STIHL BGA 200
Instruction Manual

Advertisement

Table of Contents
loading

Related Manuals for Stihl BGA 200

Summary of Contents for Stihl BGA 200

  • Page 1 STIHL BGA 200 Instruction Manual...

  • Page 3: Table Of Contents

    6.4 Fitting the Deluxe Carrying System ....11 17.1 STIHL BGA 200 Blower ......22 6.5 Using with Carrying System .

  • Page 4: Introduction

    EC Declaration of Conformity..... . . 23 20.1 STIHL BGA 200 Blower ......23 Dear Customer, Thank you for choosing STIHL.

  • Page 5: Symbols Used With Warnings In The Text

    English 3 Overview – Safety information for STIHL batteries and products 1 Nozzle with built-in batteries: www.stihl.com/safety-data- Directs and concentrates the airstream. sheets 2 Blower Tube Directs the airstream. Symbols used with warnings in the text 3 Grip For controlling the blower when a carrying system is used.

  • Page 6: Carrying Systems

    Connects blower to “AP belt bag with connecting cable” or a STIHL AR battery. 4 Safety Precautions 4 Deluxe Carrying System Serves to carry blower on STIHL AR L or AR battery. Warning Symbols 5 STIHL AR Battery Supplies power to the blower.

  • Page 7: Intended Use

    The blower may be used in the rain. Power to this blower is supplied by a STIHL AP battery in combination with the “AP belt bag with connecting cable” or a STIHL AR battery.

  • Page 8: Clothing And Equipment

    – The user must not be under the influence of alcohol, ► Wear sturdy enclosed footwear with non-slip soles. medication or drugs. Work Area and Surroundings ► If you have any queries: Contact a STIHL servicing dealer for assistance. WARNING ￭ Innocent bystanders, children and animals are not aware Clothing and Equipment of the dangers of the blower or flying debris.

  • Page 9: Operation

    ► Replace worn or damaged labels. ￭ The dust whipped up may cause the blower to be electrostatically charged. In certain conditions (e.g. dry ► If you have any queries: Contact a STIHL servicing environment) the blower may discharge suddenly and dealer for assistance.

  • Page 10: Storing

    “AP belt bag with connecting cable”. 4.10 Cleaning, Maintenance and Repairs ► Check the battery as described in the STIHL AR battery’s WARNING instruction manual or in the user instructions for the “AP belt bag with connecting cable”.

  • Page 11: Adjusting Blower For User

    ► If 3 LEDs on the battery flash red while you are checking the controls: Pull connecting cable plug out of the socket and contact your STIHL dealer for assistance. There is a malfunction in the blower. ► If you cannot carry out the above steps: Do not use the blower and contact your STIHL servicing dealer for assistance.

  • Page 12: Using With Stihl Ar Battery

    ► Put the battery on your back. ► Open the buckles on the chest strap and waist belt. ► Take the battery off your back. Using with STIHL AR Battery 6.3.1 Fitting and Adjusting the Connecting Cable The connecting cable can be fitted and adjusted to suit the user’s size, different cordless products and the application.

  • Page 13: Fitting The Deluxe Carrying System

    ► Open the buckles on the chest strap and waist belt. ► Place battery on your back. ► Take the battery off your back. Fitting the Deluxe Carrying System The deluxe carrying system serves to secure the blower to the STIHL AR L or AR battery. 0458-812-0121-A...
  • Page 14 English 6 Adjusting Blower for User ► Take out the screws (1). ► Fit the holder (2). ► Insert and tighten down the screws (1) firmly. ► Close the retainer (3). The retainer (3) snaps into place. The belt is between the retainer (3) and the deluxe carrying system.

  • Page 15: Using With Carrying System

    English 6 Adjusting Blower for User ► Take out the screw (7). The connecting cable can be fitted through the following openings: ► Adjust plate (8) to suit user’s height. – the upper left opening (1) ► Insert and tighten down the screw (7) firmly. –...

  • Page 16: Fitting The Hip Pad

    Fitting the Hip Pad The hip pad serves to secure the blower to the STIHL AR L ► Close buckle (2) on the waist belt. or AR battery or the carrying system with built-in “AP belt bag with connecting cable”.

  • Page 17: Using With Battery Belt

    English 6 Adjusting Blower for User Using with Battery Belt 6.7.1 Attaching the “Belt bag AP with connecting cord” ► Push battery (4) as far as it will go into the belt bag (5). A short beep will sound. ► Secure battery (4) with the Velcro® fastening (6). ►...

  • Page 18: Inserting And Removing Connecting Cable Plug

    ► Grip the connecting cable plug (2) with your hand. ► If air continues to flow from nozzle: Pull connecting cable plug out of the socket and contact your STIHL dealer for ► Pull the plug (2) out of the socket (1).

  • Page 19: Checking The Blower

    English 9 Checking the Blower ► If air continues to flow from nozzle: Pull connecting cable 9 Checking the Blower plug out of the socket and contact your STIHL dealer for assistance. Blower has a malfunction. Checking the Controls 10 Operating the Blower Trigger ►...

  • Page 20: Activating And Deactivating The Power Lock

    English 10 Operating the Blower ► Select the power level. ► Use trigger (1) to adjust blowing force. ► Depress the power lock button (2). This locks the blowing force in that position. You can let go of the trigger. To deactivate the power lock, depress the power lock button (2) again.

  • Page 21: Blow-Sweeping

    12.1 Transporting the Blower Every 12 months ► Switch off the blower and pull the connecting cable plug ► Have the blower checked by a STIHL servicing dealer. out of the socket. ► Carry the blower by the control handle.

  • Page 22: Troubleshooting

    ► Recharge the battery fully as described in the when switched on green. instruction manual for the STIHL AL 101, 300, 500 chargers. 1 LED glows red. Battery too hot or too cold. ► Pull the connecting cable plug out of the socket.
  • Page 23 ► If blower continues to cut out during operation: Clean contacts of connecting cable as described in the STIHL AR battery’s instruction manual or in the user instructions for the “AP belt bag with connecting cable”. ► Switch on the blower.

  • Page 24: Specifications

    2002/44/EC visit www.stihl.com/vib. – Approved batteries: – STIHL AR 17.3 REACH – STIHL AP together with “AP belt bag with connecting REACH is an EC regulation and stands for the Registration, cable” Evaluation, Authorisation and Restriction of Chemical – Blowing force: 21 N substances.
  • Page 25 Directive 2000/14/EC, Annex V. – Measured sound power level: 91 dB(A) – Guaranteed sound power level: 93 dB(A) Technical documents are deposited at ANDREAS STIHL AG & Co. KG Produktzulassung (Product Licensing). The year of manufacture, country of manufacture and serial number are applied to the product.
  • Page 26 English 20 EC Declaration of Conformity 0458-812-0121-A...
  • Page 28 0458-812-0121-A englisch www.stihl.com *04588120121A* 0458-812-0121-A...
