadcast via RDS will automatically update the information held in the audio unit. In most units, it cannot be manually changed or altered. When the unit is switched on a series of bars may appear until an RDS signal has been received.
  • Page 33 Audio ON/OFF VOL ON/OFF Press the volume control. The on/off/volume control will also operate the unit for up to one hour with the ignition turned off. The radio will switch off automatically after one hour. Volume control Use this control to raise or lower the volume of the current audio source at any time.
  • Page 34 Audio Audio distortion reduction (CLIP) CLIP automatically detects sound distortion and reduces the unit’s volume level until the distortion has been eliminated. This means that whilst the display might change numerically when you raise the volume manually with the control, there may be no actual increase in sound.
  • Page 35 Audio Bass/Treble control Adjusts the amount of bass or treble response from any audio BASS/TREB FADE/BAL source. • Where the adjustment is featured on a single button, press the button once for bass or twice for treble. Where there are separate buttons, press the button once.
  • Page 36 Audio Waveband selector AM/FM This control allows you to switch between the AM waveband (medium and long wave broadcasts) and the FM waveband. If you press the button repeatedly during radio reception, you can select from AM, FM1, FM2 or AutoStore.
  • Page 37 Audio To activate this feature: • Select a waveband. • Tune to the station required. • Press and hold one of the preset buttons. The audio unit will mute. When sound returns, the station has been stored. AutoStore selector AutoStore can be used to store the six stations with the strongest signals.
  • Page 38 Audio Station tuning controls Automatic tuning selects the next station up or down the current waveband according to which direction arrow was pressed on the seek control. Manual tuning requires you to set the manual tuning option in the menu after which the unit will then search up or down the frequency scale in smaller increments –...
  • Page 39 Audio Scan tuning • Press the MENU (or MAN) button repeatedly until the display shown opposite appears. • Use the SEEK button to scan up or down the selected waveband. ‘Scn’ flashes in the display and each station is played for a few seconds in turn.
  • Page 40 Audio With ‘AF-MAN’ selected, the unit operates in a similar way to ‘AF- AUTO’ or ‘AF-ON’, but only searches for an alternative frequency when prompted. With ‘AF-OFF’ selected, the original stored frequency remains selected. In this mode, ‘AF-OFF’ will be displayed every time the unit is turned on.
  • Page 41 Audio Using PTY While searching, the audio unit displays the programme type requested and ‘PTY’ flashes in the display. When a programme is found, the station name and the programme type flash alternately in the display. While they are flashing, press SEEK again to find another station broadcasting the same programme type.
  • Page 42 Audio When traffic information is broadcast, it will automatically interrupt normal radio, tape or CD playback and ‘TRAFFIC’ will appear in the display. If the traffic signal weakens, ‘TP’ will flash in the display. Press the SEEK button to find another traffic station.
  • Page 43 Audio Local or distant traffic announcements The number of RDS-EON traffic announcements may become excessive in some areas so there is an option on some units to select between local traffic information and all available information. If your radio is equipped with this feature: •...
  • Page 44 Irregular shaped CDs and CDs with a scratch protection film or self- adhesive labels attached should not be used. Please contact your Authorised Ford Dealer for further information. Traffic announcement volume Traffic announcements interrupt normal broadcasts at a preset...
  • Page 45 Audio During news broadcasts, the display alternates between the station name and ‘NEWS’. News interrupts are broadcast at the same preset volume level as traffic announcements. Note: This feature does not work on the AM waveband. Clock and dates displays Audio units have a built in facility that will receive the current time and date from the RDS decoder.
  • Page 46 Audio One of the disc icons will flash in the display and the word ‘WAIT’ will appear. The CD will be loaded into the first available location. A numeral appears in one of the six disc icons to confirm the CD’s location.
  • Page 47 Audio If the power to 6000E units has been disconnected, then reconnected, the unit will automatically check for the presence of discs in the magazine. This will take approximately 45 seconds. During this time all functions except Keycode entry will be locked out. STARTING PLAYBACK Note: Radio reception is automatically cut off when you play a CD.
  • Page 48 Audio If a selected disc is damaged or upside down, the warning ‘CHECK’ flashes and the disc number is displayed. The unit then selects the next available disc. If a changer is fitted, but the magazine is missing or incorrectly inserted, ‘NO DISCS’...
  • Page 49 Audio Fast forward/reverse Press and hold SEEK or SEEK to search backwards or forwards within the tracks on the disc. Random track selection Random track playback, also known as shuffle, plays all tracks on the CD in random order. To activate this feature: •...
  • Page 50 Audio Track scanning The SCAN function on certain units allows you to preview each track for a few seconds. When selected, ‘Scn’ flashes in the display. • Press the MENU button repeatedly until the display shown opposite appears. • Use the SEEK button to scan up or down the tracks selected.
  • Page 51 Audio ‘EJECT’ and ‘REMOVE’ appear in the display and the disc is held ready for removal. If it is not removed, the disc will be pulled back into the audio unit and CD playback will restart. After removal, ‘INSERT’ will be displayed briefly to allow a new disc to be inserted if required.
  • Page 52 Clean the disc and try again. If the error still shows, see your Ford Dealer. Ambient temperature too hot - unit will not work until it has cooled down. There is an eject fault. See your Ford Dealer. 6006E unit Description/rectification Ambient temperature too hot – unit will not work until it has cooled down.
