NEC PASOLINK Training Course page 89

OPERATION
PERSONAL COMPUTER
3-32
RS-232C
CABLE(BLACK)
Note: When the controlling or setting of own station are performed,
connect the cable to the LA PORT. When the controlling or
setting of opposite station are performed, connect the cable to the
NMS/RA port. But, if the following cases are applied, the NMS/
RA terminal can not be used.
• When the PM CARD is mounted on the equipment.
• When H BER alarm is issued.
Fig. 3-7 Equipment and Monitoring Setup
Step
Note: The keys, "0" to "9" are used for selection of the menu
or entering values. "Enter" key is used for confirmation
of entering values. "Esc" key is used for cancellation of
entering values and display the higher rank menu.
2 Turn on the power on the PC. Then, operate the communication
software (e.g. MS Hyper Terminal),
3 Press the "CTRL" and "D" keys at the same time,
EOW
CALL
FUSE (7.5A)
NMS/RA LA PORT
IDU
RESET
FUSE (7.5A)
LA PORT
EOW
CALL
−
NMS/RA LA PORT
RESET
FUSE (7.5A)
LA PORT
IDU
Procedure
ROI-S04488
PASOLINK
ODU IDU
PWR
RESET
MAINT
−
+
SELV
PASOLINK
PWR ODU
IDU
MAINT
−
+
SELV
PASOLINK
RESET
OPR ALM
OPR
SEL
TX RX TX RX
No.1
1
2
No.2
PASOLINK
PWR ODU IDU
MAINT
−
+
SELV
