Transformer
®
Owner's Manual
INSTALLERS: PLEASE LEAVE THIS
MANUAL WITH THE OWNER.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Transformer and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Screen Innovations Transformer

Summary of Contents for Screen Innovations Transformer

  • Page 1 Transformer ® Owner’s Manual INSTALLERS: PLEASE LEAVE THIS MANUAL WITH THE OWNER.
  • Page 2 Innovations’ option) the defective part of the merchandise. Returns for service should be made to your Screen Innovations’ dealer. If it is necessary for the dealer to return the screen or part to Screen Innovations, transportation expenses to and from Screen Innovations are payable by the purchaser and Screen Innovations is not responsible for damage in shipment.
  • Page 3 TRANSFORMER Installation requires 3 or more people. Bend knees when lifting. 512-832-6939 9715-B Burnet Road Suite 400, Austin,TX 78758 screeninnovations.com 09092019TRA...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS TRANSFORMER PROJECTOR PLACEMENT � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5 BEFORE PROCEEDING �...
  • Page 5 PROJECTOR PLACEMENT TRANSFORMER 09092019TRA...

  • Page 6: Before Proceeding

    TRANSFORMER BEFORE PROCEEDING CAUTION: READ THE INSTRUCTIONS IN THEIR ENTIRETY BEFORE PROCEEDING. ACTIONS CONTRARY TO THE INSTRUCTIONS INVALIDATE THE WARRANTY AND MAY RESULT IN SERIOUS DAMAGE AND/OR INJURY. INSTALLER: END USER: • The wall used for fixture installation must be able to •...

  • Page 7: Parts List

    TRANSFORMER PARTS LIST NOTE: Unpack the long cardboard box first and check to make sure everything listed is included. HARDWARE BOX 20X to 30X #10-32 3/16’’ & 1/8’’ 1/4-20 Power Cord 1/4’’ Lag Gloves Flat Head Top-Snapper Hex Key Screws...
  • Page 8 TRANSFORMER PARTS LIST CRATE Lef t Wing Trim Assembly Leave in plastic bag Right Wing Trim Assembly Leave in plastic bag Screen Material Leave in tube Left Frame Assembly Right Frame Assembly...

  • Page 9: Prepare The Installation Location

    TRANSFORMER PREPARE THE INSTALLATION LOCATION INSTALLATION REQUIRES TWO OR MORE PEOPLE. PLEASE USE SAFE LIFTING AND RIGGING TECHNIQUES. THE RESTING POSITION FOR THE SCREEN IS IN THE FULLY OPEN 2.4:1 POSITION. THE SCREEN WILL RETURN TO THE THIS POSITION IF IT DOES NOT RECIEVE A SIGNAL FOR 8 HOURS OR WHEN THE ON/OFF TRIGGER GOES TO A LOW VOLTAGE.
  • Page 10 TRANSFORMER PREPARE THE INSTALLATION LOCATION SCREEN WEIGHS UP TO 500 LBS. MAKE SURE TO USE APPROPRIATE ANCHORS TO SAFELY SECURE WEIGHT OF SCREEN. 500 lbs (227 kg) 3 7/8’’ [98mm] Top of mounting bracket to top of image Top of Rough Opening 3 5/16’’...

  • Page 11: Mount The Frame

    TRANSFORMER MOUNT THE FRAME Remove the shipping brackets from the crate and the fist frame half. 09092019TRA...
  • Page 12 TRANSFORMER MOUNT THE FRAME INSTALLATION REQUIRES TWO OR MORE PEOPLE. PLEASE USE SAFE LIFTING AND RIGGING TECHNIQUES. Lift left frame half up onto the left end of the long wall bracket and make sure the brackets on the frame are in the lip on the wall bracket as shown.
  • Page 13 TRANSFORMER MOUNT THE FRAME INSTALLATION REQUIRES TWO OR MORE PEOPLE. PLEASE USE SAFE LIFTING AND RIGGING TECHNIQUES. Remove the right frame from the crate. Then lift up onto the right end of the long wall bracket and make sure the brackets on the frame are in the lip on the wall bracket as shown.
  • Page 14 TRANSFORMER MOUNT THE FRAME Push the frame halves together then secure with the 1/4-20 x 2 1/2’’ Screws.
  • Page 15 TRANSFORMER MOUNT THE FRAME Slide the lower mounting brackets left or right such that the holes align with a stud or structural support. Then secure to the stud with appropriate fasteners. Then tighten the screws on the back of the lower mounting brackets to lock in place.

  • Page 16: Connect The Power And Control Wiring

    TRANSFORMER CONNECT THE POWER AND CONTROL WIRING CONTROLS CONTROL JUNCTION BOX POWER SUPPLY SIFI WALL SWITCH TO LOCAL AREA NETWORK (LAN) CONTROL TRAY POWER TRAY CONNECT TO BUS IN DATAHUB AC POWER CONNECT LED POWER LED DC POWER LED IP CONTROLLER...
  • Page 17 TRANSFORMER CONNECT THE LED WIRING Connect the left side LED wiring to the right side LED wiring. 09092019TRA...

