©2011 Bob's Space Racers Incorporated

Table of Contents

MODEL VIEW ............................ 2
SPECIFICATIONS ..................... 3
Rated power supply: .............. 3
Power consumption: ............... 3
Dimensions:............................ 3
Weight: ................................... 3
INTRODUCTION ....................... 4
Overview ................................ 4
Features: ................................ 4
GAME PLAY .............................. 4
INFORMATION.......................... 5
SET UP ...................................... 5
PACKAGE CONTENTS ............ 6
INSTALLATION......................... 7
Locations to avoid: ................. 7
GAME LEVELING ..................... 8
CORD ........................................ 9
SPECIAL EDITION (SE)
OPERATION MANUAL
Version 3
th
427 15
Street, Daytona Beach, Florida 32117
Tel: (386) 677-0761 Fax: (386) 677-0794
(for online viewers click "Back to TOC" at anytime to return to this list)
Programming Chart .............. 11
INSPECTION ........................... 12
Maintenance ........................ 12
Cleaning ............................... 13
TEST MODE ............................ 13
ERROR CODES ...................... 13
COIL BED SERVICING........... 14
SHAFT CLEANING .............. 14
TROUBLESHOOTING ............ 19
REPAIR ................................... 21
and Relay Servicing ............. 21
.............................................. 23
Replacement......................... 24
PARTS LIST ............................ 24
WARRANTY ............................ 28
................................................. 29
MAY 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Whac-A-Mole SE Version 3 and is the answer not in the manual?

Questions and answers

Related Manuals for Bob's Space Racers Whac-A-Mole SE Version 3

Summary of Contents for Bob's Space Racers Whac-A-Mole SE Version 3

  • Page 1: Table Of Contents

    SPECIAL EDITION (SE) OPERATION MANUAL Version 3 ©2011 Bob’s Space Racers Incorporated 427 15 Street, Daytona Beach, Florida 32117 Tel: (386) 677-0761 Fax: (386) 677-0794 (for online viewers click “Back to TOC” at anytime to return to this list) Table of Contents MODEL VIEW ......

  • Page 2: Model View

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 MODEL VIEW Back to TOC Whac-A-Mole® SE Version 3...

  • Page 3: Specifications

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 SPECIFICATIONS Back to TOC Rated power supply: 110VAC ±5%, 60 Hz. (Note: As for the actual voltage, please refer to the label on the game). Power consumption: Minimum 125W (1.14 Amps) Dimensions: 28”...

  • Page 4: Introduction

    Back to TOC Overview Thank you for purchasing the new Whac-A-Mole® SE from Bob's space Racers. Built on a long tradition of value, the new "SE" version Whac-A-Mole® retains all of the great game play of the original game yet is specifically designed for today's Arcade environment. The new game uses technology specifically developed for this application.

  • Page 5: Important Safety Information

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 IMPORTANT SAFETY INFORMATION Back to TOC WARNING: Unplug the game from the AC wall receptacle when servicing this product. Failure to do so could result in serious injury to yourself or others. Use only a GROUNDED AC receptacle.

  • Page 6: Package Contents

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 PACKAGE CONTENTS Back to TOC Be sure to check that you have received all packages indicated below. (1) Game Unit (2) Accessories NAME SPECIFICATION ILLUSTRATION NOTE Wrapped up 10A/250V, 10 feet Power cord inside coin (Part # E0027145)

  • Page 7: Installation

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 INSTALLATION Back to TOC Check the parts list before installation. Verify that all parts that have been received and are in good condition. ATTENTION ●For indoor use only! Play zone (Operation Zone): This machine requires space for playing the game.

  • Page 8: Game Leveling

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 GAME LEVELING Back to TOC Install this machine on a flat surface. Adjust levelers to lift the legs and level game. Make sure that the machine is level with the floor. If the machine is not level, the game may not play well.

  • Page 9: Connecting The Power Cord

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 CONNECTING THE POWER CORD Back to TOC 1. Insert the socket end of power cord into the power input of the game. 2. Insert the power cord plug into a service outlet. WARNING ●...

  • Page 10: Instruction For Play

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 INSTRUCTION FOR PLAY Back to TOC 1. Insert coin(s), the game starts. 2. The object of the game is to hit the moles heads with the hammer as soon as the mole sticks its head out of the hole.

  • Page 11: Programming Chart

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 2. Press the "SELECT" button to scroll through the various options (see “Programming Chart” below). Option Select Button 3. Press the "STEP" button to scroll through the various settings for each option. Programming Chart Back to TOC Options with Default Settings ( )

  • Page 12: Maintenance And Inspection

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 4. Press the "PROGRAMMING" button once again to EXIT the programming mode. The display will show the revision screen first, followed by the Mole heads moving up and down, before returning to normal mode as shown below.

  • Page 13: Cleaning

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 Cleaning CLEANING - Clean the outer surfaces of the game with a commercial spray type cleaner. DO NOT however, use glass cleaner or commercial sprays on the marquee graphic panel. Use a good quality spray type furniture polish to keep the game looking good.

