NETWORK REQUIREMENTS
An Ethernet connection with DHCP must be used to connect the ACU to the Local
Area Network (LAN). You also need to configure firewall settings to communicate with
the Openpath system. Openpath uses the following outbound ports:
● TCP port 443
● TCP port 80
● UDP port 123
Note:​ If using an external DNS server, outbound UDP port 53 must also be open.
To support Wi-Fi unlocking from the mobile app, the ACU's inbound TCP port 443
must be available from within the LAN. Inbound port forwarding on the router, firewall,
or NAT device is not required.
SELECTING A BACKUP BATTERY
While not required, Openpath recommends having a backup battery in case of
power outages. The size of battery depends on your setup and how long you want to
power the system.
Table 1:​ Power requirements for legacy Smart Hubs (12V)
Assuming a 12V power supply, a Smart Hub configured with four Openpath Readers
and locking hardware uses 4 Amps. To keep the system running for 3 hours with all
entries engaged, you need 4A x 3 hours = 12AH, so a 12V 12AH sealed lead acid (SLA)
or gel cell battery.
Version 1.8
Controller board
Smart Reader
Locking hardware
(while engaged)
©​ Openpath 2020
1A
0.25A
0.25A–0.5A