  • Page 53 Controls and features POSITIONS OF THE IGNITION 1. LOCK, locks the gearshift lever and allows key removal. 2. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 3. ON, all electrical circuits operational.
  • Page 54 Controls and features TURN SIGNAL CONTROL • Push up to activate the left turn signal. • Push down to activate the right turn signal. MANUAL TILT STEERING COLUMN Push the tilt steering wheel lever downward to move the steering wheel up or down. Pull the control up into the original position to lock the steering wheel in position.
  • Page 55 Controls and features CRUISE CONTROL (WHERE FITTED) To turn cruise control on • Press ON. Cruise control will not work until the vehicle is travelling at or above 48 km/h (30 mph). To avoid the possibility of loss of control, the cruise control should not be used in heavy traffic (city driving) or on winding, slippery or unsealed...
  • Page 56 Controls and features To set a higher set speed • Press and hold SET ACC. Release the control when the desired vehicle speed is reached or • Press and release SET ACC to operate the Tap-Up function. Each press will increase the set speed by 1.6 km/h (1 mph) or •...
  • Page 57 Controls and features To disengage cruise control • Depress the brake pedal. Disengaging the cruise control by depressing the brake pedal will not erase the previously programmed set speed. • Press OFF. Pressing OFF will erase the previously programmed set speed. To return to a previously set speed •...
  • Page 58 Controls and features WINDSHIELD WIPER AND WASHER For intermittent operation, move control down one position. Adjust the rotary control to the desired speed setting. For normal or low speed wiper operation, move control down two positions from OFF.
  • Page 59 Controls and features For high speed wiper operation, move control down three positions from OFF. To activate the windshield washer, pull control toward you. Release control to stop washer fluid spray. MIST FUNCTION Move control up and release for one wipe.
  • Page 60 Controls and features Rear window wiper/washer controls For intermittent operation of rear wiper, rotate end of control upward to the INT position. For normal speed rear wiper operation, rotate control upward to To activate the rear washer, rotate the control to the position and release.
  • Page 61 Controls and features INTERIOR LAMPS (WHERE FITTED) Dome lamps and map lamps The front dome lamp is located overhead between the driver and passenger seats. With overhead console When the dome lamp control switch is moved to the on position, the dome lamp will stay on at all times.
  • Page 62 Controls and features SUNROOF (WHERE FITTED) To operate the sunroof: • To open, and hold the rear portion of the control. • To close, press and hold the front portion of the control. To operate the sunroof vent position: • To open, press and hold the front portion of the control. This will open the vent.
  • Page 63 Controls and features HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to also turn on the headlamps. Your vehicle is equipped with a battery saver feature which, if you leave the headlamps on, automatically turns off the headlamp after 10 minutes when...
  • Page 64 Controls and features FOGLAMP CONTROL (WHERE FITTED) Turn on the parking lamps. Press the foglamp control, located on the instrument panel, to activate the foglamps. The foglamp LED will illuminate when the foglamps are Press the foglamp control to deactivate the foglamps. POWER WINDOWS Press and hold the rocker switches to open and close windows.
  • Page 65 Controls and features One touch down • Press AUTO completely down to the second detent. The driver’s window will open fully. Depress up to stop window operation. WINDOW LOCK The window lock feature allows only the driver to operate the power windows.
  • Page 66 Controls and features POWER DOOR LOCKS Press control to unlock all doors. Press control to lock all doors. CHILDPROOF DOOR LOCKS When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the doors are unlocked.
  • Page 67 Controls and features • Ashcup Use only soft cups in the cupholder. Hard objects can injure you in a collision. AUXILIARY POWER POINTS The auxiliary power point is located on the instrument panel. Do not plug optional electrical accessories into the cigarette lighter. Use the power point.
  • Page 68 Controls and features To install the shade: 1. Fasten the cover into the mounting brackets (make sure the cover is right side up). 2. Pull the end of the shade toward you and hook the sides into the notches (right side first) in the rear trim panels.
  • Page 69 If there is any potential remote keyless entry problem with your vehicle, ensure ALL key fobs (remote entry transmitters) are taken to your Ford Dealer, to aid in troubleshooting. Unlocking the doors Press this control to unlock all doors. The interior lamps will illuminate.
  • Page 70 • Take all your vehicle’s transmitters to your Ford Dealer for programming, or • Perform the programming procedure yourself...
  • Page 71 Controls and features Programming remote transmitters It is necessary to have all(maximum of four — original and/or new) of your remote transmitters available prior to beginning this procedure. To program the transmitters yourself: • Insert a key in the ignition and turn from 1 (LOCK) to 3 (ON) eight times in rapid succession (within 10 seconds) with the...
  • Page 72 THEFT go out. If the light stays on for an extended period of time or flashes rapidly, have the system serviced by your Ford Dealer. Key information Your vehicle is supplied with two coded keys. Only a coded key will start your vehicle.
  • Page 73 Check to make sure the coded key ignition key is an approved Ford coded key ignition key. If your keys are lost or stolen you will need to do the following: •...
  • Page 74 If two previously programmed coded keys are not available, you must bring your vehicle to your Ford Dealer to have the spare coded key(s) programmed. Please read and understand the entire procedure before you begin.
  • Page 75 If there is any potential perimeter anti-theft problem with your vehicle, ensure ALL key fobs (remote entry transmitters) are taken to your Ford Dealer, to aid in troubleshooting. Arming the system When armed, this system will help protect your vehicle from unauthorized entry.