  • Page 18: Power

    TRANSFORMER POWER TO BE INSTALLED AND/OR USED IN ACCORDANCE WITH THE APPROPRIATE ELECTRICAL CODES AND REGULATIONS BY A LICENSED ELECTRICAL PROFESSIONAL. DO NOT CONNECT POWER WITH THE CIRCUIT BREAKER ON. Controls Junction box Wall Switch To Local Area Network Power Once controls have been connected;...
  • Page 19 POWER TRANSFORMER MAKE SURE THAT ALL BODY PARTS, TOOLS, AND WIRES ARE CLEAR OF ALL MOVING PARTS. Connect power to the circuit and wall switch. Press the 2.40:1 button on the wall switch to open the screen to it’s fully open position. The wall switch is the easiest most simple way to control the screen during setup and installation.
  • Page 20 TRANSFORMER CONTROLS All Transformer screens are fully configured from the factory. This means that the mo- tors and keypad are already programmed and ready for operation. The motors are pro- grammed into a single group so that they always operate simultaneously. When integrat- ing Transformer into a home automation system, always control the motor group rather than the individual motors.
  • Page 21 TRANSFORMER ATTACH SCREEN MATERIAL SPRING CABLES ARE UNDER TENSION. DO NOT LET GO OF HOOK UNTILL IT IS ATTACHED TO THE BAR IN THE SCREEN MATERIAL. IF SPRING CABLE BECOMES UNRAVELED AND SPRING TENSION IS LOST THEN PLEASE CONTACT SI AT 512- 832-6939 FOR ASSISTANCE.
  • Page 22 TRANSFORMER ATTACH SCREEN MATERIAL SPRING CABLES ARE UNDER TENSION. DO NOT LET GO OF HOOK UNTILL IT IS ATTACHED TO THE BAR IN THE SCREEN MATERIAL. IF SPRING CABLE BECOMES UNRAVELED AND SPRING TENSION IS LOST THEN PLEASE CONTACT SI AT 512- 832-6939 FOR ASSISTANCE.
  • Page 23 TRANSFORMER ATTACH SCREEN MATERIAL Continue snapping the material into the frame untill all the right side moving snaps are attached to the screen material. Then use the top snapper to attach the screen material to the first fixed snaps in the main frame piece.

  • Page 24: Attach Screen Material

    TRANSFORMER ATTACH SCREEN MATERIAL SNAP SNAP Remove the screen material from the cardboard tube. Remove the tape securing the snaps to the ends of the frame .Then snap into the moving snaps located on the far right side of the screen assembly working left. One installer should be available to hold the rolled up screen material upright and unroll as another installer snaps the screen into the frame.
  • Page 25 TRANSFORMER ATTACH SCREEN MATERIAL Continue attaching the screen material to the frame working to the opposite end of the frame. When snapping into the fixed snaps make sure to put enough horizontal tension between the new snap and the previous snap to make the material lay flat. Once all snaps have been attached go back and adjust the snaps in the fixed frame portion to make the screen lies flat.

  • Page 26: Attach The Trim

    TRANSFORMER ATTACH THE TRIM Remove the wing trim from the crate by removing the shipping brackets from the crate and then removing the shipping brackets from the wing trim assemblies.
  • Page 27 TRANSFORMER ATTACH THE TRIM NOTE: The trim is put on to the fame such that the coiled cable for the lights is at the top. Slide the wing trim pieces on to the main screen assembly untill it hits the bumper on the end of the frame.
  • Page 28 TRANSFORMER ATTACH THE TRIM Stretch the coiled cable on the top of wing trim pieces to the port on the frame. Slide the black strain relief in into the slot and then plug the cable into the port.
  • Page 29 TRANSFORMER ATTACH THE TRIM NOTE: The bottom trim piece is the piece with the IR eye dome connected to it. Place the bottom trim just below the bottom of the screen and lug in the phone jack connected to the LED in to the port mounted to the bottom of the frame.
  • Page 30 TRANSFORMER ATTACH THE TRIM Lift up the trim and slide to the LEFT untill the blocks line up and the plunger clicks into place to secure the trim. The trim is correctly installed when the trim will no longer slide back to the right.
  • Page 31 TRANSFORMER ATTACH THE TRIM Connect the lights to the port at the top. Then rest the trim on frame and slide to the RIGHT untill the blocks line up and the plunger clicks into place to the secure the trim.

  • Page 32: Led Ip Instructions

    LED IP Setup Instructions TRANSFORMER LED IP INSTRUCTIONS Initial Set up Before attempting to connect your LED IP to Phillips Hue, ensure that the Hue Bridge is powered on and connected to the local Wi-Fi® network. 1. Begin by connecting the power supply to an electrical outlet. After a few seconds, the LEDs should power on to a white color.

  • Page 33: Screen Material Cleaning Instructions

    TRANSFORMER SCREEN MATERIAL CLEANING INSTRUCTIONS NEVER SCRUB, USE SOLVENTS, OR ANY ABRASIVE SUVSTANCE THAT MIGHT DAMAGE THE MATERIAL. Slate & Pure ® ® Suggested Method: Alternate Method: Microfiber cloth towel Can be cleaned with a and distilled water microfiber cloth. Mix a...
  • Page 34 TRANSFORMER NOTES: 9715-B Burnet Road Suite 400, Austin,TX 78758 Tel: 512-832-6939 Fax: 512-832-6136 www.screeninnovations.com...
  • Page 35 TRANSFORMER NOTES: 9715-B Burnet Road Suite 400, Austin,TX 78758 Tel: 512-832-6939 Fax: 512-832-6136 www.screeninnovations.com 09092019TRA...
  • Page 36 TRANSFORMER NOTES: 9715-B Burnet Road Suite 400, Austin,TX 78758 Tel: 512-832-6939 Fax: 512-832-6136 www.screeninnovations.com...
