Highlight a Depth Range
Depth Highlights allow you to select up to four depth ranges to be highlighted on the chart .
SOLIX
1 . From the Depth Highlights Menu, select Depth Highlights .
Tap the on/off button, or press the ENTER key, to show or
hide depth highlights .
2 . With depth highlights turned on, set the depth range for
Depth Highlight 1 by selecting Min Range or Max Range .
Press and hold the slider, or press and hold the ENTER key,
to adjust the setting .
3 . To turn on an additional highlight, select Depth Highlight
2 and tap the on/off button, or press the ENTER key .
4 . Repeat Step 2 with Depth Highlight 2 to adjust the depth
range .
5 . Repeat Steps 3-4 for each additional depth highlight (up
to four) .
Depth Highlights OFF (SOLIX)
HELIX
1 . From the Depth Highlights Menu, select Depth Highlights .
Press the RIGHT or LEFT Cursor keys to show or hide depth
highlights .
2 . With depth highlights turned on, set your desired depth
range by selecting Highlight 1 Min or Highlight 1 Max .
Press the RIGHT or LEFT Cursor key to adjust the setting .
3 . To turn on an additional highlight, select Highlight 2 .
Press the CHECK/INFO key or the RIGHT Cursor key to
display the highlight . (check mark = visible, blank = hidden)
4 . Repeat Step 2 with Highlight 2 Min and Highlight 2 Max
to adjust the depth range .
5 . Repeat Steps 3-4 for each additional depth highlight (up
to four) .
Depth Highlights ON (SOLIX)
17
Adjust the Map Display Settings
