Roland NOVA-MOD SH-101 Manual page 9

Ext LFO/Clk Mod
1ook
5
4
6
7
NC
3
NC
2
1
DPDT
Switched 1/4" Jack
To solder pad
To solder pad
under U3a pin 3
under U3a pin 2
LFO Rate Extender
DPST (center off)
Fast
Slow
Norm
TR4
150k
R15
Use 200k or 300k resistor in place of the 150k resistor
if LFO cycles longer than 30sec are needed
2
+
3
-
IC3
To do this mod, one must remove IC3 from
the circuit board, bend pens 2 and 3 up 180°
and resolder back into place.
U3
1 2 3 4
Desolder and lift end of R15 on TR4 side.
Solder the 150K Resistor in series.
TR-4