  • Page 76: Seating And Safety Restraints

    Seating and safety restraints SEATING Do not adjust the seats while the vehicle is moving. It is extremely dangerous to ride in a cargo area inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.
  • Page 77 Seating and safety restraints Seatback angle adjustment Pull lever up to adjust seatback. Lower seat cushion height adjustment (where fitted) Rotate control to raise or lower seat cushion.
  • Page 78 Seating and safety restraints Using the manual lumbar support (where fitted) The lumbar support control is located on the outboard side of the driver’s seat. The lumbar support is equipped with four levels of support. These can be cycled through by pulling the lumbar support lever up.
  • Page 79 Seating and safety restraints Folding down rear seats 1. Raise the rear seat head restraint and remove. 2. Pull the seat release control.
  • Page 80 Seating and safety restraints 3. Flip seat forward. NOTE:Make sure the floor is clear of all objects before folding the seat. 4. Place the head restraint in the holder. 5. Pull the seatback release strap toward the front seat. Make sure the seat belt buckle heads are fully extended towards the front of the vehicle and are away from the...
  • Page 81 Seating and safety restraints 6. Rotate seatback down into load floor position. Make sure seat belt buckle heads are not trapped underneath the seatback and that the seat belt buckle heads are fully extended towards the front of the vehicle. Seat belt buckle heads may break if they are trapped underneath the seatback as the seatback is rotated down.
  • Page 82 Seating and safety restraints 2. Remove the head restraint from the holder and return it to the original position on the seat back. 3. Rotate seat cushion back into the seating position making sure that the seat cushion is locked into place and that the seat belt buckles are exposed.
  • Page 83 Seating and safety restraints To remove the rear cushion 1. Pull the Yellow tab 2. Pull the cushion to the outboard side of the vehicle.
  • Page 84 Seating and safety restraints To install the rear cushion 1. Push the cushion to the inboard side of the vehicle. 2. Make sure that the hinges are locked into place. SEAT BELTS WARNING ! Seat belts are designed to bear upon the bony structure of the body, and should be worn low across the front of the pelvis or the pelvis, chest and shoulders, as applicable;...
  • Page 85 Adjust the driver’s seat to position before fastening the seat belt. Seat belts should be checked by an Authorized Ford Dealer or recognized repairer after an accident has occurred. It may be necessary to replace the belt.
  • Page 86 The belt pretensioner is not triggered in the event of a minor frontal, side or rear collision. The buckle pretensioners must only be removed or disposed by specially trained personnel. See your Ford Dealer if a belt pretensioner requires repair or replacement.
  • Page 87 Seating and safety restraints Combination lap and shoulder belts (where fitted) 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.
  • Page 88 Seating and safety restraints The automatic locking mode is available on the rear outboard passenger seat belts. When to use the automatic locking mode • Anytime a child safety seat is installed in an outboard rear seating position. Refer to Child Restraints later in this chapter. How to use the automatic locking mode •...
  • Page 89 Seating and safety restraints How to disengage the automatic locking mode Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode. After any vehicle collision, the rear passenger outboard seat belt systems must be checked by a qualified technician to verify that the “automatic locking retractor”...
  • Page 90 Seating and safety restraints Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle.
  • Page 91 This information will assist Ford in the servicing of your vehicle and may help Ford better understand real world collisions and further improve the safety of future vehicles.
  • Page 92 Seating and safety restraints The air bag may deploy with the ignition switch in any position, even if the ignition key is removed. Frontal air bag system operation Sensors in the vehicle detect the degree of severity of a frontal impact.
  • Page 93 Seating and safety restraints Side air bag system operation (where fitted) Do not block, obstruct or cover the side air bag (where fitted) because it may prevent proper deployment of the air bag and increase your risk of injury. For example, do not lean your head on the door or hang a coat or jacket over the seatback Do not use accessory seat covers.
  • Page 94 Seating and safety restraints The side air bags are fitted on the outboard side of the seatbacks of the front seats. In certain lateral collisions, the air bag on the side affected by the collision will be inflated, even if the respective seat is not occupied.
  • Page 95 Seating and safety restraints The importance of wearing seat belts Seat belts must be worn by all vehicle occupants to be properly restrained and help reduce the risk of injury in a collision. Wearing a seat belt will: • help keep you in the proper position when the air bags inflate, •...
  • Page 96 Seating and safety restraints NEVER install any child restraint (e.g. baby capsule child seat or booster seat) in the front seat where a passenger air bag is fitted, as serious injury or death may result from the force of the inflating front passenger air bag.
  • Page 97 Do not attempt to service, repair or modify the air bag system; tampering could cause activation of the system and increase the risk of personal injury. For servicing of the air bag system, see your Authorized Ford Dealer. Do not use chemical solvents or strong detergents when cleaning steering wheel, instrument panel or front seat covers to avoid contamination of the air bag system.
  • Page 98 Seating and safety restraints Only fit a “bull bar” to your vehicle which is compatible with the Air Bag Supplemental Restraint System in your vehicle. “Bull bars” which are not compatible with the Air Bag Supplemental Restraint System in your vehicle may cause your air bag to malfunction which could result in damage to your vehicle and injury to yourself or others and may void the vehicle’s compliance to Australian Design Rules and New Zealand Land Transport Rules.
  • Page 99 Seating and safety restraints CHILD RESTRAINTS Infants and small children should be restrained at all times in an approved child restraint suited to your vehicle and which conforms to AS1754–1991, or NZS5411 / BS3254 / BSAU185 / BSAU202 for New Zealand.
  • Page 100 Seating and safety restraints 2. Insert the belt tongue into proper the proper buckle (the buckle closest to the direction from which the tongue is coming) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
  • Page 101 Seating and safety restraints 6. Then attach the child restraint attachment clip to the anchor fitting with reference to the following information. Child restraint fittings Three factory installed child restraint anchor fittings are provided on the headliner at the rear of the vehicle. Illustrations of the restraint attachment clip and anchor fitting are only applicable to child restraint...
  • Page 102 Seating and safety restraints Anchorage locations The three anchor fittings are provided on the headliner at the rear of the vehicle as shown. The components supplied with child restraints conforming to AS1754–1991 must be selected to suit the anchorage points in the vehicle.

