Powering The Rps And The Netvanta 1238 Poe; Additional Information - ADTRAN NetVanta 1110 Quick Start Manual

100-240 VAC
50-60 Hz
5A MAX
P
OWERING THE
1. Plug the female end of the RPS unit's power cord (provided with the unit) into the power
receptacle labeled AC Input on the rear panel of the unit.
2. Connect the other end (3-prong plug) of the RPS unit's power cord to the proper 100 to
130 VAC or 190 to 250 VAC grounded receptacle.
3. Plug the female end NetVanta 1238 PoE unit's power cord (provided with the unit) into the
power receptacle labeled 110-240 VAC, 50-60 Hz, 5 A MAX on the rear panel of the unit.
4. Connect the other end (3-prong plug) of the NetVanta 1238 PoE unit's power cord to the
proper 100 to 130 VAC or 190 to 250 VAC grounded receptacle.
•
•
•
A I
DDITIONAL NFORMATION
For additional information about accessing and setting up the NetVanta 1238 PoE, refer to the
NetVanta 1230 Series Fast Ethernet Switch Quick Start Guide
article 2518) supplied with your unit or online at http://kb.adtran.com.
For additional details on product features, specifications, installation, and safety, refer to
NetVanta 1230 Series Fast Ethernet Switch Hardware Installation Guide
Base article 2517) online at http://kb.adtran.com.
4
AC INPUT
NetVanta 1238 PoE
RPS Connector
Thumb
Screw
Figure 3. RPS to NetVanta 1238 PoE Connection
RPS
AND THE
This unit shall be installed in accordance with Articles 300 and 400 of
NEC NFPA 70.
Power to the AC system must be from an appropriately rated and
grounded source.
Maximum recommended ambient operating temperature is 50
Copyright © 2011 ADTRAN, Inc. All Rights Reserved.
Offset Tab
RPS OUTPUT
TOP TOP TOP TOP
RPS
TOP TOP
TOP TOP
Thumb
Screw
N V 1238 P
ET ANTA
(ADTRAN's Knowledge Base
NetVanta 1110 RPS
RPS Connector
Offset
Tab
E
O
o
C.
(ADTRAN's Knowledge
