- Page 1 Assembly Installation, Care Maintenance and User Instructions Manual Trampoline 10' Combo Model STCW10N Manual # 1 Model _________________...
-
Page 2: Important Precautions
IMPORTANT PRECAUTIONS 11. If you do not use the trampoline correctly someone can be seriously hurt. ! WARNING: To reduce the risk of serious injury, read and follow all of the warnings, precau- 12. The trampoline should only be used when an older tions, and instructions in this manual before you person, who knows the proper safety precautions, is assemble (put together) and use the trampoline. -
Page 3: Trampoline Safety Information
TRAMPOLINE SAFETY INFORMATION In trampoline use, as in all active recreational sports, participants can be injured. However, there are steps that can be taken to reduce the risk of injury. In this section, primary accident patterns are identified and the responsibilities of supervisors and jumpers in accident prevention are described. -
Page 4: Methods Of Accident Prevention
METHODS OF ACCIDENT PREVENTION The Supervisor’s Role in Preventing Accidents It is the responsibility of the supervisors of trampoline users to provide knowledgeable and mature supervision. They need to know and enforce all of the rules and warnings printed in this manual to minimize the likelihood of accidents and injuries. -
Page 5: Instructional Program And Model Lessons
INSTRUCTIONAL PROGRAM AND MODEL LESSONS The following lessons are examples of an instructional program. They should follow a complete discussion and demonstration of body mechanics between the supervisor and the student(s). See pages 9 and 10 for descriptions of basic trampoline skills. Lesson 1 1. -
Page 6: Basic Trampoline Skills
BASIC TRAMPOLINE SKILLS Fundamental Bounce Knee Drop 1. Start from a standing position with your head erect and 1. Start bouncing from a standing position, keeping your your eyes on the frame pad. eyes on the frame pad. 2. Swing your arms forward and up in a circular motion. 2. - Page 7 Seat Drop Front Drop 1. Land in a sitting position with your legs parallel to the 1. Start from a low bounce and land on the mat in a prone mat. position. 2. Place your hands on the mat beside your hips. 2.
- Page 8 ASSEMBLY IMPORTANT ASSEMBLY INFORMATION Need phillips screw driver and 2 adjustable wrenches (putting the trampoline together). A rubber mallet may make assembly easier, however. Assembly requires two persons. Wear gloves to protect your hands from pinch points during assembly. TRAMPOLINE PLACEMENT 1.
- Page 9 3. Note: This step requires two persons. During this step, you will connect the four assembled leg sections Stand two leg sections and hold them in the positions shown.. Insert the small end of the Top Tube into the indicated Top Tube with "T"-Joint (1) on the other leg section.
- Page 10 Frame Pad so that the slits are directly above the Legs (2), as shown. (If you are using the Skywalker Trampoline Enclosure, go to the Skywalker Trampoline Enclosure User's Manual, pages 8-11, for instructions in assembling the Enclosure.
- Page 11 Safety Note: Do not use the trampoline without the Frame Pad. The Frame Pad is designed to reduce the pos- sibility of injuries due to jumpers coming in contact with the trampoline frame. If you do not have a Frame Pad, contact your dealer to obtain one.
-
Page 12: Care And Maintenance
CARE AND MAINTENANCE CARE Do not allow pets on the trampoline, as their claws may snag and pull the mat material or damage the frame pad. The trampoline is intended to be used by one person at a time who weighs not more than 200 pounds. The user should be either barefoot, wearing socks, or wearing gymnastic shoes. -
Page 13: Exploded Drawing And Parts List
EXPLODED DRAWING AND PARTS LIST Qty. Description Top Tube with "T"-Joint Leg Brace Stitched Bed with 64 V-rings Springs Frame Pad User's Manual and Safety Placard Top Tube with Socket Screw (Including two spare part) Set of ASTM Frame Labels * These parts are not illustrated. - Page 14 Assembly Installation, Care Maintenance and User Instructions Manual 10' Enclosure Model STCW10N Manual # 2 Read and follow all steps in manual #1 first. Model _________________...
- Page 15 IMPORTANT PRECAUTIONS 12. This trampoline enclosure is made for users who do not ! WARNING: To reduce the risk of serious injury, read weigh more than 200 pounds and children less than 6 years and follow all of the warnings, precautions, and instructions old should not use it.
-
Page 16: Enclosure Safety Information
ENCLOSURE SAFETY INFORMATION NEED FOR TRAMPOLINE ENCLOSURE SAFETY A trampoline enclosure is a recreational product. The information on this page and on pages 6-7 identify important safety precautions. The precautions are not all- inclusive, because an enclosure can be used in ways that this manual cannot cover completely. To prevent pinches and cuts during enclosure use, a frame pad must be installed on the trampoline. - Page 17 Hazards Associated with High Winds A trampoline with an enclosure can be moved or blown over by high winds. Anyone in its path, or inside of the enclosure, may be injured if this happens. If you expect high winds, take down the enclosure netting and stake the trampoline frame to the ground (see page15 in the trampoline manual), or move the trampoline and enclosure to a sheltered location.
- Page 18 ASSEMBLY ASSEMBLY (PUTTING THE ENCLOSURE TOGETHER) IMPORTANT ASSEMBLY INFORMATION • Need phillips screw driver and 2 adjustable wrenches (not included). • Assembly requires two adults. Keep children away from the trampoline enclosure until it is completely put together. • Use gloves to protect your hands from pinch points while putting the enclosure together. •...
- Page 19 3. Note: In Step 3 you will secure the Enclosure arches to the frame of the trampoline. Lift one of the arches assembled in Step 2 and insert the two Straight Tubes (6) into the tops of the two trampoline frame Square Sockets (4) as shown. Insert a bolt (2) through the matching holes in the left side Straight Tube (6) and Square Socket (4).
- Page 20 6. Align Enclosure door under one of the enclosure uprights. Center the opening over leg post. Button on Enclosure frame to each "V" spring clip. Remove spring. Place "V" clip through button slot and re-attach spring. Continue for all 64 springs and buttons. 5.
- Page 21 DISASSEMBLY (TAKING THE ENCLOSURE APART) To disassemble the trampoline enclosure (take it apart), follow assembly steps 1 through 7 in reverse order.
- Page 22 CARE AND MAINTENANCE TRAMPOLINE ENCLOSURE CARE AND MAINTENANCE To avoid damage to the trampoline and enclosure, do not allow pets or animals inside the enclosure. Appropriate shoes should be worn inside the enclosure to reduce wear to the trampoline mat (bed). Follow the tram- poline manufacturer’s recommendations.
- Page 23 EXPLODED DRAWING AND PARTS LIST Qty. Description Qty. Description Bolt Curved Tube Lock nut Foam Sleeve Self-tapping Screw Netting with attached Hardware Straight Tube Strap with D-rings L-tube User's Manual and Safety Placard End Cap Specifications are subject to change without notice. ORDERING REPLACEMENT PARTS To order replacement parts, visit our web site at www.skywalkertrampoline.com or call our toll-free Customer Care Hot Line at 1-866-603-Jump (5867), Monday through Friday, 8 a.m.