  • Page 103: Starting

    Starting PREPARING TO START YOUR VEHICLE Engine starting is controlled by the spark ignition system. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting. Only use the accelerator when you have difficulty starting the engine. For more information on starting the vehicle, refer to Starting the engine in this chapter.
  • Page 104 Starting • Make sure the parking brake is set. • Make sure the gearshift is in P (Park). 3. Turn the key to 3 (ON) without turning the key to 4 (START). If there is difficulty in turning the key, firmly rotate the steering wheel left and right until the key turns freely.
  • Page 105 Starting Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced. • If the driver’s safety belt is fastened, the light may not illuminate. STARTING THE ENGINE NOTE: Whenever you start your vehicle, release the key as soon as the engine starts.

  • Page 106: Driving

    If a “metal-to-metal,” “continuous grinding” or “continuous squeal” sound is present while braking, the brake linings may be worn-out and should be inspected by a Ford Dealer. If you notice a reduction in brake effectiveness or an increase in stopping distances, have the braking system checked immediately.
  • Page 107 Driving The ABS operates by detecting the onset of wheel lockup during brake applications and compensates for this tendency. The wheels are prevented from locking even when the brakes are firmly applied. The accompanying illustration depicts the advantage of an ABS equipped vehicle (on bottom) to a non-ABS equipped vehicle (on top) during hard braking with loss of front braking traction.
  • Page 108 Driving There are two important rules when braking in emergencies with ABS: 1. Apply full force on the brake pedal. 2. Steer around the obstacle. No matter how hard you brake, steering control is maintained. Although the anti-lock braking system ensures optimum braking efficiency, stopping distances can vary greatly, depending on the road surface and conditions.
  • Page 109 If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your Ford Dealer. STEERING Your vehicle is equipped with power steering. Power steering uses energy from the engine to help steer the vehicle.
  • Page 110 Driving PREPARING TO DRIVE YOUR VEHICLE Your vehicle has special design and equipment features to make it capable of performing in a wide variety of circumstances. These special design features, such as larger tires and increased ground clearance, give the vehicle a higher center of gravity than a passenger car. Vehicles with a higher center of gravity such as four-wheel drive vehicles handle differently than vehicles with a lower center of gravity.
  • Page 111 If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your Ford Dealer. Driving with an automatic overdrive transaxle Your automatic transaxle electronically controls the shift feel by using an adaptive learning strategy.
  • Page 112 Driving P (Park) Always come to a complete stop before shifting into P (Park). Make sure the gearshift lever is securely latched in P (Park). This locks the transaxle and prevents the front wheels from rotating. Do not use the P (Park) position in place of the park brake.
  • Page 113 O/D OFF control is pressed, there may be a transaxle electronic system malfunction. You should contact your Ford Dealer as soon as possible or damage to the transaxle could occur.
  • Page 114 Driving To return the transaxle to the normal Overdrive operation, press the O/D OFF control again. Use this control to select between Overdrive or D (O/D OFF) whenever you drive your vehicle. 2 (Second) Use 2 (Second) for start-up on slippery roads or to give you more engine braking to slow your vehicle on downgrades.
  • Page 115 Driving you to drive your vehicle over terrain and road conditions not normally travelled by two-wheel drive vehicles. Power is always supplied to the front wheels and to the rear wheels through the transaxle and Rotary Blade Coupling (RBC) unit that allows you to select a four-wheel drive mode best suited for your current driving conditions.
  • Page 116 4x4 LOCK mode is engaged. If the indicator light illuminates when driving in the 4x4 LOCK deactivated mode, contact your Ford dealer as soon as possible. DRIVING OFF ROAD Introduction The steering and handling characteristics of vehicles may vary and you must learn and understand the capabilities and limitations of your 4WD through experience.
  • Page 117 Driving How your vehicle differs from other vehicles 4WD vehicles can differ from some other vehicles in a few noticeable ways. Your 4WD may be: • Higher – to allow it to travel over rough terrain without getting hung up or damaging underbody components, and to accommodate 4WD components.
  • Page 118 Driving If your vehicle goes off the edge of the sealed road • If your vehicle goes off the edge of the sealed road surface, slow down, but avoid severe brake application. Ease the vehicle back onto the sealed road only after reducing your speed.
  • Page 119 After driving through mud, clean off residue stuck to rotating driveshafts and tires. Excess mud stuck on tires and rotating driveshafts causes an imbalance that could damage vehicle components. Ford encourages you to help preserve our national forest and other public and private lands by “treading lightly”.
  • Page 120 Driving Water Before driving through water, determine the depth. Avoid water higher than the bottom of the wheel hubs. Proceed slowly to avoid splashing. If the ignition system gets wet, the vehicle may stall. Once through water, always try the brakes.
  • Page 121 Driving Deep snow When driving through deep snow, shift to a low gear and maintain steady pressure on the accelerator. This will help prevent spinning the wheels while maintaining sufficient momentum to keep from bogging down. Using tire chains will also help. Never drive with chains on the front tires of 4WD vehicles without also putting them on the rear tires.
  • Page 122 Any modifications to a vehicle that raise the center of gravity can increase the likelyhood of a roll over. Ford recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).
  • Page 123 TRAILER TOWING Your vehicle is designed primarily as a passenger vehicle but it may be used to tow a trailer when a Ford approved towing package is fitted, without limiting your rights under the Ford Vehicle Warranty, provided you comply with all of the instructions in this section.
  • Page 124 Driving Load limits Permissible Towing Weight (kg) 4cyl Braked Trailer 1000 kg 1600 kg Unbraked Trailer 750 kg 750 kg General equipment advice • Load the trailer so that the weight on the towball is 10% of the towed weight to avoid overloading the vehicle and detracting from its handling.
  • Page 125 Driving Gear changing To prevent the engine laboring when climbing hills or driving in strong headwinds, etc. and assist braking when driving down a hill, select a suitable lower gear. Refer to the Transmission operation section in this chapter. Overtaking The ability of the vehicle to accelerate when overtaking is reduced, therefore allow greater distances.
  • Page 126 Driving Exceeding these limits may allow water to enter critical vehicle components, adversely affecting driveability, emissions, reliability and causing internal transmission damage. Check and/or replace the rear axle lubricant if: • a leak is suspected or repair required • the axle has been submerged in water Disconnect the wiring to the trailer before backing the trailer into the water.
  • Page 127 Driving To remove the cross-bar assembly from the roof rack side rails: 1. Loosen the thumbwheel at both ends of the cross-bar (both cross-bars are adjustable). 2. Slide the cross-bar to the end of the rail. 3. Use a long, flat object in order to depress the tongue in the endcaps on both sides of the cross-bar.
  • Page 128 Driving To reinstall the cross-bar assembly to the roof rack side rails: 1. Ensure that both cross-bar assemblies are installed with the F (front) arrow facing towards the front of the vehicle. 2. Use a long, flat object to depress the tongue in the endcaps on both sides of the cross-bar.

