- Page 1 GRILL ASSEMBLY Step 1: Attach Legs to Firebox Back Left Leg Front Right Leg (16) Hex Bolt --1/4”-20 x 1/2” Front Left Leg Back Right Leg Hex Bolt Step 2: Attach Bottom Shelf Bottom Shelf (4) Hex Bolt --1/4”-20 x 1/2” Hex Bolt OM9020A.2...
- Page 2 Step 3: Attach Caster Wheels Caster Wheels Step 4: Attach Metal Wheels Metal Wheel (2) Flat Washer Flat Washer (2) Hex Nut—7/16”-20 Hex Nut OM9020A.2...
- Page 3 Step 5: Attach Lid Stopper Hex Bolt Lid Stopper (1) Hex Bolt --1/4”-20 x 1/2” Step 6: Attach Lid Handle Lid Handle Handle Bezels (2) Hex Bolt --1/4”-20 x 1/2” Hex Bolts OM9020A.2...
- Page 4 Step 7: Attach Chimney Chimney Hex Bolts Hex Nut—1/4”-20 (2) Hex Bolt --1/4”-20 x 1/2” Gasket (2) Hex Nut—1/4”-20 Step 8: Attach Trolley Handle (4) Hex Bolt --1/4”-20 x 1/2” Hex Bolt Trolley Handle OM9020A.2...
- Page 5 Step 9: Place Heat Diffuse Shield Inside Firebox Heat Diffuse Shield Step 10: Place Grease Tray onto Grease Channel Grease Channel Grease Tray OM9020A.2...
- Page 6 Step 11: Place Cooking Grates into Firebox Cooking Grates Step 12: Hang Grease Bucket on hinge of grease tunnel Grease Bucket OM9020A.2...
