English
5. Product information
5.1 Type key
Example: MVIS 408-1 / 16 / K / 3- 400 – 50 - 2
MVIS
4
08
-1
/16
/K
/3 ~400
50
2
5.2 Technical data
Maximum residual pressure
Maximum operating pressure
Maximum inlet pressure
Temperature range
Fluid temperature
Ambient temperature
Electrical data
Type of motor protection
Insulation class
Frequency
Voltage
Other data
Humidity
Height
Noise level dB(A)
0/+3 dB(A)
16
Vertical high-pressure multistage centrifugal pump with glandless motor
Volume flow in m³/h
Number of impellers
Pump material code
1 = stainless steel 1.4301 (AISI 304)
Rated pressure (bar)
Gasket type EPDM
3 = 3~, three-phase current 230 V – 400 V (motor voltage)
Frequency in Hz
Number of poles
16 bar
10 bar
Notice: Actual inlet pressure (Pinlet) + pressure at pump zero volume flow
must be below the maximum operating pressure of the pump.
Pinlet + P at pump zero-flow rate ≤ Pmax of the pump
The pump's operating pressure can be found on the pump's rating plate.
Pmax
-15 °C to +50 °C
-15 °C to +40 °C (other temperature ranges upon request)
See rating plate
< 90 %, without condensation
< 1000 m (> 1000 m upon request)
≤ 55 dB(A)
