Summary of Contents for Jet JCPP-200
- Page 1 OPERATOR'S MANUAL CABLE HAND PULLER PROD. NO. 111225 MOD. NO. JCPP-200 PROD. NO. 111228 MOD. NO. JCPP-400D MULTI-FUNCTIONAL USE RECREATIONAL FENCING INDUSTRIAL EMERGENCY FRAMING www.jetequipment.com...
- Page 2 ONE YEAR LIMITED WARRANTY JET™ Cable Hand Pullers are guaranteed to be free of defects in material and workmanship. If one of these products fails during the first year of operation due to defective material or workmanship it will be repaired or replaced at our discretion.
- Page 3 Lifting Lifting Cable Leverage Capacity Capacity Capacity Capacity Diameter Single Double Single Double Line Line Line Line 111225 JCPP-200 2 ton 1 ton 3/16" 15:1 111228 JCPP-400D 2 ton 4 ton 1 ton 2 ton 1/4" 15:1 CABLE REPLACEMENT A “keyhole” opening of special quick-change design in the barrel of the ratchet wheel and a swaged end to the cable permit instant, secure replacement of the cable.
- Page 4 TO RAISE LOAD OR APPLY TENSION Engage drive pawl and ratchet wheel by pushing pawl spring in direction of arrow “A” and then raise the handle towards the direction of arrow “C”. Each stroke of handle will wind cable to pull load. TO EXTEND CABLE Secure hook and pulley to a rigid anchor.
