FM Modulator Playback
side monitor and pressing the FREQUENCY SELECT button. Each press of the
button advances the frequency as follows:
FM CH1 87.9MHz FM CH2 88.3MHz FM CH3 88.7MHz FM CH4
89.1MHz FM CH5 89.5MHz FM CH6 89.9MHz FM CH7 90.3MHz
To turn the FM Modulator Off aim the remote at the driver's side monitor and
simply press the FM ON / OFF button again.
NOTE: All of the FM modulator control functions can also be controlled in a sim-
ilar fashion using the buttons on the front of the monitor.
IR Headphones
The Vizualogic A-1000 System features integrated Infrared (IR) transmitters on
the front of each monitor. The driver's side monitor transmits on channel 'A' and
the passenger side transmits on channel 'B'. To listen to the source displayed on
monitor, turn on the headphones and select the corresponding audio channel
for the monitor being viewed. NOTE: Always adjust volume control on the
headphones to the lowest setting before turning them on.
14
(continued)
DVD FUNCTIONS
9. AUX DVD POWER – Press this
button to turn the(optional) external
DVD ON. Press the button again to
turn the DVD OFF.
10. AUX DVD EJECT – Ejects disc from
the (optional) external DVD
11. UP – Moves up within the DVD
SETUP menu.
12. DOWN – Moves down within the
DVD SETUP menu.
13. RIGHT – Moves right within the DVD
SETUP menu.
14. LEFT – Moves left within the DVD
SETUP menu.
15. ENTER – Confirms a selection.
16. RETURN – Return to previous menu
screen or playing point.
17. SETUP – Navigates SETUP MENU.
There are 4 pages to configure System
(1) General Setup Page.
(2) Audio Setup Page.
(3) Preference Page.
(4) Password Setup Page.
18. TITLE – Navigates the Title Menu on the disc.
19. MENU – Goes to the Root Menu on the disc.
20. AUDIO DOWN – Press this button to decrease playback volume.
15
11
9
10
14
13
16
17
18
12
19
20
7
