Vision Fitness X6100 Assembly Manual

Folding elliptical trainers
Hide thumbs Also See for X6100:

Advertisement

Quick Links

Download this manual See also: Owner's Manual
A s s e m b l y
G u i d e
X6100, X6200
AND
X6200HRT
FOLDING ELLIPTICAL TRAINERS

Advertisement

loading
Need help?

Need help?

Do you have a question about the X6100 and is the answer not in the manual?

Questions and answers

Related Manuals for Vision Fitness X6100

Summary of Contents for Vision Fitness X6100

  • Page 1 A s s e m b l y G u i d e X6100, X6200 X6200HRT FOLDING ELLIPTICAL TRAINERS...
  • Page 2 X6100, X6200, AND X6200HRT To avoid possible damage to this Elliptical Trainer, please follow these assembly steps in the correct order. Before proceeding, find your new Elliptical Trainer’s serial number located on the front axle tube, and enter here: Refer to this number when calling for service, and enter this serial number on your Warranty Card and in your own records. Be sure to read your Owner’s Guide before using your new Elliptical Trainer.
  • Page 3 TOOLS & PARTS INCLUDED Screwdriver 5mm T-Shaped Wrench 13mm Wrench 6mm L-Shaped Wrench PARTS BOX Console Mast Boot Dual-Action Link Arm Covers Dual-Action Axle Covers 5mm L-Shaped Wrench Rear Stabilizers Pedal Arm Bracket Covers Pedal Support Bracket Water Bottle & Cage Power Supply Heart Rate Chest Strap ( X 6 2 0 0 H R T Only) Color-coded Hardware Bags...
  • Page 4 GREEN BAG M8x13L Screw 20x29x1.5T Wavy Washer Quantity: 2 BLACK BAG M4x15L PanHead Screw 25x34x2T Wavy Washer Quantity: 2 M8x30L Screw Quantity: 2 8x35x2T Washer Quantity: 2 8x25x1.5T Washer Rubber Nut Cap Quantity: 2 ORANGE BAG 8x16x1.5T Washer Quantity: 6 PINK BAG M8 Nut Quantity: 4...
  • Page 5 ORANGE BAG STEP • For ease of assembly, place a block (about 2” thick) under the rear of the frame. • Slide the axle through the plastic sleeves of the right guide rail and the frame. Slide the left guide rail onto the left side of the axle.
  • Page 6 BLUE BAG STEP • Slide a wavy washer (25x34x2T) onto the right rotation axle. Slide the bushing housing of the right pedal arm onto the right rotation axle. The pedal arm roller wheel should be placed in the groove of the guide rail. Secure the pedal arm to the rotation axle with a washer (8x30x1.5T) and screw (M8x20L).
  • Page 7 Connect the heart rate wires from the console mast to the console. Console Attach the console to the console mast X6100 with the four screws. Mast • Attach the water bottle cage with the screwdriver and the screws removed earlier in this step.
  • Page 8 GREEN BAG STEP • Slide a wavy washer (20x29x1.5T) on the lower link arm axle, which is located under the foot plate. Slide the axle through the bracket located on top of the pedal arm. • Secure the lower link arm to the pedal arm by attaching the pedal support bracket with three screws (M8x13L).
  • Page 9 BLACK BAG STEP • On the right side, slide the dual- action axle cover into place on the con- sole mast axle. Slide a wavy washer (25x34x2T) onto the axle. Slide the right dual-action arm on the axle. Fix in place with the washer (8x35x2T) and locknut (M8).
  • Page 10 500 South CP Avenue • P.O. Box 280 • Lake Mills. WI 53551 toll free 1.800.335.4348 • phone 1.920.648.4090 • fax 1.920.648.3373 www.visionfitness.com ©2005 Vision Fitness. All Rights Reserved. 10.05 AG18.23PRD REV7...