  • Page 129: Roadside Emergencies

    Roadside emergencies HAZARD FLASHER CONTROL Use only in an emergency to warn traffic of vehicle breakdown, approaching danger, etc. The hazard flashers can be operated when the ignition is off. • The hazard lights control is located on the instrument panel above the radio.
  • Page 130 Always disconnect the battery before servicing high current fuses. Ford recommends that high current fuses be replaced by a qualified technician. Always replace a faulty fuse with a new one of the same rating.
  • Page 131 Roadside emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse Link Maxi Rating Fuses Fuses Fuses Cartridge Fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
  • Page 132 Roadside emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Canister Vent Control Solenoid Blower Relay (coil), Rear Defrost Relay (coil), Pressure Switch to Rear Wiper Motor, Rear Washer Motor, Rear Wiper Relay (coil) Four Wheel Drive Control Module, Cluster (Restraints Control Warning)
  • Page 133 Roadside emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Flasher Unit, Left reversing Lamp, Right Reversing Lamp Passive Anti-theft Transceiver (PATS), Restraints Control Module Cluster, Shift Lock Relay (coil), O/D signal to PCM PCM Relay (coil), Fan Relay 1, 2, 3 (coil), A/C Relay (coil) Front Wiper Motor, Front Washer Motor, INT Relay...
  • Page 134 Roadside emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Left/Right Turn Indicators, Left/Right Front Side Turn Lamps, Left/Right Front turn Lamps, Left/Right Rear Turn Lamps, Left/Right Trailer Turn, Flasher Unit Left /Right Trailer Position Lamps Not Used Left/Right Horn Left/Right Stoplamps, Hight Mounted Stoplamp, Left/Right...
  • Page 135 Roadside emergencies Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses. Always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs.
  • Page 136 Roadside emergencies The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description Horn Horn H/L LH 15A* Headlamp (High/Low Left, High Beams) H/L RH 15A* Headlamp (High/Low Right, High Beams) EEC (KPWR) HEGO 15A* HEGO 1,2, CMS 1,2, VMV...
  • Page 137 Roadside emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description FUEL 20A* Fuel Pump, EEC (FPM) DIODE — — DIODE — — H/L RELAY — Headlamp (High/Low, Right/Left MICRO Relay) — — — 30A** EEC (VPWR), EVR, MAF, IAC, Bulkhead MAIN 120A...
  • Page 138 Roadside emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description EEC MAIN ISO — EEC Relay FUEL PUMP ISO — Fuel Pump Relay MAIN FAN ISO — Low Speed Fan Control Relay (2.0L Engine) High Speed Fan Control Relay 1 (3.0L Engine) ADD FAN ISO —...
  • Page 139 Roadside emergencies It is recommended that the wheels of the vehicle be chocked and that no person should remain in a vehicle that is being jacked. No person should place any part of their body under a vehicle that is supported only by a jack;...
  • Page 140 Roadside emergencies though the opposite wheel is raised. Do not start the engine of a vehicle which is mounted on a jack. 1. Park on a level surface, activate hazard flashers and place gearshift lever in P (Park). 2. Set the parking brake and turn engine OFF.
  • Page 141 Roadside emergencies 5. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. Before placing the jack under the vehicle, NOTE the jack locations: Do not jack a vehicle with a trailer or caravan attached. Disconnect the trailer or caravan and make sure it is supported before jacking the vehicle.
  • Page 142 Roadside emergencies 6. Turn the jack handle clockwise until the tire is completely off the ground. Never use the differentials as a jacking point. To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire.
  • Page 143 Roadside emergencies BOOSTER STARTING Jump starting could be dangerous if done incorrectly. Therefore, if the following conditions cannot be met, or if you are uncertain about them, we strongly recommend that you leave the starting to a competent mechanic or towing service.
  • Page 144 Roadside emergencies Booster lead connecting procedure Remove the filler vent caps from both batteries and place a damp cloth over the batteries. if the booster battery is installed in another vehicle, do not allow the two vehicles to touch. Turn off all other unnecessary electrical loads. Firmly apply the park brake on both vehicles and select P (Park).
  • Page 145 Roadside emergencies Connect the other end of the same black lead to the engine lifting eye of the vehicle with the discharged battery. Do not connect the lead to the negative terminal of the discharged battery. Take care that the jumper clamps do not touch each other or any metal on either vehicle, and are clear of the cooling fans and drive belt.
  • Page 146 Roadside emergencies 4. Switch the heater fan of the vehicle with the discharged battery to the fastest position to “load” the vehicle’s electrical system prior to disconnecting the jumper leads. 5. Disconnect the leads in the reverse order. Do not disconnect or change over the discharged battery while the engine is running as damage to the electrical system may occur.
  • Page 147 It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure.

