- Page 1 2CKA001473B8291 │ 05.07.2018 Product manual Electronic room temperature controller insert 1098 U-101 1098 UF-101...
-
Page 2: Table Of Contents
Table of contents Table of contents Notes on the instruction manual........................4 Safety ................................. 5 Information and symbols used ......................5 Intended use ............................6 Improper use ............................6 Target group / Qualifications of personnel ................... 7 2.4.1 Operation ............................7 2.4.2 Installation, commissioning and maintenance ..................7 Safety instructions .......................... - Page 3 Table of contents 8.6.7 Adjust temperature ..........................37 Display during mains power failure ....................39 Maintenance ..............................40 Cleaning ............................... 40 Index ................................41 │3 Product manual 2CKA001473B8291...
-
Page 4: Notes On The Instruction Manual
If you pass the device on, also pass on this manual along with it. Busch-Jaeger accepts no liability for any failure to observe the instructions in this manual. If you require additional information or have questions about the device, please contact Busch- Jaeger or visit our Internet site at: www.BUSCH-JAEGER.de... -
Page 5: Safety
However, residual hazards remain. Read and adhere to the safety instructions to prevent hazards of this kind. Busch-Jaeger accepts no liability for any failure to observe the safety instructions. Information and symbols used The following Instructions point to particular hazards involved in the use of the device or provide... -
Page 6: Intended Use
Each use not listed in Chapter 2.2 “Intended use“ on page 6 is deemed improper use and can lead to personal injury and damage to property. Busch-Jaeger is not liable for damages caused by use deemed contrary to the intended use of the device. The associated risk is borne exclusively by the user/operator. -
Page 7: Target Group / Qualifications Of Personnel
Safety Target group / Qualifications of personnel 2.4.1 Operation No special qualifications are needed to operate the device. 2.4.2 Installation, commissioning and maintenance Installation, commissioning and maintenance of the device must only be carried out by trained and properly qualified electrical installers. The electrical installer must have read and understood the manual and follow the instructions provided. -
Page 8: Safety Instructions
Safety Safety instructions Danger - Electric voltage! Electric voltage! Risk of death and fire due to electric voltage of 100 … 240 V. Dangerous currents flow through the body when coming into direct or indirect contact with live components. This can result in electric shock, burns or even death. -
Page 9: Information On Protection Of The Environment
Information on protection of the environment Information on protection of the environment Environment Consider the protection of the environment! Used electric and electronic devices must not be disposed of with domestic waste. – The device contains valuable raw materials which can be recycled. Therefore, dispose of the device at the appropriate collecting depot. -
Page 10: Setup And Function
4.1.1 Control elements The following modules are used. The device can only be operated with central cover plate 6435-xxx. The cover plate is latched onto the control element as a so-called "floating rocker". 1098 U-101 6435-xxx 1098 UF-101 │10 Product manual 2CKA001473B8291... -
Page 11: Technical Data
Nominal voltage: 230 V AC ±10%, 50 Hz Change-over Nominal power: contact/normally open contact 10 (4) A closed while de- energized (connection 1) 1098 U-101 Change-over contact/normally closed contact 5 (2) A open while de- energized (connection 2) Change-over contact/normally... -
Page 12: Connection, Installation / Mounting
Connection, installation / mounting Connection, installation / mounting Danger - Electric voltage! Risk of death due to electrical voltage of 100 … 240 V during short-circuit in the low-voltage conduit. – Low-voltage and 100 … 240 V conduits must not be installed together in a flush-mounted box! Requirements for the electrician Danger - Electric voltage! -
Page 13: Mounting/Dismantling
Connection, installation / mounting Mounting/dismantling Danger - Electric voltage! Risk of death and fire due to electric voltage of 100 to 240 V. – Work on the 100 - 240 V supply system may only be performed by authorised and qualified electricians. –... - Page 14 Connection, installation / mounting – If the device is in its as-delivered state, pull the attachment off the flush-mounted insert with your hands. – Pull the attachment off only with your hands. Do not lever parts off with screwdrivers or similar hard objects. This will damage the device.
-
Page 15: Electrical Connection
Connection, installation / mounting Electrical connection 1098 UF-101 1098 U-101 Fig. 4: Circuit diagrams Terminal designation Assignment Phase Neutral conductor Output for controlling the heating load Output for controlling the cooling load ϑ Remote sensor connections The sensor cable must be installed in a protective cable duct. -
Page 16: Commissioning
Commissioning Commissioning Notice The setup is carried out automatically during initial commissioning or when resetting the settings (RESET). │16 Product manual 2CKA001473B8291... -
Page 17: Operation
Operation Operation No special qualifications are needed to operate the device. Notes on operation In the event of a power failure, the internal clock continues to operate for about 10 hours. After this the time and date have to be reprogrammed. All other data remain saved. The operating element can be removed from the flush-mounting insert for approximately 20 minutes and adjusted separately. -
Page 18: Operating Modes
Operation Operating modes Fig. 5: Display views of operating modes Icon Operating mode AUTO At the programmed times, the system is brought to the programmed set values for comfort, stand-by, and night mode. * COMFORT MODE Temperature when somebody is present. * STANDBY MODE Temperature when nobody is present This function is not automatically activated at the factory. -
Page 19: Normal Operation
Operation Normal operation 8.3.1 Display Fig. 6: Icons Function Display of programmed daily cycles Info line / time / date Icon for °C Mains power failure Status display = heating Current weekday "Automatic" operating mode "Comfort / Standby" operating mode "Night"... -
Page 20: Button Assignment
Operation 8.3.2 Button assignment Fig. 7: Button assignment of the cover pate Button Function In setting mode Adjusting values RESET Calling up menu level Return to operating and switching to setting mode mode. Press all buttons of – Keep the button the rocker switch pressed for 2 simultaneously for... -
Page 21: Device Settings
Operation Device settings All settings of the device are carried out supported by text-controlled operator prompting. The language, time and date have to be set first during initial commissioning. Notice Values which need to be changed flash and are displayed in grey in the following illustrated examples. -
Page 22: Menu Tree
Operation 8.4.1 Menu tree Menu Menu items Display Setting (function) Voice Country Select country (language setting) Starting times Block programming Setting the starting times for switching Comfort mode the temperature regulation on and off. The same times are taken over for the days from Monday to Friday. - Page 23 Operation Standby mode 30.0°C Night mode 25.0°C │23 Product manual 2CKA001473B8291...
