- Page 1 VueNet EasyLink ver. 1.2 User`s manual External wireless video and audio transmission system for IP cameras HD and UHD in the band 5.1 - 5.8 GHz...
-
Page 2: Safety And Maintenance Tips
Thank you for choosing the VueNet EasyLink. We trust that its unique features will come in very handy. Please, read this instruction manual to ensure safe operation and maximise efficiency of the device. Safety and maintenance tips In order to safely use our device, you should read and observe the tips contained in this instruction manual. -
Page 3: Distances And Interferences
The VueNet EasyLink module is compliant with provisions related to the safety in using electrical devices. Observe the following guidelines: the power outlet must be earthed in compliance with applicable provisions, • before transferring the device or performing any other technical operations, discon- •... -
Page 4: Preparation For Operation
System for transmission of video and audio from IP cameras. Key features of the module VueNet EasyLink: Easy configuration on switches without the need of a PC • VueNet EasyLink can work both as a receiver and a transmitter • Ensures continuous and stable transmission •... - Page 5 This can save a lot of valuable time with the configuration of many different cameras. MASTER receiver and all SLAVE transmitters must be set to the same operating channel to establish a connection. Each next set working nearby must be set to a different operat- ing channel.
- Page 6 Multipoint Configuration VueNet EasyLink can be connected in Point-to-Multipoint configuration with up to 4 transmitters to one receiver. These settings are configured by switches 7 and 8 in each transmitter according to the following formula: After 90 seconds since power start equipment will make a transparent interconnection sending all IP addresses connected to the ports of the device.
-
Page 7: Montage
Each next set working nearby must be set to a different operating channel. For advanced (not required): VueNet EasyLink enables logging in to the Web panel and checking multiple link parameters, eg. the strength of the radio signal. To log in to your dashboard, connect the VueNet EasyLink to a computer with network card set compatible with addresses according to the table on page 3. -
Page 8: Connection And Start-Up
Connection and start-up It is recommended that the first start-up and configuration of the system is done at the desk at small distances. This can save a lot of valuable time with the configuration of many different cameras. Transmitter (IP camera): Set DIPswitch No. - Page 9 Receiver powered by PoE (NVR). Set the dipswitch No. 1 to ON (receiver mode), set the operating channel by a table identical to • the transmitter, set DIP7 and DIP8 to ON (up) Connect NVR with the network cable to the PORT 1 or LAN port in PoE power supply. •...
-
Page 10: Examples Of Application
Examples of application Transmitter Transmitter 192.168. 116.2 192.168.120.2 Channel: 149 Channel: 165 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8... - Page 11 Transmitter 192.168.118.5 Channel: 157 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8...
- Page 12 Table of available operating frequencies Table of frequencies outside the EU and the US and paid Use of specific channels according to their purpose: CE - Europe • FCC - US • Using other frequencies depends on the legal regu- lations of the country where you are.
-
Page 13: General Warranty Terms
Company grants a 24 month warranty for the VueNet EasyLink transmission kit 1. If the device is not be operating properly, make sure, before returning the device for servicing, that everything was done according to the operating manual 2. -
Page 15: Device Disposal
Device disposal The mark presented to the left informs that this electrical or electronic device, after its use has ended, cannot be thrown together with household refuse The device should be delivered to a specialised collection point Detailed information about the closest collection point is available from local authorities.
