TERRA/TERRA SX
| Electric Wheelchair

5. Technical Data

Dimensions and Weights
Max. Weight:
Seat width:
Seat height:
Depth of seat:
Seat angle:
Height of backrest:
Backrest angle:
Overall length:
Total width:
Empty weight:
Tires
Drive Wheels:
Castors:
Electrical System
Main fuse:
Batteries:
Charging Unit:
Motor:
Controller:
Light and indicators:
Driving Specifications
Max. safe angle:
Speed:
Max. incline:
Max. ground clearance:
Max. obstacle height:
Range:
Turn radius:
50
136 kg
41 – 50 cm
54 cm
40 – 45 cm
-2° – +10°
55 cm
90°, 100°, 110°, 120°
106 cm including footrests
60,5 cm
88,3 kg including batteries
3.00-8 mm (PU)
2,80/2,50-4 mm (PU)
50 A
2 x 12V / 55 Ah
24VDC / 4A (HP8204B)
2 x 450 W / 5100 RPM
PG Drives VR2 with light (Terra)
PG Drives VR2 without light (Terra SX)
according to the German traffic regulations
[StVZO] (Terra)
6°
10 km/h
8°
125 mm
50 mm
32 km
120 cm
Electric Wheelchair |
Fittings
Frame: powder-coated aluminum frame
Brake: automatic braking system according to the
German traffic regulations [StVZO]
Operating forces
Joystick: approx. 1 N
Buttons on the controller: approx. 1 N
Disconnecting the drives: > 60 N

6. Maintenance tips for the user

6.1. Cleaning and Disinfection

Make sure the wheelchair is turned off before starting to clean.
• The frame and the paneling of the wheelchair can be cleaned with
a moist cloth. You can use a mild detergent for more stubborn dirt.
• The wheels can be cleaned with a wet synthetic fiber brush (do not
use a wire brush!)
• You can remove dust and small stains from your seat, backrest and
armrests with a moist cloth. Do not use any aggressive cleaning
agents, since they could disintegrate the surface of the fabric. The
upholstery can be washed in 40°C water and disinfected with a
commercially available disinfectant.
• Make sure that the electric and electronic components do not come
into contact with water unnecessarily!
Caution! Do not use high pressure cleaners or
steam cleaners.
