Introducing the USB-2533

The USB-2533 is supported under popular Microsoft

multifunction measurement and control board designed for the USB bus.

The USB-2533 provides either 32 differential or 64 single-ended analog inputs with 16-bit resolution from its

40-pin connectors. It offers seven software-selectable analog input ranges of ±10 V, ±5 V, ±2 V, ±1 V, ±0.5 V,

±0.2 V, and ±0.1V.

You can configure up to four of the analog inputs as differential thermocouple (TC) inputs.

The board has 24 high-speed lines of digital I/O, two timer outputs, and four 32-bit counters. It provides up to

12 MHz scanning on all digital input lines.

You can operate all analog I/O, digital I/O, and counter/timer I/O synchronously.

For information on the features of InstaCal and the other software included with your USB-2537, refer to the

Quick Start Guide that shipped with your device. The Quick Start Guide is also available in PDF at

www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf.

Check

www.mccdaq.com/download.htm

Windows

operating systems. The USB-2533 board is a

for the latest software version.
