- Page 1 1.1 User’s manual External wireless system with 3 PoE ports, designed for radio data transmission between IP cameras and NVR - 5GHz operating band www.camsat.com...
- Page 2 Please, read this manual to ensure safe operation and maximise efficiency of the device. The contents of this manual comprise proprietary information of CAMSAT and are intended only for use by purchasers of the equipment described herein. In order to copy or use any part of this manual for purposes other than the application or maintenance of the described equipment, it is required that the customer should first obtain a written consent from CAMSAT.
-
Page 3: Table Of Contents
I Safety and maintenance tips....................4 1. Safety tips..........................4 2. R&TTE declaration of conformity................... 5 3. Distances and interferences....................5 II CDS-6IP 3PoE.........................6 1. IP cameras bitrate......................... 6 2. PoE ports..........................6 3. Power supply.......................... 6 4. Contents of the package......................7 5. -
Page 4: I Safety And Maintenance Tips
In order to safely use our device, you should read and observe the tips contained in this manual. CDS-6IP 3PoE module is maintenance-free. We recommend installing it on a stable structure and connecting its power cables in a manner that would prevent them from being accidentally damaged by the operator or any bystanders. -
Page 5: R&Tte Declaration Of Conformity
(RED: 2014/53/UE). CDS-6IP 3PoE module is compliant with provisions related to the safety in using electri- cal devices. Observe the following guidelines: the power outlet must be earthed in compliance with applicable provisions, •... -
Page 6: Cds-6Ip 3Poe
A system with 3 PoE ports, for wireless transmission of video and audio from IP cameras. The CDS-6IP 3PoE radio unit is designed for two-way transmission of all data between IP cameras and the IP network in which the recorder or VSM video recording system is located. -
Page 7: Contents Of The Package
100% of frames. 36 months of warranty – peace and full technical support for years. 4. Contents of the package CDS-6IP 3PoE x 1 • PoE48V 0.5A power supply with 230V European or UK adapter x 1 •... -
Page 8: Description Of The Connectors
PORT 1 - Dual-function LAN port (RJ45) which has an input for a PoE power supply or an output for powering a PoE IP camera. PORT 2 & PORT 3 - LAN ports with PoE to power IP cameras or power another CDS-6IP 3PoE radio unit. -
Page 9: Some Connection Options With Ip Cameras
6. Some connection options with IP cameras... -
Page 12: System Configuration
IMPORTANT: It is recommended to make first start and configuration of the system du- ring dry run. Mount the devices on the site only after a full radio connection. To start and configure a radio device connect the CDS-6IP 3PoE to the power supply. Use one of 4 power options: PoE48V/0,5A power supply that is included in the set –... -
Page 13: Www Panel
To log into the CDS-6IP 3PoE wireless module, set the computer’s IP address in the same IP subnet (the radio unit’s default IP address in 192.168.1.1). Then start the web browser and enter the IP address of the radio unit. The login menu will appear on the screen: When using the IE browser, due to the lack of manufacturer’s support for this browser,... -
Page 14: Mounting The Device On Site
ADVANCED SETTINGS Time Zone Setting – Set the time of the NTP server. • System Log – a review of recent work and changes in the CDS-6IP 3PoE device. • Upgrade Firmware – update software. • Backup/Restore – save/restore the system configuration. -
Page 15: Logging In
→ Network Settings. The following screen will appear: Enter the new IP address for the CDS-6IP 3PoE (IP Address field) (IP address must be on the same subnet as the computer), subnet mask, IP address of the gateway (Default Gateway) (entering the IP address of the gateway is only necessary if the device operates outside the local network). -
Page 16: Scanning The Usage Of Operating Channels
7. Scanning the usage of operating channels The CDS-6IP 3PoE modules allow scanning the ether for frequencies used nearby. It is a very useful tool when setting up the working channel. With it, we know which channels to avoid and which are free and can be used for wireless transmission of signals from the IP cameras. -
Page 17: Operating Mode Settings (Transmitter / Receiver)
9. SSID radio link name (Required only for subsequent receivers) To ensure communication between the CDS-6IP 3POE wireless modules, all units must use the same SSID (set it in the Wireless Settings tab, Link Name (SSID) parameter). When setting up... -
Page 18: Distance
Basic information about the wireless connection will appear in the Wireless Status tab. Additionally, in the unit working in the MASTER (NVR/DVR) mode, the Wireless Clients tab will display a list of CDS-6IP 3PoE wireless units connected to this module. -
Page 19: Password Changing
If the response time of the device is shorter than 200-400ms it means that configuration is correct. To make sure that all devices are correctly configured, you can execute the command PING with the address of each device in the system (CDS-6IP 3PoE, IP cameras, routers, recorders). -
Page 20: Security Of Radio Connection
If the WPA data encryption method is selected, a network key is required, the same for all CDS-6IP 3PoE units. User can select the encryption key type in the Data Encryption menu: 64-bit WEP: consists of no more than 10 hexadecimal characters. -
Page 21: Test And Installation Tools
16. Test and installation tools The CDS-6IP 3PoE devices have a watchdog function. To configure the watchdog, go to ADVANCED SETTINGS → SERVICES. The Dual SLAVE function allows you to start the second network access channel on separate passwords, e.g. for administrative or service purposes. To configure this functionality, go to... -
Page 22: Troubleshooting
17. Troubleshooting PROBLEMS WITH CONNECTING • If despite correct configuration, there is a problem with the connection between devices, e.g. the device can not see each other, reset modules and setup from the beginning. RESETTING THE MODULES TO THE DEFAULT SETTINGS •... - Page 23 Internet → Network Connections. Then select the current network adapter, which is connected to the CDS-6IP 3PoE module. Click on the Internet Protocol Version 4 (TCP/IPv4) on the list, and then click Properties. In an open window, you can enter a new IP address of the computer, or click on the Advanced…...
-
Page 24: General Warranty Terms
8. All repair services resulting from the warranty are performed only in Camsat service. The warranty does not cover 1. Mechanical damage of devices and failures occurring due to fortuitous events, such as: fire, power grid overvoltage, electrical dicharges, power supply, effects of chemical sub- stances. -
Page 26: Device Disposal
Hereby, CAMSAT Gralak Przemysław declares that the product series CDS-6IP 3PoE me- ets the essential requirements and other relevant provisions of Directive 2014/53/EU. The device is CE marked, which indicates compliance with the guidelines of the Directive. The device can be sold and used for transmission in the 5 GHz band. The frequency ran- ge can be adjusted using the settings in accordance with legal regulations in every coun- try.
