Warnings; Important Information - Glow-worm Ultrapower sxi Series Installation And Servicing

Turn off the gas emergency control valve immediately. Eliminate all sources of ignition, i.e.smoking,
Do not operate electrical lights or switches either on or off. Open all doors and windows, ventilate the area.
This boiler contains metal parts (components) and care should be taken when handling and cleaning,
Under no circumstances must the User interfere with or adjust sealed parts.
Gas Category
This boiler is for use only on G20 natural gas.
Gas Safety (Installation and Use) Regulations
In your own interests and that of safety, it is the Law that
ALL gas appliances are installed by a competent person in
accordance with the current issue of the above regulations.
Control of Substances Hazardous to Health
Under Section 6 of The Health and Safety at Work Act
1974, we are required to provide information on substances
hazardous to health.
The adhesives and sealants used in this appliance are cured
and give no known hazard in this state.
Insulation Pads / Ceramic Fibre
These can cause irritation to skin, eyes and the respiratory
tract.
If you have a history of skin complaint you may be
susceptible to irritation. High dust levels are usual only if the
material is broken.
Normal handling should not cause discomfort, but follow
normal good hygiene and wash your hands before eating,
drinking or going to the lavatory.
If you do suffer irritation to the eyes or severe irritation to the
skin seek medical attention.
Manual Handling
With regards to the "Manual Handling Operations, 1992
Regulations", it should be noted that each appliance module
exceeds the recommended weight for a one man lift.
Electrical Supply
The electrical installation must be installed by a
person and in accordance with the relevant standards.
The boiler and immersion heater must be earthed.
All system components shall be of an approved type and all
wiring to current I.E.E. wiring regulations.
External wiring must be correctly earthed, polarised and in
accordance with the relevant standards.
In GB this is BS 6891.
In IE this is the current edition of I.S.813 "Domestic Gas
Installations".

WARNINGS

Gas Leak or Fault
blowlamps, hot air guns etc.
Metal Parts
with particular regard to edges.
Sealed Components

Important Information

The boiler must be connected to a permanent 230V ac, 50Hz
supply.
Connection of the whole electrical system of the boiler,
including any heating controls, to the electrical supply must
be through one common isolator and must be fused 3 Amp
maximum.
Isolation should be by a double pole switched fused spur
box, with a minimum gap of 3mm for both poles. The fused
spur box should be readily accessible and preferably adjacent
to the appliance. It should be identified as to its use.
Alternatively connection can be made through an unswitched
shuttered socket and 3A fused 3-pin plug both to the current
issue of BS 1363 may be used, provided they are not used in
a room containing a bath or shower.
Wiring to the boiler must be PVC 85
less than 0.75mm
Immersion Heater - a thermostatically controlled immersion
heater with manual reset is fitted to the cylinder as a back
up for domestic hot water in the event of the boiler being
inoperable. The immersion heater MUST be wired separately
using 3kW 13amp wiring and in accordance with the relevant
standards.
Testing and Certification
This boiler is tested and certificated for safety and
performance. It is, therefore, important that no alteration is
made to the boiler, without permission, in writing, by Glow-
worm.
Any alteration not approved by Glow-worm, could invalidate
the certification, boiler warranty and may also infringe the
current issue of the statutory requirements.
competent
4
C insulated cable, not
O
(24/0.20mm).
2
