ETI NETCOM ADH Assembly Replacement Procedure page 4

COMPRESSOR ASSEMBLY REMOVAL AND
REPLACEMENT
To replace the compressor (23216) in either
an ADH NETCOM with AC power or an ADH
NETCOM with Redundant DC power,
perform the steps below. Refer to Figure 1.
To replace the compressor (23216) in an
ADH NETCOM AC NEMA, proceed to page
6.
Compressor Power Connector
Compressor Assembly
Figure 1. THE ADH NETCOM AUTOMATIC
AIR DEHYDRATOR COMPRESSOR
ASSEMBLY.
1. Shut off machine power by placing
power switch in the OFF (O) position.
With the power switch in the off
position, unplug the power cord.
possible, move the dehydrator to a
work table.
2. Remove the front top machine panel.
Retain the mounting hardware.
3.
Loosen the captive screw at each end
of the green power connector. Refer to
Figure 2. As captive screws, they
cannot be removed.
screws have
disconnect
connector.
South Bend, Indiana USA | networketi.com
Once the end
been loosened,
the green power
Figure 2. THE POWER CONNECTOR END
4. Using a 5/16" nut driver, loosen and
remove the nuts and lock washers
securing the existing compressor
mounting bracket to the chassis.
Retain the mounting hardware for re-
use.
5.
Using a tubing wrench or vacuum
tube pliers, hold the air hose about an
inch in from the end of the hose (in
front of canister 2), then pull gently to
disconnect the air hose from the
fitting. Refer to Figure 3. With both
the mounting base and the air hose
disconnected, remove the existing
compressor from the machine.
Canister 2
If
(reference)
Figure 3. DISCONNECTING THE AIR HOSE.
4
"Captive" end screws
cannot be removed.
SCREWS.
ADH INSTRUCTION MANUAL | PART NO.
Place wrench
about an inch
from the end
to remove or
replace hose.
24098 REV B