  • Page 148: Maintenance And Care

    Therefore, if you ever smell exhaust fumes of any kind inside your vehicle do not remain in the vehicle with the windows closed and report the condition to your Authorised Ford Dealer immediately and have the condition corrected.
  • Page 149 Maintenance and care High voltage Engines with an electronic ignition system can generate very high voltages. Care should be taken when servicing to avoid contact with conductive parts to avoid severe electrical shock. These systems can produce dangerous high tension voltages in the primary and secondary circuit.
  • Page 150 INSTALLATION OF AUXILIARY EQUIPMENT To avoid any damage to the vehicle, check with an Authorised Ford Dealer to ensure correct installation of auxiliary equipment. Fitment of some non-Ford/Motorcraft accessories (such as alarms and other electronically controlled devices) may affect normal vehicle operation due to electromagnetic interference emitted by these accessories.
  • Page 151 Maintenance and care The fluid reservoirs for engine coolant, brake and windscreen washer fluids are translucent to allow rapid visual checks. For easy identification, all the filler caps and the engine oil and automatic transmission fluid dipsticks are marked yellow. Keep oils, greases and vehicle fluids (including used engine oil) away from the skin and eyes.
  • Page 152 Maintenance and care 2. At the front of the vehicle, lift up on the auxiliary latch handle located in the center between the hood and the grille. 3. L ift the hood open and secure it with the prop rod. IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 2.3L DOHC 4 cylinder engine...
  • Page 153 Maintenance and care IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 3.0L DOHC V6 Duratec engine 1. Power steering fluid reservoir 2. Engine coolant reservoir 3. Brake fluid reservoir 4. Automatic transmission fluid dipstick 5. Air filter assembly 6. Power distribution box 7.
  • Page 154 Maintenance and care ENGINE OIL Checking the engine oil Refer to the Service Guide for the appropriate intervals for checking the engine oil. 1. Make sure the vehicle is on level ground. 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan.
  • Page 155 Maintenance and care • Oil levels above the MAX mark may cause engine damage. Some oil must be removed from the engine by a service technician. 7. Put the indicator back in and ensure it is fully seated. Adding engine oil 1.
  • Page 156 If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced. It is recommended you use the appropriate Ford oil filter (or another brand meeting Ford specifications) for your engine application. BRAKE FLUID...
  • Page 157 Refer to the Service Guide for the appropriate intervals for changing the air filter element. When changing the air filter element, use only a genuine Ford or Motorcraft air filter element. Do not start your engine with the air cleaner removed and do...
  • Page 158 Maintenance and care Changing the air filter element 1. Loosen the clamp that secures the air inlet tube to the engine air filter cover and disconnect the tube from the cover. 2. Release the clamps that secure the air filter housing cover. 3.
  • Page 159 Modern engine run at very high temperatures. Inferior quality coolants are ineffectual in maintaining adequate corrosion protection to the cooling system. For this reason, only use coolant which meets the Ford specification for your vehicle. • DO NOT USE Ford Extended Life Engine Coolant (orange in colour) •...
  • Page 160 Refer to the Service Guide for the service interval schedules. If adding fluid is necessary, use only fluid that meets the Ford specification DEXRON II. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C).
  • Page 161 Maintenance and care TRANSMISSION FLUID Checking automatic transmission fluid Refer to your Service Guide for scheduled intervals for fluid checks and changes. Your transaxle does not consume fluid. However, the fluid level should be checked if the transaxle is not working properly, i.e., if the transaxle slips or shifts slowly or if you notice some sign of fluid leakage.
  • Page 162 Maintenance and care The transmission fluid should be in the crosshatch zone. High fluid level Fluid levels above the crosshatch zone may result in transaxle failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. High fluid levels can be caused by an overheating condition.
  • Page 163 Maintenance and care BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the scheduled maintenance guide for the service interval schedules.
  • Page 164 Maintenance and care When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
  • Page 165 Maintenance and care • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal. Call your local authorized recycling center to find out more about recycling automotive batteries. RECYCLE CHECKING WIPER BLADES Check the wiper blades on your vehicle for roughness by running the tip of your fingers over the edge of the blade.
