DEClaser 3500 Printer
Internal Fax Modem
Installation Guide
EK-D350P-IG.A01
Digital Equipment Corporation
Maynard, Massachusetts
Part Number 194683-001 - 08/12/94 - - Saved by digital - -
Rev # - File Name FAXMODM2.DOC

Advertisement

Table of Contents
loading

Summary of Contents for Digital Equipment DEClaser 3500

  • Page 1 ..... . . DEClaser 3500 Printer Internal Fax Modem Installation Guide EK-D350P-IG.A01 Digital Equipment Corporation Maynard, Massachusetts Part Number 194683-001 - 08/12/94 - - Saved by digital - -...
  • Page 2 ..... . . First Printing, June 1994 Digital Equipment Corporation makes no representations that the use of its products in the manner described in this publication will not infringe on existing or future...
  • Page 3: Federal Communications Commission Notice

    ..... . . FEDERAL COMMUNICATIONS COMMISSION NOTICE Class B Equipment FCC ID: A09-LN14X-FX This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause...
  • Page 4 Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Digital Equipment Corporation may void the user's authority to operate the equipment. Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods in order to maintain compliance with FCC Rules and Regulations.
  • Page 5 ..... . . If your telephone equipment causes harm to the telephone network, the telephone company may discontinue your service temporarily. If possible, they will notify you in advance.
  • Page 6 ..... . . CANADIAN REGULATIONS GOVERNING THE USE OF FACSIMILE DEVICES The Canadian Department of Communications label NOTE: identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operations, and safety requirements.
  • Page 7: Electrostatic Discharge

    ..... . . ELECTROSTATIC DISCHARGE A discharge of static electricity from a finger or other conductor may damage circuit boards or other static-sensitive devices. This type of damage may reduce the life expectancy of the device.
  • Page 8: Kit Contents

    ..... . . KIT CONTENTS One Fax Modem board Screws Telephone cord with modular connection [RJ11 (USA) or CA11 (Canada)] Fax software and documentation ITEMS NEEDED FOR INSTALLATION Internal Fax Modem Option Kit...
  • Page 9 ..... . . Turn the printer off and unplug the AC WARNING: power cord before attempting to remove the system controller board.
  • Page 10 ..... . . STEP 2 DISCONNECT ALL CABLES FROM THE PRINTER. STEP 3 PRESS DOWN ON THE TABS TO OPEN AND LOWER THE REAR COVER.
  • Page 11 ..... . . STEP 4 LOOSEN THE SCREWS AND REMOVE THE SYSTEM CONTROLLER BOARD. 1 Thumbscrews 2 System Controller Board 3 Rear Cover STEP 5 REMOVE THE BLANK PLATE COVERING AN...
  • Page 12 ..... . . STEP 6 PLUG THE MODEM INTERFACE CONNECTOR INTO LOCATION J7 OR J9 AND SECURE. Be sure that the screws are inserted through the insulator cover when securing the modem to the mounting posts.
  • Page 13 ..... . . STEP 7 REINSTALL AND SECURE THE CONTROLLER BOARD AND CLOSE THE REAR COVER. 1 Thumbscrews 2 System Controller Board 3 Rear Cover STEP 8 RECONNECT ALL CABLES.
  • Page 14 ..... . . STEP 9 CONNECT THE TELEPHONE CORD FROM A WALL JACK TO THE "LINE" JACK ON THE MODEM. WARNING: Always disconnect the Internal Fax Modem from the telephone system when installing...
  • Page 15 ..... . . STEP 11 PLUG IN AND TURN ON (O) THE PRINTER. STEP 12 PRINT A HARDWARE REPORT. Using the printer control panel: 1.
  • Page 16: Troubleshooting

    ..... . . TROUBLESHOOTING If the option you just installed is not listed on the Hardware Report, you should: 1. Make sure that the Fax Modem is properly attached and firmly secured to the J7 or J9 connector.
