WARNING:
D o not connect 12V out on the Wiegand port to the legacy panel;
doing this will cause voltage backfeeding, potentially damaging one of the
supplies.
Version 1.8
Figure 15 : Wiring to Legacy Panels
© Openpath 2020
Page 22
