Figure 12: Mounting in AL400 Enclosure with Mounting Plate
Callout
Description
1
TP-ADD-2D
2
28058B-02 mounting plate
3
TP-ADD (AL400) enclosure
4
#6-32 SEMS nut, 8 holes
5
#6-32 x .38 in. (9.652 mm), 4 holes
8
Figure 13: Mounting in AL600 Enclosure with Mounting Plate
Callout
Description
1
TP-ADD-2D
2
28058B-02 mounting plate
3
TP-ADD (AL600) enclosure
4
#6-32 SEMS nut, 8 holes
5
#6-32 x .38 in. (9.652 mm), 4 holes
TruPortal Dual Door Interface Module Quick Reference
