Accessories; Standard Accessories; Optional Accessories; Branch Joint Of Outdoor & Indoor Unit - Midea VRF V4 Plus I Series Manual

R410A DC Inverter VRF V4 Plus Individual Series 50Hz

10. Accessories

10.1 Standard accessories

Name
Outdoor unit installation manual
Outdoor unit owner's manual
Indoor unit owner's manual
Accessory screw bag
Toggling flathead screw
Gauge point subassembly
90° mouthing elbow
Seal plug
Connecting pipe subassembly

10.2 Optional accessories

Branch joint of outdoor & indoor unit
Optional accessories
Branch Joint of outdoor
unit
Branch Joint of indoor
unit
Other optional accessories
Optional accessories
Outdoor controller
Three phase electricity power
protector
Digital ammeter (WHM)
56
Model name Packing Size (mm)
FQZHW-02N1D
FQZHW-03N1D
FQZHW-04N1D
FQZHN-01D
FQZHN-02D
FQZHN-03D
FQZHN-04D
FQZHN-05D
Model name
MD-CCM02/E
DPA51CM44
or
HWUA/DPB71CM48
DTS634/DT636
Shape Quantity
1
1
1
1
1
2
1
4×2
1
Gross Weight (kg)
255×150×185
345×160×285
475×165×300
290×105×100
290×105×100
310×130×125
350×180×170
365×195×215
Function
Monitor the outdoor operating parameter
To stop the air-conditioner running in case of bad power
supply such as Phase Error, Over-voltage, Under-voltage
lose, phase lost and phase sequence inverse. Thus to protect
the equipment.
Electricity Charge monitor
MCAC-VTSM-2014-04
Function
This manual
/
/
Be used in maintenance
For toggling of indoor and outdoor units
For purpose of airtight test
For connecting pipes
Be used for cleaning pipe
For connecting liquid side
1.5
3.4
4.8
Distribute the refrigerant to
0.4 Indoor Units and balance the
0.6 resistance
outdoor unit.
0.9
1.5
1.9
Specifications & Performances
Function
between each
