Panneaux et ensembles de douche
FR
à fermeture automatique temporisée
Shower panels and shower kits
EN
with automatic, time flow shut-off
Duschelemente
DE
und Duschkombinationen
mit automatischer Abschaltung
Purger soigneusement les canalisations
FR
avant la pose et la mise en service du produit.
Thoroughly flush the pipes to remove any impurities
EN
before installing and commissioning the product.
Vor Montage und Inbetriebnahme des Produkts
DE
die Anschlussleitungen regelkonform spülen.
Dokładnie wypłukać instalację przed
PL
montażem i uruchomieniem produktu.
Spoel zorgvuldig de leidingen alvorens
NL
tot installatie of ingebruikname van de kraan over te gaan.
Перед установкой и подключением устройства тщательно
RU
промыть канализационные трубы напором воды.
SPORTING
Panele i zestawy natryskowe
PL
z automatycznym zamknięciem czasowym
Douchepanelen en douchecombinaties
NL
met automatische zelfsluiting
Панели и душевые комплекты
RU
с автоматическим порционным
закрытием
NT 714S2
Indice C
Advertisement
Table of Contents
Related Manuals for Delabie Delabie Sporting 714700
Summary of Contents for Delabie Delabie Sporting 714700
- Page 1 NT 714S2 SPORTING Indice C Panneaux et ensembles de douche Panele i zestawy natryskowe à fermeture automatique temporisée z automatycznym zamknięciem czasowym Shower panels and shower kits Douchepanelen en douchecombinaties with automatic, time flow shut-off met automatische zelfsluiting Duschelemente Панели и душевые комплекты und Duschkombinationen с...
- Page 2 180° 0-9 mm...
- Page 4 OPERATION • Press the push-button starter 1 (Fig. A, B, G, H & J) to open the valve. • Automatic shut-off after ~30 seconds (+5/-10 according to the European standard EN 816). INSTALLATION • In order to capture all of the spray, install the shower tray 10cm from the wall: we recommend recessed shower trays or sloping gutters.
- Page 5 • THE INTEGRITY OF THE SEALS BETWEEN THE STAINLESS STEEL WALL PLATE AND THE WALL OR THE WALL PLATE AND THE TAP AT LEAST ONCE A YEAR, AND MAKE GOOD IF NECESSARY. If this advice is not followed, water may leak into the wall. DELABIE cannot be held responsible for any ingress.
- Page 6 • Sizing the pipes correctly will avoid problems of flow rate, pressure loss and water hammer (see calculation table in our brochure and online at www.delabie.com). • Protect the installation with filters, water hammer absorbers and pressure reducers to reduce the frequency of maintenance (recommended pressure from 1 to 5 bar maximum).
- Page 7 Dirt or abrasions on the O-rings on the shower head mechanism (Fig. A, B, C, M, N & P): • Using the tool 31, unscrew the ring 3 and remove the cover 7 (Fig. A & C or B & C). •...