  • Page 166 Maintenance and care Renewing wiper blades It is recommended that wiper blades are renewed before winter. To replace the wiper blades: 1. Fold back the wiper arm and position the wiper blade at right angles to the wiper arm. 2. To remove, press the retaining clip (A) to disengage the wiper blade, then pull the blade down toward the windshield to remove it...
  • Page 167 Failure to follow tire pressure recommendations can adversely affect the way your vehicle handles. Do not exceed the Ford recommended pressure even if it is less than the maximum pressure allowed for the tire.
  • Page 168 Authorized Ford Dealer. If you nevertheless decide to equip your 4WD for off-road use with tires larger than what Ford recommends, you should not use these tires for highway driving. If you use any tire/wheel combination not recommended by Ford, it may adversely affect vehicle handling and could cause steering, suspension, axle or transfer case failure.
  • Page 169 (even if only a small amount of leaded fuel was added). The lead content of the fuel will cause permanent damage to the catalytic converter. Contact your nearest Authorised Ford Dealer immediately for advice. Turn the ignition off. Open the fuel door and slowly unscrew the petrol cap anti-clockwise.
  • Page 170 “Check Engine” indicator, refer to the Instrumentation chapter. Fuel Filter For fuel filter replacement, see your Ford Dealer. Refer to the Service Guide for the appropriate intervals for changing the fuel filter. Replace the fuel filter with an authorized Motorcraft part.
  • Page 171 Maintenance and care • observe the running-in advice provided at the beginning of this manual • when your vehicle is run in, drive at steady speeds where possible and avoid jiggling the accelerator • warming the engine is not necessary •...
  • Page 172 Maintenance and care Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Illumination of the indicator, charging system warning light or the temperature warning light, fluid leaks, strange odors, smoke or loss of engine power, could indicate that the emission control system is not working properly.
  • Page 173 Maintenance and care 3. Press two tabs and disconnect the electrical connector from the bulb. 4. Remove the rubber boot from the lamp assembly by pulling on one of the tabs. 5. Press the retainer spring forward and spread the spring releasing it from bulb hooks and rotate it away from the bulb.
  • Page 174 Maintenance and care 6. Without turning, carefully pull bulb out of headlamp assembly. Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its metal base and do not touch the glass. The oil from your hand could cause the bulb to break the next time the headlamps are operated.
  • Page 175 Maintenance and care 1. Open the liftgate to expose the lamp assemblies. 2. Remove the two screws from the lamp assembly. 3. Carefully remove the lamp assembly by pulling it rearward to disengage snap features on the outward side of the lamp. 4.
  • Page 176 To complete installation, follow the removal procedure in reverse order. Replacing front parking lamp/turn signal bulbs For bulb replacement, see your Ford dealer. Replacing foglamp bulbs For bulb replacement, see your Ford dealer. Replacing the interior bulbs Check the operation of the following interior bulbs frequently: •...
  • Page 177 The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident the alignment of your headlamps should be checked by your authorized Ford dealer. CLEANING AND CARING FOR YOUR VEHICLE Washing your vehicle...
  • Page 178 Maintenance and care washing when the hood is still warm, immediately after or during exposure to strong sunlight. NOTE: Any petrol spilled on the vehicle or deposits such as bird droppings should be washed and sponged off as soon as possible. Deposits not removed promptly can cause damage to the vehicle’s paintwork.
  • Page 179 Maintenance and care • Never apply anything to the drive belt (including belt dressing). • Cover the highlighted areas to prevent water damage when cleaning the engine. • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage.
  • Page 180 Maintenance and care Cleaning the windshield, wiper blades and rear window If the wiper blades do not wipe properly, clean the wiper blade rubber element with undiluted windshield washer solution or a mild detergent. To avoid damaging the blades, do not use fuel, kerosene, paint thinner or other solvents.
  • Page 181 Maintenance and care Inside windows Use glass cleaner for the inside windows if they become fogged. Cleaning mirrors Do not clean your mirrors with a dry cloth or abrasive materials. Use a soft cloth and mild detergent and water. Be careful when removing ice from outside mirrors because you may damage the reflective surface.

