Transformer
®
Owner's Manual
INSTALLERS: PLEASE LEAVE THIS
MANUAL WITH THE OWNER.
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Transformer and is the answer not in the manual?

Questions and answers

Related Manuals for Screen Innovations Transformer

Summary of Contents for Screen Innovations Transformer

  • Page 1 Transformer ® Owner’s Manual INSTALLERS: PLEASE LEAVE THIS MANUAL WITH THE OWNER. ®...
  • Page 2 Innovations’ option) the defective part of the merchandise. Returns for service should be made to your Screen Innovations’ dealer. If it is necessary for the dealer to return the screen or part to Screen Innovations, transportation expenses to and from Screen Innovations are payable by the purchaser and Screen Innovations is not responsible for damage in shipment.
  • Page 3 TRANSFORMER Installation requires 3 or more people. Bend knees when lifting. 512-832-6939 9715-B Burnet Road Suite 400, Austin,TX 78758 screeninnovations.com 07052017TRB...

  • Page 4: Table Of Contents

    TRANSFORMER TABLE OF CONTENTS PROJECTOR PLACEMENT � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5 BEFORE PROCEEDING �...

  • Page 5: Projector Placement

    PROJECTOR PLACEMENT TRANSFORMER Better 11° Best 11° Good 36”-42” (91cm - 106cm) 07052017TRB...

  • Page 6: Before Proceeding

    TRANSFORMER BEFORE PROCEEDING CAUTION: READ THE INSTRUCTIONS IN THEIR ENTIRETY BEFORE PROCEEDING. ACTIONS CONTRARY TO THE INSTRUCTIONS INVALIDATE THE WARRANTY AND MAY RESULT IN SERIOUS DAMAGE AND/OR INJURY. INSTALLER: END USER: • The wall used for fixture installation must be able to •...

  • Page 7: Parts List

    TRANSFORMER PARTS LIST NOTE: Unpack the long cardboard box first and check to make sure everything listed is included. HARDWARE BOX 20X to 30X #10-32 1/8’’ Hex Key Power Cord 1/4’’ Lag Gloves Flat Head Top-Snapper Screws Screws SPARE PARTS...
  • Page 8 TRANSFORMER PARTS LIST CRATE Right Wing Trim Assembly Leave in plastic bag Lef t Wing Trim Assembly Leave in plastic bag Assembled Screen...

  • Page 9: Unpack The Assembled Screen

    TRANSFORMER UNPACK THE ASSEMBLED SCREEN INSTALLATION REQUIRES TWO OR MORE PEOPLE. PLEASE USE SAFE LIFTING AND RIGGING TECHNIQUES. WEAR GLOVES TO PREVENT DAMAGING THE SCREEN MATERIAL. LIFT FROM THE FRAME PIECES NOT THE SCREEN MATERIAL. Remove the shipping brackets from the crate and the assembled screen.

  • Page 10: Prepare The Installation Location

    TRANSFORMER PREPARE THE INSTALLATION LOCATION INSTALLATION REQUIRES TWO OR MORE PEOPLE. PLEASE USE SAFE LIFTING AND RIGGING TECHNIQUES. THE RESTING POSITION FOR THE SCREEN IS IN THE FULLY OPEN 2.4:1 POSITION. THE SCREEN WILL RETURN TO THE THIS POSITION IF IT DOES NOT RECIEVE A SIGNAL FOR 8 HOURS OR WHEN THE ON/OFF TRIGGER GOES TO A LOW VOLTAGE.
  • Page 11 TRANSFORMER PREPARE THE INSTALLATION LOCATION SCREEN WEIGHS UP TO 500 LBS. MAKE SURE TO USE APPROPRIATE ANCHORS TO SAFELY SECURE WEIGHT OF SCREEN. 500 lbs (227 kg) 3 7/8’’ [98mm] Top of mounting bracket to top of image Top of Rough Opening 3 5/16’’...

  • Page 12: 3Rd Party Controls Connections

    TRANSFORMER 3RD PARTY CONTROLS CONNECTIONS ONLY REMOVE THE CONTROLS COVER IF USING THE SERIAL PORT, LENSE TRIGGER, OR PROJECTOR TRIGGER. IF ONLY THE IR REMOTE WILL BE USE THEN THIS STEP IS NOT NECESARRY. RJ45 RS232 SERIAL INPUT 1/8’’ LENSE TRIGGER INPUT 1/8’’...

  • Page 13: Plug In Power

    TRANSFORMER PLUG IN POWER TO BE INSTALLED AND/OR USED IN ACCORDANCE WITH THE APPROPRIATE ELECTRICAL CODES AND REGULATIONS BY A LICENSED ELECTRICAL PROFES- SIONAL. DO NOT CONNECT POWER WITH THE CIRCUIT BREAKER ON. SCREEN WILL OPEN WHEN POWER IS TURNED ON. MAKE SURE THAT ALL BODY PARTS, TOOLS, AND WIRES ARE CLEAR OF ALL MOVING PARTS.

