OPERATOR'S MANUAL

Table of Contents

Need help?

Do you have a question about the Jersey Wheels and is the answer not in the manual?

Questions and answers

Summary of Contents for Bob's Space Racers Jersey Wheels

Page 1 Bob’s Space Racers Jennison Entertainment Technologies ® Inc. ©1976-2020 822 South Nova Road 427 Whac-A-Mole Way, Daytona Beach, Florida 32114 Holly Hill, Florida 32117 Phone - 1-(386)-255-1599 Phone - (386) 677-0761 Fax: 1-386-255-1589 Fax - (386) 677-4865 E-mail: Service@JennisonGames.com E-mail: tech@bobsspaceracers.com OPERATOR’S MANUAL...
Page 2: Table Of Contents
3.5 Solution B (Errors 11-14) …………………………………………….. 3-2 3.6 Motor Belt Errors …………………………………………………….. 3-2 3.7 Sensor Break or Home Break Error ………………………………….. 3-2 Chapter 4 : Option Settings – Jersey Wheels ……….…………………………………... 4-1 Chapter 5 : Service …………………………………………………..………………….. 5-1 5.1 Calling for Service ……………………………………………………. 5-1 Appendix A : Policies ……………………………………………………………..……….
Page 3: Introduction
A. Introduction A.1 Overview This manual contains information about the Arcade Game Jersey Wheels™, including: Setup, tools, instructions how to play, maintenance, tech tips, troubleshooting, game options settings, and service. Appendixes A-C contain information about policies, warranty, and service. Appendix D has a list part(s) pertaining to this specific game.
Page 4 Rear Cabinet Support Brace Mount Mounting Bolts Figure A.18 Figure A.19 Figure A.20 Sign Mounting Bolts | Wheel Mounting Bolts | Rear Cabinet Support Mounting Bolts Wrenches Figure A.21 Figure A.22 Power Cable Allen Keys Figure A.23 Figure A.24 Bob's Space Racers® Inc. ©1976-2019...
Page 5: Setup
B. Setup B.1 Steps to setup a Jersey Wheels™ game. Initial setup involves creating a location for the game. B.1.1 Assembling the game, see Section B.2. B.1.2 Make necessary game connections, see Section B.3. B.1.2 Hook up the power to the game.
Page 6 Figure B.5 Mounting Figure B.4 Bolts Figure B.3 Figure B.6 Figure B.7 Figure B.2 Figure B.8 Stabilizer Figure B.10 Figure B.9 Bob's Space Racers® Inc. ©1976-2019...
Page 7 Figure B.14 Figure B.13 Mounting Bolts Figure B.12 Figure B.15 Figure B.16 Figure B.11 Figure B.17 Stabilizer Figure B.19 Figure B.18 Bob's Space Racers® Inc. ©1976-2019...
Page 8: Hooking Up The Connections
B.3 Hooking up the Connections version of Jersey Wheels™ have cable which needs to be Depending on the 3-Wheel 4-Wheel connected. Each version will have the base cabinet and two wheels on top. The third wheel on a 3-Wheel Jersey Wheel™ from the second wheel to...
Page 9: Chapter 1 : Operator's Procedure
Kick up the game and watch the wheels spin. The bottom wheel will start first. Press the flashing button after it turns green. Land on the Bonus on each wheel to receive the ultimate number of tickets. 1.2 Operate / Race 3-Wheel Version Stops here. 4-Wheel Version Stops here. Bob's Space Racers® Inc. ©1976-2019...
Page 10: Chapter 2: Maintenance
Check to see that the turns on and initializes properly. 2.2.2.3 Check all lights. 2.2.2.4 Check each wheel for proper motion. 2.2.2.7 Check to see that all wheels and moving parts are work properly. Repair as needed. 2.2.2.8 Bob's Space Racers® Inc. ©1976-2019...
Page 11: Chapter 3: Troubleshooting
Indicates the motor belt for wheel #3 is either too loose BLT3 Belt Wheel #3 or too tight, adjust as necessary. Indicates the motor belt for wheel #4 is either too loose BLT4 Belt Wheel #4 or too tight, adjust as necessary. Bob's Space Racers® Inc. ©1976-2019...
Page 12: Sensor Break Or Home Break Error
Indicates that either the home position break or another Pin4 Pin (Break) Wheel #4 break is not being read on wheel #4. Check the location of the break and or check the sensor. Bob's Space Racers® Inc. ©1976-2019...
Page 13: Chapter 4: Option Settings - Jersey Wheels
4.1 Jersey Wheels IO Settings Version 3.1 Options for the Jersey Wheels are set by three dip switch blocks (SW1, SW2, SW3), see Figure 4.2 & 4.3). By flipping the white tab upwards towards the “ON”, as seen in Figure 4.1, will activate an option setting.
Page 15: Chapter 5: Service
Office Hours: 8:30AM – 5:00PM EST Has afterhours support, charges may apply. E-mail: Tech@bobsspaceracers.com EXCLUDING HOLIDAYS Visit Our Website for More Information WWW.BOBSSPACERACERS.COM “SUPPORT” page. A great resource on our website is the C USTOMER Bob's Space Racers® Inc. ©1976-2019...
Page 16: Appendix A: Policies
Warranty credit: if your game is under warranty. See the Warranty Policy page. A.2.2.1 Note: this credit does not include return shipping charges. Credit for the item(s). A.2.2.2 Note: this credit does not include return shipping charges, nor does it include the repair charges for the item(s). Bob's Space Racers® Inc. ©1976-2019...
Page 17: Appendix B: Warranty
No employee or representative of Bob’s Space Racers® Inc. or any other party is authorized to make any other warranty or to assume any other liability in connection with the sale of its equipment. Bob's Space Racers® Inc. ©1976-2019...
Page 18 Bob’s Space Racers® Inc. at 386-677-0761. B.2.5 Return the defective item(s) in the exact same packaging the Replacement item(s) came in. This insures no more damage will be done to the item(s) during the return shipping Thank You! Bob's Space Racers® Inc. ©1976-2019...
Page 19: Appendix C : Federal Communications Commission Statement
Note: All games from Bob’s Space Racers® Inc. are shipped with the same factory keys and lock sets. Bob’s Space Racers® Inc. recommends changing the keys and locks on your games upon receipt. Bob's Space Racers® Inc. ©1976-2019...
Page 20: Appendix D : Parts
Wheel Cover (Please Specify which Wheel Cover When Ordering) Wheels (Please Specify Which Wheel When Ordering) LED Lights (Please Specify When Ordering) Wheel Frame Front Border Set (Please Specify Which Wheel & Color When Ordering) Bob's Space Racers® Inc. ©1976-2019...
Page 21: Appendix E: Wire Diagram
Appendix E: Wire Diagram E.1 Wiring Diagram 4-Wheels 1 of 2 Figure E.1 Bob's Space Racers® Inc. ©1976-2019...
Page 33: Appendix F : Revision
Appendix F: Revision Information Revision Date of Revision Description of Revision Approved by July 28, 2017 Jack Cook August 21, 2017 1.1 Options 2.9 & Errors Jack Cook December 4, 2017 1.2 Options 3.1 Jack Cook Bob's Space Racers® Inc. ©1976-2019...
