π
H-8097
SHOP-VAC
WET/DRY
®
VACUUM
ATTENTION: Read all safety rules carefully before
attempting to operate. Retain for future reference.
CAUTION: Never operate this unit when flammable
materials or vapors are present because electrical
devices produce arcs or sparks that can cause a
fire or explosion. NEVER OPERATE UNATTENDED.
H-8097 SHOP-VAC
®
The H-8097 Shop-Vac
®
wet and dry nonvolatile materials. It is equipped with powerful,
permanently lubricated motors and standard filtration systems.
Double filtration is standard on Shop-Vac
vacuums. The vacuum is equipped with an easy roll caster
system. Automatic float shut-off prevents overflow during wet
pick-up. The vacuum includes versatile 1½" (3.81 cm) diameter
accessories and a rugged stainless steel tank. UL listed.
TO REDUCE RISK OF FIRE, ELECTRIC SHOCK
OR INJURY:
1.
Do not leave appliance unattended when plugged
in. Unplug from outlet when not in use and before
servicing. Connect to a properly grounded outlet
only. See Grounding Instructions on page 2.
2. Do not expose to rain. Store indoors.
3. Do not allow to be used as a toy. Close attention is
necessary when used by or near children.
4. Use only as described in these instructions. Use only
manufacturer's recommended attachments.
5. Do not use with damaged cord or plug. If appliance
is not working as it should, has been dropped,
damaged, left outdoors or dropped into water,
contact Uline Customer Service for assistance.
6. Do not pull or carry by cord, use cord as a handle,
close a door on cord, pull cord around sharp edges
or corners or run appliance over cord.
7.
Keep cord away from heated surfaces.
8. Do not unplug by pulling on cord. To unplug, grasp
the plug, not the cord.
PAGE 1 OF 9
1-800-295-5510
uline.com
IMPORTANT SAFETY INSTRUCTIONS
Wet/Dry Vacuum is for vacuuming
commercial
®
9. Do not handle plug or appliance with wet hands.
10. Do not put any object into openings. Do not use with
any openings blocked; keep free of dust, lint, hair
and anything that may reduce air flow.
11. Keep hair, loose clothing, fingers and all parts of
body away from openings and moving parts.
12. Do not pick up anything that is burning or smoking,
such as cigarettes, matches or hot ashes.
13. Do not use without dust bag and/or filters in place.
14. Turn off all controls before unplugging.
15. Use extra care when cleaning on stairs.
16. Do not use to pick up flammable or combustible
liquids (such as gasoline) or use in areas where they
may be present.
17. Do not use as a sprayer of flammable liquids, such
as oil-base paints, lacquers, household cleaners, etc.
18. Do not vacuum toxic, carcinogenic, combustible or
other hazardous materials, such as asbestos, arsenic,
barium, beryllium, lead, pesticides or other health-
endangering materials. Specially designed units are
available for these purposes.
19. Do not pick up soot, cement, plaster or drywall dust
without cartridge filter and collection filter bag in
place. These are very fine particles that may pass
through the foam and affect the performance of the
motor or be exhausted back into the air. Additional
collection filter bags are available.
20. Do not leave cord lying on the floor after cleaning. It
can become a tripping hazard.
21. Use special care when emptying heavily loaded tanks.
22. To avoid spontaneous combustion, empty tank after
each use.
23. The operation of a utility vacuum can result in
foreign objects being blown into eyes, which can
result in eye damage. Always wear safety goggles
when operating vacuum.
0719 IH-8097

Advertisement

Table of Contents
loading

Summary of Contents for U-Line SHOP-VAC H-8097

  • Page 1 π H-8097 1-800-295-5510 uline.com SHOP-VAC WET/DRY ® VACUUM IMPORTANT SAFETY INSTRUCTIONS ATTENTION: Read all safety rules carefully before 9. Do not handle plug or appliance with wet hands. attempting to operate. Retain for future reference. 10. Do not put any object into openings. Do not use with CAUTION: Never operate this unit when flammable any openings blocked;...
  • Page 2: Grounding Instructions

    STAY ALERT! Watch what you are doing and use WARNING! Do not use to vacuum lead paint common sense. Do not use vacuum cleaner debris, as this may disperse fine lead particles when you are tired, distracted, or under the into the air.
  • Page 3 UNPACKING Remove vacuum and all accessories from carton. 2. Assemble vacuum following the instructions below. IMPORTANT! Open tank cover by pushing 3. Depending on dry pick-up or wet pick-up operation, latches or clamps outward with thumbs and install proper filter. (See page 5 for filter guide) remove any accessories that may have been 4.
  • Page 4 ASSEMBLY CONTINUED CARRIAGE HANDLE ASSEMBLY SIDE TANK HANDLES ASSEMBLY 1. Take two handle supports and two 1" Attach carriage handle to tank by Figure 10 Figure 14 screws. Place screws through the inserting bolt through center hole of hole provided in center of each handle and tank, secure with nut support.
  • Page 5: Filter Combinations

    FILTERS BEST BETTER GOOD High Efficiency Collection Filter Bags Ultra Web Cartridge Filter** Reusable Disc Filter ® • Dry pick-up only • Wet or dry pick-up • Dry pick-up only • Fine dust and particles • Easy cleanup • General purpose •...
  • Page 6: Operation

    OPERATION WET PICK-UP INSTALLING AND CLEANING THE CARTRIDGE See the Shop-Vac® vacuum filter guide on page 5 to Slide cartridge filter down over filter Figure 19 determine which type of wet filtration is best for your cage. (See Figure 19) needs.
  • Page 7 OPERATION CONTINUED AUTOMATIC SHUTOFF STORAGE The vacuum cleaner is equipped with an automatic Before storing the vacuum cleaner, always empty and shutoff that operates when picking up liquids. When the clean the tank. Never allow liquids to sit in the tank for liquid in the tank reaches a certain level, an internal any extended period of time.
  • Page 8: Routine Maintenance

    SHOP-VAC VACUUM FILTER CLEANING REFERENCE ® Foam Sleeve Full Polyester Sleeve Super Performance Filter Reusable Disk Filter CleanStream Abrasion- ® Resistant Cartridge Filter FILTER CLEANING INSTRUCTIONS Foam Sleeve Rinse with water, dry and reinstall. Full Polyester Filter Brush off dirt and reinstall; if filter gets wet, rinse with water, dry and reinstall.
  • Page 9: Troubleshooting

    TROUBLESHOOTING ISSUE POSSIBLE CAUSE(S) CORRECTIVE ACTION Parts/accessories missing Packed in tank 1. Check in tank. Vacuum cleaner will not start No power at receptacle 1. Check for power. 2. Defective switch 2. Replace switch. 3. Defective motor 3. Replace motor. Dust discharging from exhaust Filter not installed or installed Properly install filter.
