Daikin BRP069A61 Installation Manual
Altherma lan adapter
Hide thumbs
Also See for BRP069A61:
- Installer's reference manual (16 pages) ,
- Installer's reference manual (24 pages) ,
- Installation manual (12 pages)
Related Manuals for Daikin BRP069A61
Summary of Contents for Daikin BRP069A61
- Page 1 Installation manual Daikin Altherma LAN adapter Installation manual BRP069A61 English Daikin Altherma LAN adapter BRP069A62...
-
Page 2: Table Of Contents
Table of Contents ▪ The full set of latest technical data is available on the Daikin Table of Contents extranet (authentication required). About the product 1 About the documentation About this document..............The Daikin Altherma LAN adapter allows for smartphone control of... -
Page 3: About The Box
LAN adapter. Installation manual This LED is only active for BRP069A61 (present for 2-pole plug connector for X3A BRP069A62, but always inactive). Ethernet cable Grommet Screws to mount rear casing... -
Page 4: Overview Of Electrical Connections
To router Connector X1A is for the connection of the LAN adapter to the digital inputs of a solar inverter / energy management system, and allows for use of the Daikin Altherma system in various Smart Grid Connections applications. Connection... -
Page 5: To Mount The Rear Casing To The Wall
(c). 3 Mount the rear casing to the wall with the screws and plugs from the accessory bag. 3× Mounting holes 3× Bottom knockout holes Rear knockout holes BRP069A61+BRP069A62 Installation manual Daikin Altherma LAN adapter 4P463935-1C – 2017.08... -
Page 6: To Mount The Pcb To The Rear Casing
1 When entering the wiring from the bottom: inside the LAN adapter casing, ensure strain relief by routing the cable along the indicated cable path. 2 Connect indoor unit terminals X5M/1+2 to LAN adapter terminals X3A/1+2. Installation manual BRP069A61+BRP069A62 Daikin Altherma LAN adapter 4P463935-1C – 2017.08... -
Page 7: To Connect The Digital Inputs
3 For the system to run in the "Recommended ON" operation installer reference guide. mode (Smart Grid application), connect the digital input to the X1A/1+2 LAN adapter digital input. BRP069A61+BRP069A62 Installation manual Daikin Altherma LAN adapter 4P463935-1C – 2017.08... - Page 8 4P463935-1 C 00000002 4P463935-1C 2017.08...
