Invacare® Stream
Component
Backrest/ manual recline/
powered recline (if fitted)
Frames (chassis) / battery
mounting
Wheel suspension and
wheels
Drive units, clutch
mechanism
Brakes
Legrests
Lighting (if fitted)
Battery mounting
Batteries
Remote / power module
16
Check
Damage to backrest
Seams
Fixing
Check cable
Check function
Check fixings, welded
seams and battery
mounting
Check drive wheels for
tight fit and side play
Check castors for tight fit,
float and side play
Tyres
Check straight running
Motors
Check functions in drive
and push modes
Check clutch mechanism
Check motor brake
Check welded seams,
interlocking, screws, foot
plates
Check cable
Check function
Check battery support and
mounting belts for damage
Check batteries for damage Replace batteries if
Check battery voltage
Check contacts and
terminals
Remote, status LED flashing Evaluate error/ flash code
Fixings
Cables and connecting
plugs
Joystick function
Power supply
Remedy
Replace parts if damaged
Tighten screws
Replace cable or motor if
necessary
Tighten screws
Replace components if
necessary
Adjust, replace wheel hubs
Replace wheels, castor
forks or wheel bearings
Repair or replace if
damaged
Replace wheels, castor
forks or wheel bearings
Test motors
Replace motor if necessary
Tighten screws/ nuts, adjust
or replace if necessary
Test motor brake
Tighten, replace if
necessary
Replace lamp or cable if
necessary
Replace if necessary
necessary
Charge batteries
Clean contacts and
terminals
Tighten fixings, replace if
necessary
Replace damaged cables
and tighten connecting
plugs, if necessary
Replace joystick knob if
necessary
Replace remote if necessary
Replace damaged cables
and tighten connecting
plugs, if necessary
Notes
See 6.7 Wheels, page 21.
See 6.7 Wheels, page
21 and 6.6.2 Replacing
Steering Head Bearings on
Castors, page 20.
See 6.7 Wheels, page 21.
See 6.7 Wheels, page 21.
See 5.1 Testing Motor,
page 11.
See 6.6 Drive Components,
page 17.
See 5.2 Testing Motor
Brake, page 11.
See 6.10 Lighting Unit,
page 32.
See 6.9 Batteries, page 31.
See user manual.
See 6.9 Batteries, page 31.
See remote user manual.
