Honeywell CT40 Series Quick Start Manual

Powered by android
Hide thumbs

Advertisement

Quick Links

CT40 Series
powered by Android™
Quick Start Guide
CT40-A-EN-QS-01 Rev E
06/20

Advertisement

loading

  Related Manuals for Honeywell CT40 Series

  Summary of Contents for Honeywell CT40 Series

  • Page 1 CT40 Series powered by Android™ Quick Start Guide CT40-A-EN-QS-01 Rev E 06/20...
  • Page 2: Memory Card Specifications

    Note: CT40-L0N/CT40P-L0N models do not include a WWAN radio. Memory Card Specifications Honeywell recommends the use of Single Level Cell (SLC) industrial grade microSD™ or microSDHC™ memory cards with mobile computers for maximum performance and durability. Contact a Honeywell sales representative for...
  • Page 3 Mobile Computer Features Imager Window (LED/Laser Aperture) Speaker Microphone Scan Status LED Front Facing Camera (model dependent) Battery Status/ Power Button Notification LED Push-to-Talk Touch Panel Button (model dependent) Scan Button Scan Button Microphone Speaker...
  • Page 4 Note: Hand strap not shown. Camera Lens Laser Safety and Flash Label Location BLE port In (model dependet) BLE Speaker Out (model dependent) Volume Button Scan Button SIM Card Door MicroSD Card Door USB, Type C (model dependent) Audio Jack Pin (model dependent) I/O Connector...
  • Page 5 Battery Latch (Models Battery Latch (Model CT40-L0N-xxxxxAx, CT40-xxx-xxxxx0x) CT40-xxx-xxxxxBx, CT40-xxx-xxxxxHx, CT40P-L0N-xxxxxAx, CT40P-xxx-xxxxxBx, CT40P-xxx-xxxxxHx) Battery (Refer to page...
  • Page 6 Install a microSD Card (Optional) Note: Format the microSD card before initial use. Note: Always power off the computer before attempting to install or remove a card.
  • Page 7 Install a microSIM Card Note: Phone feature is only available on CT40-L1N/CT40P-L1N models. On all models, the SIM slot supports use of a UICC card for NFC Secure Element NFC link encryption. Note: Always power off the computer before attempting to install or remove a card.
  • Page 8: About The Battery

    Configuration number (CN) is located on the label in the battery well of the mobile computer. We recommend use of Honeywell Li-ion battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty. Nous recommandons l’utilisation de batteries Li-ion de la marque Honeywell.
  • Page 9 Install Battery (Model CT40-xxx-xxxxx0x)
  • Page 10 Install Battery (Models CT40-LON-xxxxxAx, CT40-xxx-xxxxxBx, CT40-xxx-xxxxxHx, CT40P-L0N-xxxxxAx, CT40P-xxx-xxxxxBx, CT40P-xxx-xxxxxHx)
  • Page 11: Install The Hand Strap

    Install the Hand Strap...
  • Page 12 Charge the Mobile Computer The mobile computer ships with a partially charged battery. Charge the battery with a CT40 series charging device for a minimum of 4 hours. Using the computer while charging the battery increases the time required to reach a full charge.
  • Page 13: Turn Power On/Off

    Turn Power On/Off The first time you power on the computer, a Welcome screen appears. You can either scan a configuration barcode or use the Wizard to manually set up the computer. Once setup is complete, the Welcome screen no longer appears on startup and Provisioning mode is automatically turned off (disabled).
  • Page 14: Sleep Mode

    Press and hold the Power button until the options menu appears. Touch Swap Battery and follow the on-screen instructions. Once you replace the battery, press the Power button. Sleep Mode Sleep mode automatically turns the touch panel display off and locks the computer to save battery power when the computer is inactive for a programmed period of time.
  • Page 15: About The Home Screen

    About the Home Screen Notification / Status Bar Home Screen Panel Favorites Tray Search Bar Navigation Buttons To learn how to customize the Home screen, see the user guide.
  • Page 16: Navigation And Function Buttons

    Navigation and Function Buttons Button Description Back Return to the previous screen. Home Return to the Home screen. Recent Apps View and switch between recently used apps. Scan Touch the front (on-screen) Scan button to trigger the scanner. Volume Press the top of the button to raise the speaker volume.
  • Page 17 About Provisioning Mode After completing the out-of-box set up process, Provisioning mode is automatically turned off. Scanning a barcode to install applications, certificates, configuration files, and licenses on the computer is restricted unless you enable Provisioning mode in the Settings app. To learn more, see the user guide. Scan a Barcode with the Scan Demo For optimum performance, avoid reflections by scanning the barcode at a slight angle.
  • Page 18 Sync Data To move files between your CT40 and a computer: Connect the CT40 to your computer using a USB charge/ communication accessory. On the CT40, swipe down from the top of the screen to see the notifications panel. Touch the Android System notification twice, to open the options menu.
  • Page 19 Restart the Mobile Computer You may need to restart the mobile computer to correct conditions where an application stops responding to the system or the computer seems to be locked up. Press and hold the Power button until the options menu appears.
  • Page 20: Limited Warranty

    Trademarks Android is a trademark of Google LLC. Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made.
  • Page 21 If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. Honeywell International Inc.
  • Page 22 CT40XP-ML-RS-01 L’équipement est prévu pour une utilisation dans les pays de la Communauté européenne. Plages de fréquences de fonctionnement : 802.11a/b/g/n/ac, Bluetooth et NFC Modèle: CT40P-L0N Restrictions de la Communauté européenne : la bande de fréquences 5 150-5 350 MHz est limitée à une utilisation à l’intérieur uniquement.
  • Page 23 SAR is measured with this device at a saperation of 5mm to the body. Caution: If a body worn accessory is not purchased from Honeywell, the accessory must contain no metal and provide a 1.5 cm (0.6 in) space between the device and the Mise en garde : Si un accessoire de corps n’est pas acheté...
  • Page 24 Should you experience trouble with this equipment, please contact Honeywell International Inc, 13509 South Point Blvd, Ste.100, Charlotte, NC 28273, Tel: 800-782-4263 for repair or warranty information.

This manual is also suitable for:

Ct40-l0nCt40-l1nCt40p-l0nCt40p-l1n
