YOKOGAWA FU24 Instruction Manual

YOKOGAWA FU24 Instruction Manual

Ph/orp combination sensor with pressure ompensation
Hide thumbs Also See for FU24:
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction
Manual
IM12B06J03-03E-E_ed10.indd 1
Model FU24
pH/ORP Combination sensor
with pressure compensation
IM 12B06J03-03E-E
10th edition
8/30/2018 10:42:35

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FU24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for YOKOGAWA FU24

Summary of Contents for YOKOGAWA FU24

  • Page 1 Model FU24 Instruction pH/ORP Combination sensor Manual with pressure compensation IM 12B06J03-03E-E 10th edition IM12B06J03-03E-E_ed10.indd 1 8/30/2018 10:42:35...
  • Page 2 IM 12B06J03-03E-E IM12B06J03-03E-E_ed10.indd 2 8/30/2018 10:42:35...
  • Page 3 IM 12B06J03-03E-E IM12B06J03-03E-E_ed10.indd 3 8/30/2018 10:42:36...
  • Page 4 IM 12B06J03-03E-E IM12B06J03-03E-E_ed10.indd 4 8/30/2018 10:42:36...

  • Page 5: Table Of Contents

    3.3 Mounting the sensor 4. DIMENSIONS 5. WIRING 5.1 Connections 5.2 Definition EXA/FLXA terminal numbers to FU24 sensor 5.3 Settings for PH402G and PH202G(S) 5.4 Settings for PH150, PH450G and FLXA 6. GENERAL CALIBRATION & MAINTENANCE PROCEDURE 6.1 Calibration for pH measurement 6.2 Calibration for ORP and rH measurement...

  • Page 6: Preface

    PPS 40GF body is designed for easy installation via the 1” NPT threaded connections provided on both ends of the sensor. The FU24 sensor is available in two types: • With fixed cable, 5 and 10 metres. • With VarioPin connector:...

  • Page 7: Warranty And Service

    1.3 Warranty and Service 1.4 Serial number Yokogawa products and parts are The Serial number is defined by nine (9) guaranteed free from defects in alphanumeric characters: workmanship and material under normal X 1 X 2 Production location use and service for a period of (typically) 12...

  • Page 8: General Specifications

    : 8 ± 15 mV Slope : > 96 % (of theoretical value) Note: The temperature sensor included in the FU24 is designed for cell compensation and for indication. It is NOT designed for process temperature control. 2.4 Dynamic specifications Response time pH : t 90 <...

  • Page 9: Regulatory Standards (Only For Sensor Without Suffix -Vs)

    Ui = 18 V; Ii = 170 mA; Pi = 0.4 W; Li = 0 mH; Ci = 0 nF (VP type) or 3.6 nF (permanently connected cable) or certified intrinsically safe Yokogawa pH/ORP transmitter Model FLXA21/ 202 series or Model PH202S series.

  • Page 10: Installation Of Fu24

    Tighten the sensor using a wrench on the sensor flats. The FU24 can also be mounted in a FF20-*22 and FF20-*33 flow fitting or put in the process by making use of the FS20-*22 and FS20-*32 subassembly.
  • Page 11 FU24 TeflonTape Figure 2. FF20-.33 installation example FU24 IM 12B06J03-03E-E IM12B06J03-03E-E_ed10.indd 11 8/30/2018 10:42:36...

  • Page 12: Dimensions

    Dimensions in mm (inches) 260.9 [10.28"] 193.0 [7.61"] 71.0 [2.80"] 1"NPT 1"NPT TYPE: NPT 246.2 [9.70"] 178.4 [7.03"] 56.4 [2.22"] TYPE: FSM 247.0 [9.73"] TYPE: VP/VS NPT 232.4 [9.16"] TYPE: VP/VS FSM Figure 3. Dimensions FU24 IM 12B06J03-03E-E IM12B06J03-03E-E_ed10.indd 12 8/30/2018 10:42:36...

  • Page 13: Wiring

    5. WIRING 5.1 Connections The FU24 sensor is provided with a fixed cable or Variopin (VP/VS) connector. 5.2 Definition EXA/FLXA terminal numbers to FU24 sensor FU24-05/10 wire # EXA/FLXA pH+ORP terminal pH compensated pH+rH FU24-VP and FU24-VS with WU10/WE10- wire color...

  • Page 14: Settings For Ph402G And Ph202G(S)

    6. GENERAL CALIBRATION & MAINTENANCE PROCEDURE 6.1 Calibration for pH measurement To calibrate the FU24 pH/ORP sensor, two buffer solutions with known pH values are required. It is recommended that one buffer solution has a value near to pH 7.00.

  • Page 15: Calibration For Orp And Rh Measurement

    The rH value is a function of the reference system and the pH value of the buffer solution. The FU24 sensor has a reference system of saturated Silver/Silver Chloride (Ag/AgCl). The commonly used standards for ORP and rH calibration are made from Chinhydron (Quinhydrone) powder dissolved in pH buffer solutions (1 g / 200 ml).

  • Page 16: Model Codes

    7. MODEL CODES Model Code Suffix Code Option Description FU24 Wide body sensor Type - VP Variopin connector - VS Variopin connector for SENCOM - 05 Fixed cable, 5 meter - 10 Fixed cable, 10 meter Temp. element - T1...

  • Page 17: Chemical Compatibility Chart

    Note: Information in this list is based on our general experience and literature data and However Yokogawa is unable to accept responsibility for claims related to this information. given in good faith. However Yokogawa is unable to accept responsobility for claims related to this information.
  • Page 18 IM 12B06J03-03E-E IM12B06J03-03E-E_ed10.indd 18 8/30/2018 10:42:37...
  • Page 19 IM 12B06J03-03E-E IM12B06J03-03E-E_ed10.indd 19 8/30/2018 10:42:37...
  • Page 20 Yokogawa has an extensive sales and YOKOGAWA ELECTRIC CORPORATION YOKOGAWA ELECTRIC ASIA Pte. LTD. World Headquarters 5 Bedok South Road distribution network. 9-32, Nakacho 2-chome, Musashino-shi Singapore 469270 Singapore Tokyo 180-8750 Please refer to the European website Japan www.yokogawa.com/sg www.yokogawa.com (www.yokogawa.com/eu) to contact your...
