Glow-worm Ultrapower sxi Series Installation And Servicing page 24

10 Telescopic Flue - Length, Preparation and Installation
Top Outlet Horizontal Concentric Flue Packs:
A2043600
Horizontal telescopic flue pack.
SEALING
TAPE (telescopic only)
TELESCOPIC
TERMINAL ASSEMBLY
SEALING
COLLAR
0.5m
EXTENSION
2000460481
1m
EXTENSION
2000460482
2m
EXTENSION
2000460483
SECURING
COLLAR
SCREW x 2
TRIM RING
SCREW x 1
o
45 Bend
2000460485
(2off)
VERTICAL
FLUE
ADAPTOR
A2024600
24
FLUE
ELBOW
SCREW x 2
o
90 Bend
2000460484
SCREW x 4
GASKET
(fitted)
Diagram 10.2
Diagram 10.3