-
Page 24: Language
Operation 8.4.2 Language The language is set via the selection of the country. Fig. 8: Country / language selection Button Display Entry / Comments Select language Germany – Select the country via the arrow buttons. – Confirm your selection with the OK button. You simultaneously switch to the next menu item. -
Page 25: Reset (Resetting The Device)
Operation 8.4.3 RESET (Resetting the device) 1. Remove the cover and press the reset button. 2. Replace the cover. 3. Then, again set the language, the date and the time, see see chapter 8.4 “Device settings“ on page 21. Fig. 9: Reset 8.4.4 RESET (resetting to the factory settings) -
Page 26: Setting The Starting / Switching Times
Operation Setting the starting / switching times 8.5.1 General ■ STANDBY times can only be set to a point of time that is later than the set comfort time. ■ Night mode cannot be set after 23:59 h, since the starting time (night) will jump to the comfort time programmed on the same day. -
Page 27: Block Programming
Operation 8.5.2 Block programming Fig. 11: Menu item – Block Button Display Entry / Comments – Press the menu button for 2 seconds to switch to the setting Starting times mode. BLOCK – Press the OK button to select menu item "Block programming". The weekdays flash. - Page 28 Operation – Press the menu button to switch to the operating mode. Table 1: Sequence of operating steps │28 Product manual 2CKA001473B8291...
-
Page 29: Calling Up Special Functions
The adjustment range depends on the type of the device. Type Value Adjustment range 45.0° 05.0 – 15.0°C 1098 U-101 20.0 – 30.0°C 10.0 – 25.0°C 1098 UF- 35.0 – 50.0°C In this example a temperature of 45°C has been set. - Page 30 Operation The preset minimum temperature of 10°C flashes. – Set the desired temperature via the arrow buttons. 20.0° In this example a temperature of 20°C has been set. – Confirm your entry with the "OK" button. Max and Min values The maximum and minimum temperature values have been set.
-
Page 31: Valve Protection
Operation 8.6.2 Valve protection Fig. 13: Menu item – Valve protection In order to prevent the valve of the heater/circulating pump from getting blocked, it can be programmed to open automatically once a day. When the service circuit is active, the heating valve opens daily at 10:00 for 5 minutes. -
Page 32: Standby Times
Operation 8.6.3 Standby times Fig. 14: Menu item – Standby times Standby mode is not activated at the factory. The activation and adjustment (reduction) of the temperature during absence can be activated or deactivated here. Button Display Entry / Comments –... -
Page 33: Offset
Operation 8.6.4 OFFSET Fig. 15: Menu item OFFSET If the room temperature set on the device and the temperature measured on-site do not correspond, the temperature can be adjusted via the OFFSET value (correcting value) by up to ±5°C. Button Display Entry / Comments –... -
Page 34: Button Lock
Operation 8.6.5 Button lock Fig. 16: Menu item - Button lock To protect the basic settings against being unintentionally changed, the device has a button lock. To release the button lock when it is active, one of the buttons must be pressed for 5 seconds. -
Page 35: Date / Time
Operation 8.6.6 Date / Time Fig. 17: Date Button Display Entry / Comments – Press the menu button for 2 seconds to switch to the setting Starting times mode. Date--Time – Select menu "Date - Time" via the arrow buttons. –... - Page 36 Operation "AUTO". Table 7: Sequence of operating steps │36 Product manual 2CKA001473B8291...
-
Page 37: Adjust Temperature
Operation 8.6.7 Adjust temperature Fig. 18: Menu item – Temperature adjustment Here, the preset temperature values can be changed manually as required. Push- Display Entry / Comments buttons – Press the menu button for 2 seconds to switch to the Starting times setting mode. - Page 38 Operation Effects in "Comfort / Standby or Night mode": There is an adjustment to the changed temperature values. The AUTO time program is not executed. The corresponding icons are deactivated. – Press the menu button to switch to the operating mode. Table 8: Sequence of operating steps │38 Product manual 2CKA001473B8291...
-
Page 39: Display During Mains Power Failure
Operation Display during mains power failure The illustration on the right shows an example of a display with the mains voltage activated. Fig. 19: Display during normal operation Fig. 20: Display during mains power failure The illustration above shows the display during a mains voltage failure or the control element unplugged. -
Page 40: Maintenance
Maintenance Maintenance Cleaning Caution! - Risk of damaging the device! ■ When spraying on cleaning agents, these can enter the device through crevices. – Do not spray cleaning agents directly onto the device. ■ Aggressive cleaning agents can damage the surface of the device. –... -
Page 41: Index
