Port Introduction - Zhiyun CRANE 2S User Manual

Get to know the CRANE 2S
29
28. Type-C camera control port
29. Quick release base adjustment
module
30. Quick release base locking latch
31. 1/4" screw thread with crown gear
32. Type-C firmware update port
Serial
Port type
No.
Type-C camera control
1
Type-C port for
2 TransMount Follow
Focus Motor
3 firmware update port
35
36
37

Port introduction

Camera connection and control
port
Motors connection and control
upgrade the CRANE 2S firmware
28
30
33. 1/4 camera locking screw
34. Camera backing base
35. Quick release plate
36. Lens support
37. Locking screw for lens support
Function
TransMount Zoom or Focus
Connect to the computer to
31
32
33
34
Output Input
5V1A NA
8.7V2A NA
/ /
3
