KIT COMPONENTS
• A) Radio housing • B) Trim plate • C) ISO brackets
A
B
Metra. The World's best kits.
®
Pontiac Grand Prix
2004-2008
KIT FEATURES
• DIN radio provision with pocket
• ISO DIN radio provision with pocket
C
MetraOnline.com
© COPYRIGHT 2017 METRA ELECTRONICS CORPORATION
99-3527
I N S TA L L AT I O N I N S T R U C T I O N S
U.S. Patent # D513,508
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Assembly
– DIN radio provision with pocket........................3
– ISO DIN radio provision with pocket .................3
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: GMOS-01 • GMOS-04
Antenna Adapter: 40-GM10
Steering Wheel Control Interface: ASWC-1
TOOLS REQUIRED
• Phillips screwdriver • Panel removal tool
• 9/32" socket wrench
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
REV. 11/20/17 INST99-3527
