DA-JB4100 INSTALLATION MANUAL

Mounting

Mount the junction box to the wall and connect your camera as follows:
Wall
Junction Box
1
Mount the junction box to the wall by using the screws and the anchors.
Use the provided guide pattern to check the distance between the screw holes if necessary.
This manual is intended for users of the DA-JB4100 junction box. It
includes instructions for mounting the DA-JB4100 junction box to a wall.
• This junction box is intended to be used with some models of
cameras. Do not use it with other models of cameras.
• This installation should be performed by a qualified service
personnel in conformance to all local codes.
• You may need to reinforce the wall. If the wall is not strong
enough to support the camera, the camera may fall.
• Do not use this product for other purposes.
Bushing