  • Page 14: Mount The Assembled Screen

    TRANSFORMER MOUNT THE ASSEMBLED SCREEN INSTALLATION REQUIRES TWO OR MORE PEOPLE. PLEASE USE SAFE LIFTING AND RIGGING TECHNIQUES. WEAR GLOVES TO PREVENT DAMAGING THE SCREEN MATERIAL. LIFT FROM THE FRAME PIECES NOT THE SCREEN MATERIAL. Lift the screen assembly up from the bottom metal frame onto the long wall bracket and make sure the brackets on the frame are in the lip on the wall bracket as shown.
  • Page 15 TRANSFORMER MOUNT THE FRAME Slide the lower mounting brackets left or right such that the holes align with a stud or structural support. Then secure to the stud with appropriate fasteners. Then tighten the screws on the back of the lower mounting brackets to lock in place.
  • Page 16 CONNECT POWER TRANSFORMER SCREEN WILL OPEN WHEN POWER IS TURNED ON. MAKE SURE THAT ALL BODY PARTS, TOOLS, AND WIRES ARE CLEAR OF ALL MOVING PARTS. Connect power to the circuit and let the screen open to it’s fully open position.
  • Page 17 TRANSFORMER ADJUST SCREEN MATERIAL Plug in the IR eye for control of the screen. Press the 16:9 button to close the screen, and adjust the fixed snaps to make the screen flat. You may need to move the outermost fixed snaps in to make the screen flat at the transition, then adjust snaps working towards middle to make the screen flat.Cycle the screen several times between...

  • Page 18: Attach The Trim

    TRANSFORMER ATTACH THE TRIM Remove the wing trim from the crate by removing the shipping brackets from the crate and then removing the shipping brackets from the wing trim assemblies.
  • Page 19 TRANSFORMER ATTACH THE TRIM NOTE: The trim is put on to the fame such that the coiled cable for the lights is at the top. Slide the wing trim pieces on to the main screen assembly untill it hits the bumper on the end of the frame.
  • Page 20 TRANSFORMER ATTACH THE TRIM Stretch the coiled cable on the top of wing trim pieces to the port on the frame. Slide the black strain relief in into the slot and then plug the cable into the port.
  • Page 21 TRANSFORMER ATTACH THE TRIM NOTE: The bottom trim piece is the piece with the IR eye dome connected to it. Place the bottom trim just below the bottom of the screen and connect the IR eye mono jack into the port hanging from the bottom of the screen. Plug in the phone jack connected to the LED in to the port mounted to the bottom of the frame.
  • Page 22 TRANSFORMER ATTACH THE TRIM Lift up the trim and slide to the LEFT untill the blocks line up and the plunger clicks into place to secure the trim. The trim is correctly installed when the trim will no longer slide back to the right.
  • Page 23 TRANSFORMER ATTACH THE TRIM Connect the lights to the port at the top. Then rest the trim on frame and slide to the RIGHT untill the blocks line up and the plunger clicks into place to the secure the trim.

  • Page 24: Low Voltage Triggers (Optional)

    TRANSFORMER LOW VOLTAGE TRIGGERS (OPTIONAL) Tip DC +5V to +12V 50mA min Shielded 2 Conductor wiring Sleeve 18 Gauge or Larger 65ft (20 m) Max Projector ON/OFF Trigger • Screen will move to the Preset 1 position (factory set to 16:9) when trigger transfers from low to high voltage.

  • Page 25: Rs232 Serial Control (Optional)

    RS232 SERIAL CONTROL (OPTIONAL) TRANSFORMER PIN 1 RXD PIN 6 GND PIN 8 RJ45 MALE PLUG TAB UNDERNEATH Command Action Description Screen moves to preset 1 position (factory set to 16:9). Screen moves to preset 2 position (factory set to 1.85:1).

  • Page 26: Ir Control

    IR CONTROL TRANSFORMER ONLY USE THE IR RECIEVER PROVIDED BY SI WTIH THE SHIPMENT. THE IR RECIEVER IS INSTALLED IN THE TRIM PIECE AND CONNECTED TO THE 1/8’’ STEREO JACK IN THE CONTROLLER AS ONE OF THE LAST STEPS OF INSTALLATION.
  • Page 27 TRANSFORMER IR CONTROL Preset Setting Mode Button Action Description Press 16:9 Save current aspect ratio position into preset 1. 1.85 Save current aspect ratio position into preset 2. 2.35 Save current aspect ratio position into preset 3. Save current aspect ratio position into preset 4.
  • Page 28 TRANSFORMER IR CONTROL (3RD PARTY) IR Hex Codes The following RS1 protocol codes are provided in pronto hex code format to be used when programming a 3rd party universal IR remote or control system. See remote’s manufacturer for instructions on how to use the codes.

  • Page 29: Led Control

    TRANSFORMER LED CONTROL Increase / Decrease Brightness Discrete OFF / ON Increase / Decrease Speed of QUICK Pre-programmed Sequence QUICK SLOW SLOW Color Pre-programmed AUTO Keys Sequences DIY 1 DIY 2 DIY 3 AUTO FLASH DIY 4 DIY 5 DIY 6...
  • Page 30 TRANSFORMER LED CONTROL LED Lighting Hex Codes 20 13 20 13 20 13 20 13 5C A3 5D A2 41 BE 40 BF 20 13 20 13 20 13 20 13 58 A7 59 A6 45 BA 44 BB 20 13...

  • Page 31: Screen Material Cleaning Instructions

    TRANSFORMER SCREEN MATERIAL CLEANING INSTRUCTIONS NEVER SCRUB, USE SOLVENTS, OR ANY ABRASIVE SUVSTANCE THAT MIGHT DAMAGE THE MATERIAL. Slate & Pure ® ® Suggested Method: Alternate Method: Microfiber cloth towel Can be cleaned with a and distilled water microfiber cloth. Mix a...
  • Page 32 TRANSFORMER ® NOTES: 9715-B Burnet Road Suite 400, Austin,TX 78758 Tel: 512-832-6939 Fax: 512-832-6136 www.screeninnovations.com...
