Summary of Contents for EdilKamin KLIK

  • Page 1 KLIK PELLET STOVE Installation, use and maintenance page 2...
  • Page 2: Table Of Contents

    Maintenance Troubleshooting The original language of this manual is Italian The undersigned EDILKAMIN S.p.A., with registered office in Via Vincenzo Monti 47 - 20123 Milan (Italy) - Tax ID Code and VAT number 00192220192 Hereby declares, under its sole responsibility, that:...
  • Page 3 European regulations. For the will operate to best effect and in complete safety. installation, and for anything not specifically indicated in the Commissioning is required for activation of the Edilkamin manual, observe local regulations. manufacturer warranty. The warranty is only valid in the The diagrams provided in this manual are for illustration country where the product was bought.
  • Page 4: Safety Information

    Use of the product as a support or ladder. DO warranty certificate inside the product: specifically, NOT CLIMB ONTO THE PRODUCT OR USE IT AS neither Edilkamin nor the retailer are liable for A SUPPORT. Risk of damage and injury. damage resulting from incorrect installation or •...
  • Page 5: Dimensions

    DIMENSIONS KLIK - DIMENSIONS (cm) Ø 4 Combustion air Ø 8 Smoke outlet USER/INSTALLER...
  • Page 6: Technical Data

    Protection rating Fuse 4 AT, 250 Vac 5x20 The above data is for guidance only and was measured during certification by a notified body. EDILKAMIN s.p.a. reserves the right to modify the product without notification in the interests of improvement. USER/INSTALLER...
  • Page 7: Unpacking

    UNPACKING PREPARATION AND UNPACKING Package materials such as plastic and The packaging materials are neither toxic nor noxious films my be dangerous for children. and do not require special disposal. Suffocation hazard. The user is responsible for storing, disposing of and Keep packages away from children.
  • Page 8 UNPACKING UNPACKING The delivery consists of two packages: • one (1) containing the structure of the stove with the side panels already fitted; • one (2) with the top The package with the stove contains: • warranty certificate, • glove, •...
  • Page 9: Cover

    UNPACKING POSITIONING THE TOP The only component that is not fitted is the top. Screw on the rubber grommets, the screws and the rubber caps. Then, position the top. INSTALLER...
  • Page 10: Installation

    Contact the authorised Edilkamin Technical Assistance Any extraction fans operating in the same room or Centre. area as the product, may affect its draught.
  • Page 11 INSTALLATION FLUE SYSTEM THE FUMES DUCT (Fumes duct, flue and chimney pot) Further to the general prescriptions for the fumes duct This chapter has been drawn up pursuant to European and flue, the fumes duct: regulations EN 13384, EN 1443, EN 1856 and EN •...
  • Page 12 INSTALLATION THE FLUE: EXTERNAL AIR INTAKE Further to the general prescriptions for the fumes duct In general, we suggest two ways to ensure a proper and flue, the flue: flow of combustion air. • must only be used for discharging fumes •...
  • Page 13 The electrical system must be compliant; check the operation of the earth in particular. Edilkamin is not responsible for malfunctions resulting from an improperly earthed system. The power line must be of adequate section for the power of the appliance.
  • Page 14: Instructions For Use

    USER INSTRUCTIONS FIRST IGNITION (COMMISSIONING) PHASES FUEL • Make sure you have read and understood this Use Class A1 wood pellets conforming to the UNI • manual EN ISO 17225-2 standard or similar local regulations • Remove all flammable materials from the appliance envisaging, for example, products with the following •...
  • Page 15 USER INSTRUCTIONS OPERATION Description. The access to and adjustment of these functions is described below: Mode Size settings MANUAL • power level (from 1 to 3) with (POWER) consequent level of automatic ventilation DELAY • time after which the stove comes on.
  • Page 16 (from 2 to 12 hours after). • LED signalling PELLETS RUNNING OUT (after about half-an-hour the appliance will go out) Nome: KLIK • LED signalling CLEAN (the appliance switches off and, when the appliance is off and cold, you need to perform Rev:...
  • Page 17 USER INSTRUCTIONS REMOTE CONTROL - OPTIONAL The service technician can install a remote control on the appliance. REMOTE CONTROL WILL ONLY GIVE COMMANDS WHEN THE POWER KNOB IS TURNED TO POSITION 0. WHEN IN THE OTHER POSITIONS, IT WILL ONLY DISPLAY THE STATUS OF THE APPLIANCE.
  • Page 18: Maintenance

    MAINTENANCE Disconnect the product from the power supply. Failure to service the product properly will prevent it from working properly. Any problems due to failure in servicing the stove will void the warranty. DAILY MAINTENANCE • Do not dump the cleaning residue into the pellet (To be performed always when the LED tank.
  • Page 19 For any spare parts, contact your dealer or technician. flue every 3 months. Using non-original spare parts may damage the appliance and relieves Edilkamin of all liability for You should clean the chimney system at least once a damage resulting such use.
  • Page 20: Troubleshooting

    TROUBLESHOOTING If problems occur, the product shuts itself off automatically. Do not disconnect from the power supply. If the appliance has switched off with the knob in position 1, 2, 3, RELAX or TURBO. To re-start the appliance, allow the switch off procedure to be completed, then move the knob to position 0 for at least five seconds, after which the signalling LEDs should go out.
  • Page 21 TROUBLESHOOTING SHUTDOWN MESSAGES AND THEIR SOLUTIONS: CLEAN LED ON: the appliance needs cleaning PELLET LED ON: the appliance needs loading with pellets BOTH LEDs ON: different kind of alarm and so you need to call the service technician. The number of flashes on the LED indicates the type of alarm according to the list below. MESSAGE PROBLEM SOLUTION...
  • Page 24 *941896* w w w . e d i l k a m i n . c o m cod. 941896-GB 06.18/B...
