PLEASE READ THIS FIRST
CN1074 & CN1074A Bell47G II Detail Manual Updates
Step 12
The direction of the landing gear mounts are backwards in the original instructions, when attaching the hori-
zontal straight struts to the plastic vertical struts, make sure that the mounting tabs are pointing inwards. Oppo-
site to what is shown in the photo.
Step 14
The photo showing the landing gear mounted to the mechanics is backwards, see Step 12 and replace the
original four self tapping screws with M3x12 self tapping screws.
Step 18
Two M2x8 are provided as they are missing from the hardware for this step.
PLEASE READ THIS FIRST
CN1074 & CN1074A Bell47G II Detail Manual Updates
Step 12
The direction of the landing gear mounts are backwards in the original instructions, when attaching the hori-
zontal straight struts to the plastic vertical struts, make sure that the mounting tabs are pointing inwards. Oppo-
site to what is shown in the photo.
Step 14
The photo showing the landing gear mounted to the mechanics is backwards, see Step 12 and replace the
original four self tapping screws with M3x12 self tapping screws.
Step 18
Two M2x8 are provided as they are missing from the hardware for this step.
PLEASE READ THIS FIRST
CN1074 & CN1074A Bell47G II Detail Manual Updates
Step 12
The direction of the landing gear mounts are backwards in the original instructions, when attaching the hori-
zontal straight struts to the plastic vertical struts, make sure that the mounting tabs are pointing inwards. Oppo-
site to what is shown in the photo.
Step 14
The photo showing the landing gear mounted to the mechanics is backwards, see Step 12 and replace the
original four self tapping screws with M3x12 self tapping screws.
Step 18
Two M2x8 are provided as they are missing from the hardware for this step.
Advertisement
Related Manuals for Century Helicopter Products Bell 47G II ARF Helicopter
Summary of Contents for Century Helicopter Products Bell 47G II ARF Helicopter
- Page 1 PLEASE READ THIS FIRST CN1074 & CN1074A Bell47G II Detail Manual Updates Step 12 The direction of the landing gear mounts are backwards in the original instructions, when attaching the hori- zontal straight struts to the plastic vertical struts, make sure that the mounting tabs are pointing inwards. Oppo- site to what is shown in the photo.
- Page 2 MAIN ROTOR DIAMETER 53.5” 53.5” HEIGHT HEIGHT HEIGHT 16.25” 16.25” 16.25” HEIGHT HEIGHT 16.25” 16.25” LENGTH LENGTH 50” 50” LENGTH LENGTH LENGTH 50” 50” 50” Century Helicopter Products Designed and Developed in USA 1st Edition May, 2002 All rights reserved.
-
Page 3: Pre-Assembly Information
Building Instructions for: Building Instructions for: Building Instructions for: Building Instructions for: Building Instructions for: CN1074 Bell 47G II ARF Helicopter CN1074A Bell 47G II Conversion Kit Introduction Introduction Introduction Introduction Introduction Congratulations on your purchase of Century Helicopter Product's scale RC Bell 47G II helicopter model. -
Page 4: Recommended Tools & Accessories
Bell 47G II Construction Manual This manual has been written for Century’s 50 size Bell 47G II scale helicopter available in ARF version and conversion kit. This is the detail construction of the Bell 47G II helicopter fuselage compo- nents, landing gear, tailboom assembly which work in cooperation with the scale mechanics instruc- tion manual. - Page 5 Updates to Steps in the Scale Mechanics Manual Updates to Steps in the Scale Mechanics Manual Updates to Steps in the Scale Mechanics Manual Updates to Steps in the Scale Mechanics Manual Updates to Steps in the Scale Mechanics Manual The following Step numbers are referrenced from the steps in the main Scale Mechanics Manual.
- Page 6 Fiberglass Preparation Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual Prepare the fiberglass, wash all parts in warm water with mild detergent to remove all residue used in the molding process and let them dry completely.
- Page 7 STEP 4 Drilling Components STEP 4 Drilling Components STEP 4 Drilling Components STEP 4 Drilling Components STEP 4 Drilling Components Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual Hinges and door pivot locks must be drilled when on the sheet material.
- Page 8 Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual STEP 7 Door Hardware & Mounting STEP 7 Door Hardware & Mounting STEP 7 Door Hardware & Mounting STEP 7 Door Hardware & Mounting STEP 7 Door Hardware &...
- Page 9 Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual STEP 9 Cabin & Fuel Tank Mount Hardware STEP 9 Cabin & Fuel Tank Mount Hardware STEP 9 Cabin & Fuel Tank Mount Hardware STEP 9 Cabin &...
- Page 10 Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual STEP 12 Landing Gear STEP 12 Landing Gear STEP 12 Landing Gear Bell47G II Detail Manual Bell47G II Detail Manual STEP 12 Landing Gear STEP 12 Landing Gear Insert all the M3x4 Set Screws into the landing gear components.
- Page 11 Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual STEP 15 Drive Shaft Housing, Guides & Tail Beacon STEP 15 Drive Shaft Housing, Guides & Tail Beacon STEP 15 Drive Shaft Housing, Guides & Tail Beacon STEP 15 Drive Shaft Housing, Guides &...
- Page 12 Bell47G II Detail Manual Bell47G II Detail Manual STEP 18 Tail Wire Skid STEP 18 Tail Wire Skid Bell47G II Detail Manual Bell47G II Detail Manual Bell47G II Detail Manual STEP 18 Tail Wire Skid STEP 18 Tail Wire Skid STEP 18 Tail Wire Skid Loosen the end M3x10 Socket Cap Screw and insert the tail wire into the hole in the end of the gear box.
- Page 13 Landing Skid Set (Aluminum) with Caps .. 2 CN1074-20 Landing Strut Set ........2 CN1074-21 Landing Gear Set Complete ...... 1 CN1074-22 Decal Set ..........1 Century Helicopter Products 523 Sinclair Frontage Rd., Milpitas, CA 95035 USA Fax:1-408-942-9524 www.centuryheli.com email: info@centuryheli.com...
- Page 14 Bell47G II Scale Accessory Kit #CN1074B The scale accessory kit includes the key items to really make your Bell47G II super scale. The bottom plate positions the fuel tank facing backwards slim- ming the mechanics while the scale side frame extend up to the servo tray. The front mount muffler is now elegantly hidden below the battery tray.
- Page 15 Left side scale Mount plate frame has only M3x10 SHCS one diagonal M3x12 Self Tap brace. [CN1074C] Throttle arm needs to be re- positioned to Pressure Fitting avoid touching [CN1074C] the vertical brace. Muffler, Header & Coupler [CN1074C] 6. Attach the engine header, the silicon coupler and the muffler but do not attach the cable ties at this time.
