YOKOGAWA FX1000 Drawings

Drawings
SD 04L21B01-01EN
External Dimensions
If not specified, the tolerance is ±3%.
However, in cases of less than 10mm, the tolerance is ±0.3 mm.
Mounting bracket
161.7 (6.37)
144.0 (5.67)
74.5 (2.93)
69.5
(2.74)
Panel Cutout Dimensions
Single-unit mounting
+ 2 (0.08)
137 (5.39)
0
+ 2 (0.08)
137
0
(5.39)
Side-by-side mounting
(horizontally)
+2 (0.08)
137
0
(5.39)
+ 2 (0.08)
L
0
Paperless Recorder
FX1000
If not installing the rubber packing for dust and water protection,
*1: 20.2 (0.80), *2: 163.7 (6.44), *3: 110.0 (4.33).
(*1) (*2)
22.2 (0.87) 161.7 (6.37)
108.0 (4.25)
(*3)
Panel thickness
2 to 26
( )
0.08 to 1.02
Side-by side mounting
(vertically; max. 3 units)
137 (5.39)
+ 2 (0.08)
MIN 175
L
(6.89)
MIN 175
(6.89)
(Dimensions after attaching
the mounting bracket)
(Dimensions after attaching
the mounting bracket)
+ 2 (0.08)
Units L in mm
0
(approx. inches)
2 282 (11.10)
0
3 426 (16.77)
4 570 (22.44)
5 714 (28.11)
6 858 (33.78)
7 1002 (39.45)
+ 2 (0.08)
0 8 1146 (45.12)
9 1290 (50.79)
10 1434 (56.46)
n (144 × n) – 6 [(5.67 × n) – 0.24]
Unit: mm
(approx.
inch)