  • Page 14: Coil Bed Servicing

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 COIL BED SERVICING Back to TOC The coil bed is the assembly that houses the solenoids, score sensors and Whac-A-Mole® heads. This unit is built as an assembly to make servicing and repair easy. The entire unit removes from the game as a sub-assembly in just a couple of minutes.
  • Page 15 ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 Procedure 2 Instructions Back to TOC Cleaning Mole Head Shafts without removing them from the game unit . Open the front of the game unit for access 3. Remove the clip using a short flathead 3.
  • Page 16 ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 Procedure 3 Instructions Back to TOC Removing Mole Heads for cleaning 1. Turn off the A.C. power to the game. 2. Remove the 2 bolts that attach the playfield 3. Lift the playfield up and pull forward to remove it to the top of the main cabinet.
  • Page 17 ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 6. Disconnect the two Molex connectors that are connected to the coil bed assembly. WARNING! REMOVE WITH CARE. SENSORS ARE EASILY BROKEN!!!!! 8. Remove Mole Head from the Assembly by pulling it 7.
  • Page 18 ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 11. Reassemble the washers on the top part of the 12. Insert the shaft into the assembly. shaft. *Note the correct order 13. Reassembly the washers. Note the correct order 14.

  • Page 19: Troubleshooting

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 TROUBLESHOOTING Back to TOC WARNING For your safety, and to reduce risk of damage to your game read the Important Safety Information on page 5 before attempting any troubleshooting procedure. TROUBLESHOOTING PHILOSOPHY When troubleshooting any product, certain general guidelines should be followed.

  • Page 20: Quick Reference Troubleshooting Chart

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 Quick Reference Troubleshooting Chart Back to TOC Symptom Possible Problem Solution Power (ii) Power Sound Problems Low Volume Check Volume Control and adjust as -No sound necessary -Low Sound Faulty speaker harnessing Check connections and/or repair harnessing -Intermittent Sound Faulty speaker...

  • Page 21: Electronic / Electrical Repair

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 Faulty solenoid coil Check coil resistance and replace solenoid coil Faulty main P.C. board or component Repair or replace main P.C. board Mole head will not Disconnected sensor Check connections. score Faulty Connector or Connections Check and/or replace Sensor...

  • Page 22: Score Sensor Replacement

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 6. Re-install the solenoid plunger bearing making sure that the anti-rotation roll pin engages the notch in the top of the solenoid. 7. Re-install the bearing retaining bolts. NOTE: INSTALL THE BOLTS EVENLY AND DO NOT OVERTIGHTEN. IF THE BOLTS ARE TIGHTENED UNEVENLY, SOLENOID PLUNGER SHAFT BINDING MAY OCCUR.

  • Page 23: Marquee Display And Florescent Bulb / Ballast Replacement

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 MARQUEE DISPLAY AND FLORESCENT MARQUEE BULB / BALLAST REPLACEMENT GRAPHICS Back to TOC PANEL SCREWS 1. Turn off A.C. power to the game and unplug the game from the A.C. receptacle.

  • Page 24: Florescent Ballast Replacement

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 FRONT VIEW (MARQUEE NOT SHOWN) Florescent Ballast Replacement BULB 1. Remove the florescent bulb and the retaining clip. 2. Unscrew the bulb socket from the rear of the cabinet by removing the SOCKET (2) screws.
  • Page 25 ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 Decal, Left Side Decal, Right Side CX800207 Panel Playfield CX800235 Playfield Support Box Assembly E0023750 5 amp, 250 volt fuse E0800913 Electrical Wire Box E0025100 12VDC Mech Counter E0800005 Solenoid, 175 Stator E0800040 Ballast 120v Fluorescent E0800041...
  • Page 26 ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 E0800154 Sensor Tube Receiver E0800165 Sensor Tube Transmitter 3 Digit – 7 Segment Display EX033609 W0800002 Shaft Whac-A-Mole Head Plunger W0800004 Shaft Elect Whac-A-Mole Plunger 5VDC/12VDC/110VAC/ E0800450 200 W PSU E0022860 27 VDC 11.7 Amp PSU W0800207...
  • Page 27 ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 All Unit Wiring Harnesses with Plugs Mole Box Assembly (Does not include Mole Plungers, coils or cables)

  • Page 28: Warranty

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 WARRANTY Back to TOC BOB’S SPACE RACERS INC. 90 DAY COIN-OPERATED GAME WARRANTY INCLUDED IN THIS WARANTY Bob’s Space Racers ® , Inc. warrants to the original purchaser only that the equipment that is the subject of this sale conforms to its specifications, and is free from defects under normal service for a 90 day period from the original date of deliver.

  • Page 29: When Calling For Service

    ® BOB’S SPACE RACERS WHAC-A-MOLE® SE ARCADE MANUAL BSR V3.0 WHEN CALLING FOR SERVICE Back to TOC 1. When calling for service, please check the service manual first. Many times the answer to your problem has been addressed in this documentation. 2.
