2.13.6. Data

User data is recovered and presented on this D type
15W PIN#
5
6
7
The unit supplies a pair of ground free relay contacts to give a "summary alarm"
status of the unit. The relay default is factory configured for an "open circuit"
indicating a fail.
To reverse this configuration use the internal 'status' link on the control PCB.
The relay contacts open if the IRD6200 loses power or has a "major" alarm.
15W PIN# Signal
Status
14
relay
Status
15
relay
2.13.7. Audio 1 & 2
The audio channels one and two are not available.
2.13.8. Ethernet – Control
Standard 10/100 Ethernet connection for control of the unit using Web Browser
(HTTP) and Network Management (SNMP).
If required, use the internal web browser link to download a copy of the units
SNMP MIB (Management Information Base). Navigate to Unit Setup / Control /
Download MIB.
NOTE: See section 4.62.13.8 to connect to the unit via the internal web browser.
To ensure that the version relevant to the current code release is used, always
use the SNMP MIB link as the reference for any SNMP application.
Issue No: 1
Ref: IRD6-ASUM-700X
Signal
Data Rx
Data Tx RS232 MPEG data output
GND
Description
Relay contact opens on fault
Relay contact opens on fault
