- Page 1 CAM-Analog2.0 CVI/TVI/AHD User manual ver. 1.1 Wireless signal transmission kit for analog CVI, TVI and AHD CCTV cameras with resolution up to 2Mpix...
-
Page 2: Table Of Contents
Thank you for choosing our product. We are sure that you will appreciate its unique features. Please read the manual to ensure safe use and enable maximum performance. Table of contents Safety and maintenance tips....................2 R&TTE declaration of conformity ..................3 Basic information ......................... -
Page 3: Safety And Maintenance Tips
It is necessary to comply with current norms and safety standards in current location and on current site. Both user and installer are obliged to check the current norms and condi- tions of specific installation every time. In case non-compliance of norms with current safety requirements please refrain from installing the devices. CAM-Analog2.0 Instrukcja... -
Page 4: R&Tte Declaration Of Conformity
CAM-Analog2.0 is compliant with provisions related to the safety in using electrical de- vices. Observe the following guidelines: the power outlet must be grounded in compliance with applicable provisions, •... -
Page 5: Basic Information
• DC power socket • DIPswitch for setting up channels and working parameters • Package contents: Transmitter video/audio with built-in directional antenna • Receiver video/audio with built-in directional antenna • U-bolt or zip ties • User manual • CAM-Analog2.0 Instrukcja... -
Page 6: Technical Parameters
Transmitter: 9-16V DC / 800mA Receiver: 9-16V Power supply DC / 500mA Mounting Zip ties or u-bolt Working temperature -20°C ÷ 55°C Dimensions Tx: 152x105x60 [mm], Rx: 164x164x80 [mm] Outdoor IP66 Guarantee 2 years Norms compliance CE, RoHS CAM-Analog2.0 Instrukcja... -
Page 7: First Start
SETTINGS nr 5. For most UE countries 14dBm in 5.8GHz is the maximal signal strength. Setting up working mode (dipswitch SETTINGS - 6) Configure the format of video signal using SETTINGS – 6 switch referring to camera stan- dard. CAM-Analog2.0 Instrukcja... -
Page 8: Installation
It is necessary to ensure full optical visibility in the first Fresnel zone. With 5.8GHz frequency and 400m distance you need to ensure at least free 3.2m radius of space (r in the dr point) for radio beam. CAM-Analog2.0 Instrukcja... -
Page 9: Description Of Indicators And Joints
3. Due to generating interferences it is not recommended use of cheap switch-mode power supplies and other power supplies than intended to use, for example CAMSAT ZS12/1A. 4. It is not recommended to connect transmitter with receiver to one shared power supply. -
Page 10: Safety Warnings
7. The warrantor may refuse to carry out warranty repairs or terminate the warranty if it is determined that the seals placed on devices or components comprising it are damaged. 8. All repair services resulting from warranty are made exclusively in the Camsat service. Warranty does not cover 1. -
Page 11: Declaration Of Conformity
5.2. Declaration of conformity CAM-Analog2.0 Instrukcja... -
Page 12: Device Disposal
Hereby, CAMSAT Gralak Przemysław declares that the product series CAM-Analog2.0 meets the essential requirements and other relevant provisions of Directive 1999/5/WE. The device is CE marked, which indicates compliance with the guidelines of the Directive. The device can be sold and used for transmission in the 5GHz band. The frequency range can be adjusted using the settings in accordance with legal regulations in every country.
