  • Page 1 Bob’s Space Racers ® Inc. ©1976-2019 427 Whac-A-Mole Way, Holly Hill, Florida 32117 Phone - (386) 677-0761 Fax - (386) 677-4865 https://www.bobsspaceracers.com...

  • Page 2: Table Of Contents

    Power Requirements …………………………………………………..………………. pg 3 Check Packing List ………………………………………………………..……………. pg 3 Removing Product off Pallets ..…………………………………………..……………. pg 4 Setting Up The Prize Wheels …..………………………………………..……………. pg 4 Setup ………………………………………………………..……………………………. pg 5 2.0 : Operator’s Procedure ……..……………………………………………………………... pg 7 Object of the Game ….……………….………………………………….……………... pg 7 Operate …………………………………………………………….…………………….

  • Page 3: Introduction

    1.0 Introduction Overview This manual contains important information about Prize Wheel™. Such as: Setup, instructions how to play, maintenance, troubleshooting, game options settings, and service. Appendixes A and B contain information about policies, warranty, and service. Appendix D is a parts breakdown of commonly replaced parts. Safety This game has moving parts.

  • Page 4: Removing Product Off Pallets

    Merchandise Cabinet from pallet. • Pallet 3 Upper Merchandise Cabinet Do not slide Upper Merchandise Cabinet off pallet, it can damage the bottom. Setting Up the Prize Wheels • Place the Upper Merchandise Cabinet behind the Lower Merchandise Cabinet along the wall •...

  • Page 5: Setup

    Setup • Parts to Setup Marquee Wheel Upper Lower Merchandise Merchandise Cabinet Cabinet Harness Jumper Operator’s Walkway Player Counter Bob’s Space Racers ® Inc. ©1976-2019 P a g e...
  • Page 6 • Once fully assembled ensure the game is level. • Make necessary game connections □ Board Harness is connected to Jumper □ Player counter is connected to Jumper □ Speaker □ Button Assembly □ Connect Middle wheel to Top Wheel □...

  • Page 7: Operator's Procedure

    2.0 Operator’s Procedure Object of the Game Land on all sections that say WINNER on each wheel starting from the bottom the easiest and advance to the wheel above with the difficulty gradually increasing. Pressing the blinking button will cause the spinning wheel to start its stopping sequence.

  • Page 8: Maintenance

    3.0 Maintenance Maintenance Recommendations Clean the outer surfaces of the game with a commercial spray type cleaner. DO NOT USE commercial chemical sprays on vinyl graphics. DO USE a good quality spray type furniture polish to keep the game looking good.

  • Page 9: Troubleshooting

    4.0 Troubleshooting Troubleshooting Philosophy When troubleshooting any product, certain general guidelines should be followed Always check to be sure that your game power is turned on. Ensure that all of the fuses in the game are functional and that the AC voltage is in the proper operating range for your game.

  • Page 10: Schematics

    Schematics Master Board View 1 Master Board View 2 Bob’s Space Racers ® P a g e | 10 Inc. ©1976-2019...
  • Page 11 Bottom Wheel Middle Wheel Bob’s Space Racers ® Inc. ©1976-2019 P a g e | 11...
  • Page 12 Top Wheel LED Controller Bob’s Space Racers ® P a g e | 12 Inc. ©1976-2019...
  • Page 13 Button Speaker / Meters Bob’s Space Racers ® Inc. ©1976-2019 P a g e | 13...
  • Page 14 Power Supplies Coin / Tickets Bob’s Space Racers ® P a g e | 14 Inc. ©1976-2019...
  • Page 15 LED Panels Bob’s Space Racers ® Inc. ©1976-2019 P a g e | 15...

  • Page 16: Options Settings - Gd Electronics

    5.0 Options Settings – GD Electronics RECOMMENDED MIDWAY OPTION SETTINGS Program: JWM.V15 SW1 – Dip Adjustment Item Description Coins per Credit Score per Ticket MIDWAY Game Version Not Used Attract Mode SW2 – Dip Adjustment Item Description Not Used Not Used Not Used SW3 –...

  • Page 17: Service

    6.0 Service Calling for Service When calling for service, please check the operator’s manual first. You may find a solution to your problem within this manual. Please make sure you have the serial number of the game ready when you call. If this is a repeat call, please tell the service technician that you have made a previous call regarding this problem.

  • Page 18: Family Entertainment Center Options

    7.0 BSR Family Entertainment Center (FEC) Options Swipe Card This option will allow any game to be operated without an attendant. Configurations: • BSR will run the wires for the card swipe system • If the customer pre-purchases the swipe card system, BSR can install them on the game.

  • Page 19: Appendix A: Policies

    Appendix A: Policies Service Policy Here at BOB’S SPACE RACERS® INC., we pride ourselves in providing the highest quality, long lasting, and easy to maintain equipment. Technical Support Service hours are from 8:30 am to 5:00 pm, EST, Monday through Friday, excluding holidays.

  • Page 20: Appendix B: Warranty

    Appendix B: Warranty Game Warranty BOB’S SPACE RACERS® INC. ©1976-2019 1 YEAR GAME WARRANTY INCLUDED IN THIS WARANTY Bob’s Space Racers® Inc., warrants to the original purchaser only that the equipment that is the subject of this sale conforms to its specifications, and is free from defects under normal service for one-year period from the original date of deliver.

  • Page 21: Appendix C: Federal Communications Commission Statement

    Appendix C: Federal Communications Commission Statement This equipment has been tested and found to comply with limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 22: Appendix D: Parts List

    Appendix D: Parts List Part # Description Picture MASTER BOARD E0805001 SENSOR STEPPER MOTOR DRIVER Model: M542C WHEEL MOUNTING BOLTS POWER SUPPLY E0022863 MEANWELL RSP-320-24 POWER SUPPLY E0022750 MEANWELL HRP-450-12 POWER SUPPLY E0022755 MEANWELL HRP-450-5 FRONT COVER PLEX Please Specify which Wheel BOTTOM | MIDDLE | TOP LARGE TICKET M0008600...

  • Page 23: Appendix E: Revision

    Appendix E: Revision Revision Date of Revision Description of Revision Approved by March 19, 2019 Bob’s Space Racers ® P a g e | 23 Inc. ©1976-2019...
  • Page 24 Bob’s Space Racers ® Inc. ©1976-2019 427 Whac-A-Mole Way, Holly Hill, Florida 32117 Phone - (386) 677-0761 Fax - (386) 677-4865 Bob’s Space Racers ® P a g e | 24 Inc. ©1976-2019...
