Summary of Contents for Daikin BRP069C51
- Page 1 Installer reference guide Wireless LAN connecting adapter BRP069C51...
-
Page 2: Table Of Contents
About opening the adapter..........................11 5.7.2 To open the adapter............................11 6 Starting up the system 7 Configuration To install the Daikin Residential Controller application ....................13 To configure the adapter ..............................13 8 Hand-over to the user 9 Troubleshooting Overview: Troubleshooting ............................15 9.1.1... -
Page 3: About This Document
▪ Declaration of conformity: INFORMATION: Declaration of conformity Hereby, Daikin Industries Czech Republic s.r.o. declares that the radio equipment type BRP069C41 is in compliance with the Directive 2014/53/EU. The original declaration of conformity is available from http://www.daikineurope.com/support- and-manuals/product-information/. -
Page 4: Specific Installer Safety Instructions
In case you drop or damage the adapter, disconnect the indoor unit from its power supply. Otherwise, this can lead to fire or malfunction. If this happens, consult your dealer. BRP069C51 Installer reference guide Wireless LAN connecting adapter 4P626518-1 – 2020.05... -
Page 5: About The Adapter
About the adapter 3 About the adapter Wireless LAN adapter to connect the heat pump system to the Daikin Cloud via the internet, allowing for control of the heat pump system with the Daikin Residential Controller app. 3.1 Components RUN lamp (orange). Lights when connecting to a router (wireless LAN access point). -
Page 6: About The Box
Screws (M3×8) for the adapter Adapter holder with double face tape Mounting screws for the holder (M3×16) Cable tie mounting Cable tie Connection cable Serial number sticker (SSID, KEY, MAC) Installation manual BRP069C51 Installer reference guide Wireless LAN connecting adapter 4P626518-1 – 2020.05... -
Page 7: Installation
In places where it is near a heat source. ▪ In places where it is exposed to a source of steam. ▪ In places where it is exposed to machine oil vapour. BRP069C51 Installer reference guide Wireless LAN connecting adapter 4P626518-1 – 2020.05... -
Page 8: Connecting The Electrical Wiring
Do NOT turn on the power supply before you have connected the electrical wiring, closed the adapter, and mounted it to the indoor unit. 5.4.4 To connect the adapter with the unit 1 Separate the upper casing from the lower casing. BRP069C51 Installer reference guide Wireless LAN connecting adapter 4P626518-1 – 2020.05... -
Page 9: Closing The Adapter
5.5 Closing the adapter 5.5.1 To close the adapter 1 Hook the front casing into the rear casing. 2 Insert the two screws from the accessory bag. 2× BRP069C51 Installer reference guide Wireless LAN connecting adapter 4P626518-1 – 2020.05... -
Page 10: Mounting The Adapter
When using screws 1 Fix the adapter holder on the wall/surface with 2 screws M3×16 (accessory). 2 Slide the adapter into the holder. Screw locations Adapter holder BRP069C51 Installer reference guide Wireless LAN connecting adapter 4P626518-1 – 2020.05... -
Page 11: Opening The Adapter
Before opening the adapter, turn OFF the power to the indoor unit. 5.7.2 To open the adapter 1 Remove the screws with a screwdriver. 2× 2 Unhook the front casing from the rear casing. BRP069C51 Installer reference guide Wireless LAN connecting adapter 4P626518-1 – 2020.05... -
Page 12: Starting Up The System
The adapter gets its power from the indoor unit. For the adapter to function, make sure it is connected to the indoor unit, and the indoor unit is powered on. Turn on the power supply and check that the RUN lamp of the product blinks. BRP069C51 Installer reference guide Wireless LAN connecting adapter... -
Page 13: Configuration
▪ App Store for appliances using iOS. 2 Search for Daikin Residential Controller. 3 Follow the directions on the screen to install. 7.2 To configure the adapter Open the Daikin Residential Controller application on your smartphone or tablet PC and follow the in-app instructions. http://www.onlinecontroller.daikineurope.com/ BRP069C51... -
Page 14: Hand-Over To The User
Otherwise, this can lead to fire or malfunction. If this happens, consult your dealer. NOTICE Do not use the adapter near microwave ovens. This can affect wireless LAN communications. BRP069C51 Installer reference guide Wireless LAN connecting adapter 4P626518-1 – 2020.05... -
Page 15: Troubleshooting
9.1.3 Symptom: Nothing happens when the adapter is in AP mode Possible causes Corrective action The firmware is corrupted. Contact your dealer to report the firmware issue. BRP069C51 Installer reference guide Wireless LAN connecting adapter 4P626518-1 – 2020.05... - Page 16 4P626518-1 2020.05 Verantwortung für Energie und Umwelt...
