Invacare® Stream
Removing posture belt
1. Remove plastic cap (5).
2. Loosen bolt (3) and associated nut (covered in figure).
3. Remove nut incl. washer.
4. Remove screw incl. posture belt, washer (2) and washer arranged behind.
Another nut is fixed between two washers (2) and (4) as a spacer so that belt mounting can rotate freely.
5. Replace posture belt (1).
Installing posture belt
1. Install parts in reverse order.
34
1608312-B