  • Page 182: Capacities And Specifications

    Capacities and specifications VEHICLE DIMENSIONS Dimensions 4 Door mm (in.) (1) Overall height 1 775 (69.9) (2) Front track / rear 1 550 (61.0)/1 530 (60.2) (3)Overall width 1 825 (71.8) (4) Wheelbase 2 620 (103.1) (5)Overall length 4 415 (173.8)
  • Page 183 Capacities and specifications...
  • Page 184 Capacities and specifications IDENTIFYING YOUR VEHICLE Vehicle identification number The vehicle identification number is attached to a metal tag and is located in the engine bay. Tire decal The tire decal is located on the driver’s door. The tire pressures should be checked regularly, when the tires are cold (including the spare wheel).

  • Page 186: Index

    Index Brakes .........105 anti-lock....97-99, 105-107 Air bag supplement restraint anti-lock brake system (ABS) system ...........90 warning light......10 indicator light ......9, brake warning light ....10 fluid, checking and adding..155 Air cleaner filter ....156-157 parking ........107 Air conditioning......shift interlock......109 Antifreeze Break-in period.......2 (see Engine coolant) ....
  • Page 187 Index Coolant checking and adding ....158 disposal ........159 Foglamps........63 Four-Wheel Drive Cruise control description ......18,113 (see Speed control) ....54 driving off road......115 indicator light ....12, 115 Fuel ..........167 Defrost choosing the right fuel . . . 159, 167 rear window.......18 fuel injection shut-off switch..128 Dipstick gauge..........14...
  • Page 188 Index high beam ......11, 62 Lane change indicator replacing bulbs ......171 (see Turn signal).......53 turning on and off .....62 Liftgate..........67 warning chime......13 Lights, warning and indicator ..8 Heating..........19 air bag ..........9 heating and air conditioning anti-lock brakes (ABS) ..10, 105 system........18 anti-theft........11 Hood..........149...
  • Page 189 Index Seat belts (see Safety restraints)....83 Octane rating ......167 Seats ..........75 Odometer ........15 SecuriLock passive anti-theft Oil (see Engine oil) ....153 system..........71 Overdrive ........110 Special notice .........3 utility-type vehicles.....3 Speed control .......54 Parking brake ......107 Speedometer ........14 Power distribution box (also see Fuses)......134 Starting your vehicle ....104 jump starting ......142...
  • Page 190 Index Windows power .........63 Vehicle dimensions ....181 rear wiper/washer .....59 Vehicle Identification Number Windshield washer fluid (VIN)...........183 and wipers checking and adding fluid..156 checking and cleaning ....164 Warning chimes.......12-13 liftgate reservoir......156 operation ........57 Warning lights (see Lights)..156 replacing wiper blades ....165 Washer fluid........148 Wrecker towing ......146...
  • Page 192 Change of Ownership or Address...
  • Page 194 Change of Ownership or Address...
  • Page 196 Change of Ownership or Address...
  • Page 198 Change of Ownership or Address...
  • Page 200 Change of Ownership or Address...
  • Page 202 Produced by FORD MOTOR COMPANY OF AUSTRALIA LIMITED ABN 30 004 116 223 Registered Office: 1735 Sydney Road, Campbellfield, Victoria 3061 PART NO. ZB ESCAPE OM www.ford.com.au...

Table of Contents
