INSTALLATION INSTRUCTIONS
PRO-E ELECTRIC RUNNING BOARDS
APPLICATION:
Ranger Super Crew 2019-2022
PART NUMBER:
29-24155
Estimated Time to Complete Product Installation: 3 - 4 Hours
Westin Automotive Products, Inc.
Thank you for choosing Westin products
320 W. Covina Blvd
for additional installation assistance please call
San Dimas, Ca. 91773
Customer Service (800) 793-7846
1
www.westinautomotive.com
P.N.: 75-2924155-RevA
ECO #: W23-0060
DATE: 10/10/2023
Advertisement
Related Manuals for Westin PRO-E 29-24155
Summary of Contents for Westin PRO-E 29-24155
- Page 1 PART NUMBER: 29-24155 Estimated Time to Complete Product Installation: 3 - 4 Hours Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com...
- Page 2 Note: It is recommended that anti-seize lubricant is used on all stainless steel fasteners to prevent thread damage and galling. Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca.
- Page 3 ITEM 3 ITEM 4 ITEM 5 ITEM 6 ITEM 7 Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com P.N.: 75-2924155-RevA...
- Page 4 White, Door Trigger Black, Negative. 12V- Red, Positive, 12V+ ITEM 12: Wiring Harness Leads Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com...
- Page 5 Pull back the B-Pillar on both sides of vehicle Figure 1 Driver Side Shown Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com...
- Page 6 Brown wire under driver carpet to driver B-Pillar Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com...
- Page 7 Modules under the door seals so they sit between each door jamb. Grounding Bolt in B-Pillar Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com...
- Page 8 Front Driver Door Induction Module Placement Front Driver Door Magnet Placement Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com P.N.: 75-2924155-RevA...
- Page 9 Front Driver Door Magnet Placement Front Driver Door Induction Module Placement Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com P.N.: 75-2924155-RevA...
-
Page 10: Manual Switch
Neatly route the power wires up to the battery but do not connect the power wires at this time. Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com... - Page 11 Figure 17 Driver Side Shown Front Linkage Control Module Rear Linkage Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com P.N.: 75-2924155-RevA...
- Page 12 Figure 18 Front Motor linkage Figure 19 Rear Motor linkage Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com P.N.: 75-2924155-RevA...
- Page 13 Sliding T-Nuts to be aligned with the corresponding slot openings in the front and rear motor linkages. Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com...
- Page 14 Frame of vehicle LED Placement Figure 24 Front & Rear LED positioning Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com...
- Page 15 Left Left Front Right Rear Right Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com P.N.: 75-2924155-RevA ECO #: W23-0060...
- Page 16 Module can prevent the running boards from opening and closing properly. 30. With the running boards operating properly, neatly tuck away all wiring using the provided zip ties (Item 7). Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca.
-
Page 17: Care Instructions
STAINLESS STEEL PRODUCTS CAN BE CLEANED WITH MILD SOAP AND WATER. STAINLESS STEEL POLISH SHOULD BE USED TO POLISH SMALL SCRATCHES. • GLOSS BLACK FINISHES SHOULD BE CLEANED WITH MILD SOAP AND WATER. Westin Automotive Products, Inc. Thank you for choosing Westin products 320 W. Covina Blvd for additional installation assistance please call San Dimas, Ca. 91773 Customer Service (800) 793-7846 www.westinautomotive.com... - Page 18 AND SAFETY. DRILLING: Most Westin products do not require drilling for installation. If drilling is defined as required, use caution when drilling a vehicle. FAILURE TO REVIEW AN AREA TO BE DRILLED MAY RESULT IN PERSONAL INJURY AND/OR INJURY TO OTHERS AS WELL AS VEHICLE DAMAGE.
